Showing 1–16 of 62 results
-
REQUEST A QUOTE
- Encoder Type: Absolute (retains position data even if power is lost).
- Output Signal: Digital.
- Actuator Design: Solid shaft.
- Sensing Technology: Electromechanical/Mechanical.
- Electrical Design: Direct Current (DC) powered.
- Wiring & Connection: Shielded cable termination to protect against electromagnetic interference.
- Mounting: Compatible with standard industrial surface mounting.
- Country of Origin: Commonly manufactured and distributed out of industrial hubs in China.
62-58HN-8620-G13121-S010 Hein Lanz Absolute Rotary Encoder.
-
REQUEST A QUOTE
- Manufacturer Part Number: 64610805 / 3ABD64610805
- Primary Function: Pulse encoder interface for accurate motor speed/position feedback
- Drive Compatibility: ABB ACS800 series and DCS800 series drives
- Supported Encoder Signals: Differential and single-ended signals
- Supply Voltage Output: Configurable 15 VDC or 24 VDC to power the encoder
- Maximum Frequency: 200 kHz
- Power Consumption: 55 mA from the drive's internal power supply
- Physical Dimensions: 165 mm (H) x 115 mm (L) x 40 mm (W) (Note: Standard card width is approx 40 mm)
- Net Weight: 0.35 kg (0.77 lbs)
- High-Accuracy Control: Essential for demanding applications (like cranes, winders, and heavy positioning equipment) where standard sensorless vector control cannot deliver exact zero-speed torque or precise speed regulation.
ABB RTAC-01 Pulse Encoder Interface Module (ABB Drives).
-
REQUEST A QUOTE
- Encoder Type: Incremental Optical Rotary Encoder
- Housing Diameter: ∅ 40 mm (clamping type body)
- Shaft Diameter: ∅ 6 mm (solid external shaft)
- Resolution: 1000 Pulses Per Revolution (PPR)
- Output Phases: 3-Channel: A, B, and Z (Index phase)
- Control Output Type: NPN Open Collector
- Power Supply Voltage: 12–24V DC ± 5% (ripple P-P: max 5%)
- Starting Torque: Max. 40 gf·cm (Max. 0.00392 N·m)
- Connection Type: Radial Cable Type (2-meter pre-wired cable)
- Protection Structure: IP50 (IEC standard)
AUTONICS E40S6-1000-3-N-24 Rotary Encoder (E40S Series).
-
REQUEST A QUOTE
- Encoder Type: Incremental Rotary Encoder
- Housing Size: Ø40 mm diameter
- Shaft Dimensions: Ø6 mm solid shaft outer diameter
- Resolution: 2000 P/R (Pulses per Revolution)
- Output Phases: 3 Channels: A, B, Z
- Control Output Type: Totem Pole (Push-Pull compatible)
- Power Supply Voltage: 12–24 VDC ±5% (Ripple P-P: max. 5%)
- Starting Torque: Max. 40 gf·cm (0.00392 N·m)
- Connection Mechanism: Radial cable type (Standard length: 2m)
- Ingress Protection Rating: IP50 (Dust protection)
AUTONICS E40S6-2000-3-T-24 Rotary Encoder (E40S Series).
-
- Manufacturer: Autonics
- Model / Part Number: E40S8-200-3-N-24
- Body Diameter: 40 mm
- Shaft Outer Diameter: Ø8 mm
- Resolution: 200 Pulses per Revolution (P/R)
- Output Phases: 3 Channels (A, B, Z)
- Control Output: NPN open collector
- Power Supply Voltage: 12-24VDC ±5%
- Maximum Response Frequency: 300 kHz
- Maximum Allowable Revolution: 5000 rpm
- Starting Torque: Max. 40 gf·cm (Max. 0.00392 N·m)
- Connection Type: Radial cable type
- Protection Rating: IP50
-
- Manufacturer: AUTONICS
- Model / Part Number: E50S8-2048-6-L-5
- Sensing Technology: Optical incremental
- Starting Torque: Max. 70 gf·cm (0.00686 N·m)
- Power Voltage: 5VDC ±5% (Max 5% ripple P-P)
- Connection Type: Axial cable type
- Protection Structure: IP50 (IEC standard)
-
- Manufacturer: AUTONICS
- Model / Part Number: E50S8-300-3-T-24
- Resolution: 300 P/R (Pulses per Revolution)
- Output Phases: 3 channels (A, B, Z)
- Control Output: Totem pole output
- Power Supply Voltage: 12-24VDC ±5% (ripple P-P: max. 5%)
- Shaft Diameter: Ø8 mm
- Diameter of Housing: 50 mm
- Connection Type: Axial cable type
- Starting Torque: Max. 70 gf·cm (Max. 0.00686 N·m)
- Protection Structure: IP50 (IEC standard)
-
- Manufacturer: AUTONICS
- Model / Part Number: E50S8-360-3-T-24
- Series: E50S
- Resolution: 360 pulses per revolution
- Shaft Diameter: 8 mm
- Output: Totem-pole output
- Supply Voltage: 12–24 VDC
-
- Manufacturer: AUTONICS
- Model / Part Number: E50S8-3600-3-T-24
- Resolution: 3,600 Pulses per Revolution (P/R)
- Shaft Diameter: Ø8 mm
- Control Output: Totem pole type
- Output Phases: 3 Phases (A, B, Z)
- Power Supply: 12–24VDC ±5%
- Connection Type: Axial cable type
- Max Rotation: 5,000 RPM
- Max Frequency: 300 kHz
- Ingress Protection: IP50 rating
-
- Manufacturer: AUTONICS
- Model / Part Number: E50S8-600-3-T-24
- Output Type: Totem pole (works with many types of controllers like PLCs)
- Output Phases: A, B, Z (A and B measure speed/direction; Z provides a reference zero-point)
- Max Speed: 5,000 revolutions per minute (RPM)
- Max Frequency: 300 kHz (maximum speed it can send pulses safely)
- Connection Type: Axial cable type (a 2-meter wire comes directly out of the back)
- Weather Protection: IP50 rating (protected against dust, but not waterproof)
-
REQUEST A QUOTE
- Output Type: Totem pole (Push-Pull)
- Supply Voltage: 12–24 VDC ± 5% (ripple P-P: max. 5%)
- Resolution: 1 pulse per 1 mm
- Number of Pulses: 250 pulses per revolution
- Wheel Circumference: 250 mm
- Output Phases: A, B (Allows direction sensing)
- Connection Type: Axial cable type (pre-wired)
- Protection Rating: IP50 (Indoor/Dust-resistant environment)
AUTONICS ENC-1-1-T-24 Wheel-Type Encoder (ENC Series).
-
REQUEST A QUOTE
- Encoder Compatibility: Dual-purpose support for Incremental encoders and SSI (Synchronous Serial Interface) / BiSS-C absolute encoders.
- Physical Connector: 15-pin female D-Sub interface.
- Operating Voltage & Supply: Configurable encoder supply voltage of 5 V (at 250 mA) or 15 V.
- Voltage Drop Compensation: Features an integrated auto-compensation mechanism for 5 V setups to negate transmission losses over long cable distances.
- Signal Monitoring: Actively monitors encoder input signals for failures, ensuring system safety by executing line-break and short-circuit diagnostics.
- Counter Depth & Frequency: 32-bit resolution tracking with an operating limit up to 200 kHz.
- Physical Metrics: Ultra-compact footprint weighing approximately 0.08 kg – 0.1 kg with an IP20 protection enclosure rating once securely slotted.
- Standout Feature: Available in brand-new factory condition.
B&R 8AC123.60-1 Encoder Interface Module (ACOPOS).
-
- Manufacturer: BECKHOFF
- Model / Part Number: EL5042
- Encoder Channels: 2
- Encoder Interface: BiSS-C
- Bus System: EtherCAT E-bus
- Mounting: DIN rail terminal assembly
-
- Manufacturer: FANUC
- Model / Part Number: A860-0309-T302
- Resolution: 1,024 Pulses/Rev (Quadrature Encoder)
- Maximum Speed: 10,000 RPM
- Mounting Type: 68mm Square Flange (50mm center alignment)
- Connection: Integrated 17-pin electrical connector
- Operating Temperature: 0 to 60°C (32 to 140°F)
- Humidity Limits: Up to 80% non-condensing relative humidity
- Weight: Approximately 1.15 lbs (0.6 kg)
-
- Manufacturer: FANUC
- Model / Part Number: A860-2000-T301
- Series Designation: α iA1000 (α1000iA) series.
- Resolution: 1,000,000 divisions per single motor revolution for extreme cutting accuracy.
- Mechanical Interface: Built with an Oldham-type coupling to help handle tiny shaft misalignments.
- Electrical Connection: A keyed 10-pin circular connector (receptacle model JN2AS10UL1-R).
- Position Backup: Uses a built-in capacitor that holds the memory for about 10 minutes. This gives you time to change the main system batteries without losing your position data.
- Environmental Protection: Rated at IP65 to shield internal electronics from heavy workshop dust and liquids.
-
REQUEST A QUOTE
- Manufacturer: FANUC
- Model / Part Number: A860-2005-T301
- Encoder Type: Incremental pulse coder, αiI1000
- Speed Range: 3,000–6,000 rpm
- Electrical Rating: 24 V DC
FANUC A860-2005-T301 Rotary Encoder. Contact us for product information and quotation.
