Showing 145–160 of 229 results
-
REQUEST A QUOTE
- Manufacturer: Festo Corporation
- Part Number (MPN): 161879
- Type Code: KMPPE-B-2,5
- GTIN / EAN: 4052568072131
- Cable Length: 2.5 m (8.2 ft)
- Number of Cores: 8-wire configuration
- Conductor Cross Section: 0.25 mm² (~24 AWG)
- Outer Cable Diameter: 6.8 mm
- Surge Immunity: 0.6 kV
- Core Identification: DIN 47100 standard
FESTO KMPPE-B-2-5 161879 Plug Socket (KMPPE Series).
-
- Brand: Festo
- Model: MFH-5/3G-1/8-B
- Series: MFH
- Part number: 30484
- Valve function: 5/3-way, closed centre
- Actuation: Electrical
- Pilot supply: Internal
- Reset method: Spring return
- Pneumatic connection: G1/8
- Operating pressure: 3–10 bar
- Standard nominal flow rate: 1000 l/min
- Nominal size: 8 mm
- Valve width: 26 mm
- Manual override: Non-detenting
- Maximum switching frequency: 3 Hz
- Switch-on time: 23 ms
- Switch-off time: 30 ms
- Ambient temperature: -5 to +40 °C
- Medium temperature: -10 to +60 °C
- Weight: 400 g
-
- Brand: Festo
- Model: VADMI-70-P
- Series: VADMI
- Part number: 162526
- Type: VADMI-70-P
- Function: Vacuum generator with ejector pulse
- Laval nozzle size: 0.7 mm
- Pneumatic supply port: M5
- Vacuum connection: G1/8
- Vacuum sensor output: 1 PNP switching output
- Product weight: 180 g
-
REQUEST A QUOTE
- Operating Voltage: 24V AC (Lower functional limit: 19.20V AC).
- Control Signal: 0–10V DC modulating or proportional control.
- Positioning Force: 1600 N to 1800 N nominal force.
- Stroke / Nominal Travel: 40 mm.
- Operating Ambient Temperature: -10°C to 55°C.
- Alternative: Honeywell 24V Transformers
HONEYWELL AC24V1800N Damper Actuator (AC24V Series).
-
REQUEST A QUOTE
- Torque Rating: 5 Nm (44 lb-in), suitable for managing smooth, seal-less air damper applications up to approximately 10 sq. ft.
- Control Signal Types: Versatile triple-mode support including Modulating (analog signal), Floating (3-point), and ON/OFF (2-position).
- Nominal Voltage: 24 Vac/dc, 50/60 Hz.
- Rotation Stroke: 95° with a built-in rotation limiter and adjustable mechanical end limits.
- Runtime: 110 seconds at 50Hz or 90 seconds at 60Hz.
- Power Consumption: 5VA / 2W.
- Protection Class: IP54 rated for dust and splash protection.
- Shaft Mounting: Direct coupling for round shafts (8 to 16 mm) and square shafts (6 to 13 mm).
- Integrated Feedback: Provides a continuous voltage position feedback signal directly to the building automation system or PLC for real-time tracking of the exact damper angle.
- Auto-Calibration: Automatically runs an auto-calibration sequence upon power-cycling to map the mechanical limits before aligning to the control signal.
HONEYWELL CN7505A2001 Direct Coupled Damper Actuator (CN7505 Series).
-
REQUEST A QUOTE
- Model Series: Series 72 Modutrol IV
- Actuation Type: Non-Spring Return
- Power Supply: 120V AC, 50/60 Hz
- Power Consumption: 15 VA
- Control Input Signal: Modulating, 4–20 mA current
- Operational Torque: 150 lb-in
- Stroke Range: Adjustable from 90° to 160° (Factory set at 90°)
- Timing / Speed: 30 to 60 seconds nominal travel time
- Crankshaft: 3/8-inch square, dual-ended shaft
- Enclosure Rating: NEMA 3 weather protection (when mounted in an upright position)
HONEYWELL M7284A1004 Electric Modulating Actuator Motor (Modutrol IV Series).
-
REQUEST A QUOTE
- Stem Force / Close-off: 600 N (135 lbf)
- Supply Voltage: 24 V AC (50/60 Hz)
- Power Consumption: 4 VA
- Stroke Length: 20 mm (0.79 inches)
- Run Time: 60 seconds (1 minute) for full stroke
- Control Signal: 3-point floating (SPDT)
- Fail-Safe Operation: Non-spring return (fails in place upon power loss)
- Protection Rating: IP54
- Direct-Coupled Installation: Quick and easy installation directly onto the valve body without needing a separate linkage.
- Manual Override: Equipped with a manual control knob that allows mechanical valve adjustments during power outages.
HONEYWELL ML6420A3007 Linear Valve Actuator (ML6420 Series).
-
REQUEST A QUOTE
- Supply Voltage: 24 Vac
- Stem Force: 600 N (135 lbf)
- Stroke/Lift: 20 mm
- Run Time: 60 seconds (1 minute)
- Power Consumption: 4 VA
- Protection Rating: IP54
- Manual Override: Features an external manual control knob. If power fails, you can adjust the valve manually. Once power is restored, the knob automatically unlocks and hands control back to the system.
- No Calibrations Needed: It features a direct-coupled design with force-limiting microswitches. These switches turn off the actuator precisely when the specified force is hit, saving installation time and protecting the valve.
- Valve Compatibility: Seamlessly operates standard Resideo/Honeywell Home valve series including DE, XE, DF, XF, and V5329C lines.
- Features & Benefits: * Quick and easy installation, no separate linkage required. * Conduit connector is standard. * No adjustment…
HONEYWELL ML6420A3007-E Linear Valve Actuator (ML6420 Series).
-
REQUEST A QUOTE
- Nominal Stem Force: 1800 N (405 lbf) for heavy-duty applications.
- Stroke Length: 38 mm (1-1/2 inches).
- Power Input: 24 Vac (+10%, -15%), 50/60 Hz.
- Power Consumption: Maximum 11 VA to 16 VA depending on operational frequency.
- Run Time: Approximately 175–210 seconds for a full 38 mm stroke.
- Control Input Signals: Selectable 0…10 Vdc, 2…10 Vdc, 0…20 mA, or 4…20 mA.
- Feedback Signal: 2…10 Vdc position feedback.
- Materials: ABS plastic cover with a rugged die-cast aluminum yoke and base.
- Direct Valve Coupling: Mounts directly onto compatible Honeywell globe valves (such as V5011, V5013, V5015, V5016, and VGF series) without requiring separate linkages or adjustments.
- System Target: Optimally used for larger valves (typically 4 inches and above) due to its high 1800 N force capability.
HONEYWELL ML7421B8012-E Linear Valve Actuator (ML7421 Series).
-
REQUEST A QUOTE
- Manufacturer: HONEYWELL
- Model / Part Number: MVN7510 24V 10NM
- Rated Torque: 10 Nm
- Supply Voltage: 24 V AC/DC
- Control Type: Modulating or floating
- Running Time: 90–110 s
- Rotation Angle: Up to 95°
- Ingress Protection: IP54
- Power Consumption: 5 VA
HONEYWELL MVN7510 24V 10NM Non-Spring-Return Valve Actuator. Key specifications include Rated Torque: 10 Nm; Supply Voltage: 24 V AC/DC; Control Type: Modulating or floating; Running Time: 90–110 s.
-
- Manufacturer: HONEYWELL
- Model / Part Number: VE4025A1210T
- Valve Function: Normally closed
- Control: On/off
- Nominal Size: DN25 (1 inch)
- Supply Voltage: 220–240 VAC
- Maximum Inlet Pressure: 360 mbar
- Opening and Closing Time: Less than 1 second
- Degree of Protection: IP65
- Maximum Cycle Rate: 20 cycles per minute
- Pressure Tappings: Two 1/4-inch connections on the inlet side
-
REQUEST A QUOTE
- Electrical Design: DC PNP
- Output Function: Normally Open (NO)
- Operating Voltage: 10…30 V DC (cULus Class 2 source required)
- Switching Frequency: 10,000 Hz (10 kHz)
- Sensing Range: Magnetic sensitivity: 2.8 mT
- Current Rating: 100 mA (Permanent current rating)
- Current Consumption: < 10 mA
- Connection Type: 0.3 m PUR Cable with M8 Connector (A-coded, 3-wire)
- IP Rating: IP 65 / IP 67
- Operating Temperature: -25°C to 75°C (Max ambient up to 85°C)
IFM MK5101 Cylinder Sensor (MK Series).
-
REQUEST A QUOTE
- Detection System: Scale Shot System II, Absolute type (no tracking errors)
- Measuring Range: 12 mm (0.47")
- Resolution: 0.1 µm (0.004 Mil)
- Indicated Accuracy: 1 µm (0.04 Mil) peak-to-peak (at 20°C)
- Sampling Cycle: 4 ms
- Actuation / Fluid: Air push type / Clean dry air
- Applied Air Pressure: 0.24 MPa to 0.26 MPa
- Pressure Resistance: 0.5 MPa
- Measuring Force: • Downward: 1.2 N
- Enclosure Rating: IP67 (IEC compliant)
KEYENCE GT2-PA12K Contact Sensor (GT2 Series).
-
REQUEST A QUOTE
- Product Type: Pneumatic parallel gripper
- Action: Double-acting
- Bore Diameter: 16 mm
- Finger Motion: Parallel
The KOGANEI NHBDP-16 is a double-acting pneumatic parallel gripper for workpiece handling.
-
REQUEST A QUOTE
- Nominal Voltage: AC/DC 24 V (50/60 Hz)
- Torque: 4 Nm (approx. 35 in-lb)
- Control Type: Modulating DC 2…10 V proportional signal
- Position Feedback: DC 2…10 V
- Power Consumption: 2.5 W running / 1 W holding (5 VA wire sizing)
- Running Time (Motor): 150 seconds for 90° rotation
- Running Time (Fail-Safe): < 20 seconds (Spring Return)
- Fail-Safe Position: De-energized NC (Normally Closed / Valve Closed)
- Auxiliary Switch: Integrated SPDT switch for position feedback or safety interfacing
- Angle of Rotation: 90°
- Manual Override: Hand lever included
- Enclosure Rating: IP54 / NEMA 2
- Ambient Temperature Range: -30°C to 50°C [-22°F to 122°F]
- Electrical Connection: Pre-wired cable (1 meter supply/control cable and integrated auxiliary switch cable)
LFH24-SR-S BELIMO Rotary Valve Actuator.
-
REQUEST A QUOTE
- Torque: 5 Nm (Newton meters)
- Power Supply: AC 100…240 V at 50/60 Hz (Nominal range: AC 85…265 V)
- Power Consumption: 2 W when running / 0.5 W in the rest position
- Running Time: 90 seconds for a 90° rotation
- Control Type: Open/close (2-point) or 3-point floating
- Enclosure Rating: IP54 / NEMA 2 (dust and splash protection)
- Connection: Comes with an integrated 1-meter, 3-wire PVC cable
- Overload Protection: The actuator is completely overload protected, eliminating the need for electrical limit switches. It automatically stops spinning once it hits its physical end stops.
- Manual Override: Features a temporary or lockable manual override push-button, which disengages the gear train so you can adjust the valve by hand during setup or testing.
- Simple Direct Mounting: Designed to attach quickly to standard ball valves using just one central screw, preventing improper mechanical alignment.
LR230A 220V BELIMO Rotary Valve Actuator.
