- IGBT Technology Type: Trench Gate
- Package / Mounting: Screw-mount, structurally isolated copper baseplate
- Industrial Motor Drives: Used for speed and torque regulation in AC servo controls and heavy industrial machinery.
- Uninterruptible Power Supplies (UPS): Serves in the inverter or rectifier conversion stages.
- General Purpose Inverters: Implemented in renewable energy power networks (e.g., solar inverters, wind turbines).
- High-Power DC-DC Converters: Integrated into large-scale battery storage and battery-powered supply networks.
- Status: This module is officially classified as Obsolete / End-of-Life (EOL) by the manufacturers.
- Datasheets: View and download the official multi-page documents on the Alldatasheet Portal or check structural definitions via the Ineltron Data Repository.
MITSUBISHI CM200DU-24F IGBT Module (CM200).
-
REQUEST A QUOTE
- Configuration: Dual (Half-Bridge)
- Integrated Protection: Freewheeling Diodes
- Motor Drives: Used to orchestrate AC and DC motor control, as well as servo amplifiers.
- Power Converters: Frequently integrated into large industrial inverters, Uninterruptible Power Supplies (UPS), and induction heating rigs.
- Renewable Energy: Acts as a stage-power switching element for commercial solar inverters and wind turbine networks.
- DIY & High Voltage Projects: Highly favored in the hobbyist community for constructing heavy-duty Dual Resonant Solid State Tesla Coils (DRSSTC), notably running off a doubled 120VAC line to achieve electric arc discharges spanning over 6 feet (1.83 meters).
- Datasheet Review: The official structural schematic and thermal curves can be cross-examined via the ALLDATASHEET CM300DY-12NF PDF.
MITSUBISHI CM300DY-12NF IGBT Module (CM300).
-
REQUEST A QUOTE
- Collector-Emitter Saturation: 3.2 V
- Package / Mounting: 7 Terminals, Chassis Mount
- Industrial Power Systems: Uninterruptible Power Supplies (UPS inverter/rectifier stages), AC motor speed controls, motion/servo controls, and heavy-duty welding power supplies.
- High-Voltage DIY & Tesla Coils: This module is widely considered a gold standard among hobbyists for building medium-to-high power DRSSTC (Dual Resonant Solid State Tesla Coils). Two modules paired in a full-bridge configuration can manage an output swing of nearly 1400V, producing electrical arcs exceeding 12 feet.
- Discontinued Status: The CM300DY-24H has been officially discontinued by Mitsubishi Electric.
MITSUBISHI CM300DY-24H IGBT Module (CM300).
-
REQUEST A QUOTE
- Configuration: Dual / Half-Bridge (2 elements)
- Technology Generation: IGBT 5 (Trench Gate)
- Mounting / Terminals: Panel (Screw) / 7-Pin Tab
- Isolated Baseplate: All internal components and electrical interconnects are fully isolated from the copper heat-sinking baseplate. This provides simplified thermal management, letting you mount multiple modules to a single common heatsink without external electrical isolation.
- Discrete Free-Wheel Diode: Features integrated, super-fast recovery reverse diodes designed to handle high freewheeling currents and protect the IGBT structure from inductive voltage spikes.
- AC Motor Control: Variable frequency drives (VFDs) and high-power industrial AC drive inverters.
- Servo Controls: Precision motion control systems requiring heavy current handling.
- Uninterruptible Power Supplies (UPS): High-reliability backup power systems.
- Power Management: Battery-powered industrial supplies, solar inverters, and large DC-to-DC converters.
MITSUBISHI CM400DY-24A IGBT Module (CM400).
-
REQUEST A QUOTE
- Configuration: Dual (Half-Bridge)
- Primary Uses: Optimized for general-purpose industrial inverters, AC motor drives, and high-precision servo controls.
- Integrated Diodes: Contains two IGBT transistors connected in a half-bridge layout, each supported by an ultra-fast recovery reverse freewheeling diode.
- Package Footprint: Chassis mount module configuration utilizing a standard multi-terminal layout with M6 nuts for structural power termination.
MITSUBISHI CM400DY-24NF IGBT Module (CM400).
-
REQUEST A QUOTE
- Configuration: Single IGBT with discrete Free-Wheel Diode
- Weight: 270 g / ~0.6 lbs
- Isolated Baseplate: All internal components and electrical interconnects are fully isolated from the copper heatsink baseplate
- Integrated Free-Wheel Diode: Features a dedicated, super-fast recovery diode connected anti-parallel to handle inductive load current
MITSUBISHI CM450HA-5F IGBT Module (CM450).
-
REQUEST A QUOTE
- Configuration: 1-Element (Single) Packaged as a single switch per module
- Mounting Type: Chassis Mount Heavy-duty bolt-down installation
- Uninterruptible Power Supplies (UPS): Frequently integrated to scale up energy capacity and reinforce industrial backup systems.
- DC Choppers & Converters: Managing voltage transitions in large industrial power feeds.
- Welding Equipment & Power Supplies: Regulating high-current demands safely.
- Datasheets: You can view complete pin configurations and timing diagrams on the Alldatasheet Technical Archive.
MITSUBISHI CM600HU-24F Single-Element IGBT Module (F-Series).
-
- Brand: Mitsubishi Electric
- Model: MR-TB50
- Series: MELSERVO
- Terminal count: 50 pins
- Purpose: Junction terminal block for servo control signals
- Compatible amplifier family: MR-JE-A
- Terminal screw size: M3.5
- Maximum applicable wire: 2 mm²
- Maximum crimp terminal width: 7.2 mm
- Mounting screw size: M4
- Overall length: Approximately 244 mm
- Body height: Approximately 50 mm
- Depth: Approximately 46.5 mm
-
- Manufacturer: Mitsubishi
- Model / Part Number: FR-A8NS
- High-Speed Motion Integration: Connects the FR-A800 drive as an extension of a motion controller system, allowing highly synchronized speed and position pulse configurations.
- Position Control Support: Features like position droop pulse clearing (CLRN) can be processed through the network via the host system depending on parameter programming.
- Reduced Wiring: Replaces complex traditional analog/digital control wiring with a single fiber-optic SSCNET cable, minimizing electrical noise interference.
-
REQUEST A QUOTE
- Model / Series: FR-CS82S-025-60 (FREQROL-CS80 Series)
- Input Power Source: Single-Phase 200 to 240 V AC (± 10%), 50/60Hz
- Rated Motor Capacity: 0.4 kW (approx. 0.5 Horsepower)
- Rated Output Current: 2.5 A
- Output Frequency Range: 0.2 to 400 Hz
- Control System: Soft-PWM, General-purpose magnetic flux vector control, or V/F control
- Enclosure Rating: IP20 (Open Type)
- Circuit Board Coating: Type "60" (Indicates conformal coating for improved environmental resistance)
- FR: FREQROL Inverter Series
- Kempston Controls US: Available as a standard stock item for domestic industrial fulfillment.
MITSUBISHI FR-CS82S-025-60 Variable Frequency Drive (FREQROL-CS80).
-
REQUEST A QUOTE
- Model Number: FR-D720S-0.75K-CHT
- Applicable Motor Capacity: 0.75 kW (1.0 HP)
- Input Power: 1-Phase 200–240V AC (±10%)
- Output Voltage: 3-Phase 200–240V AC
- Rated Output Current: 4.2 Amperes
- Output Frequency Range: 0.2 to 400 Hz
- Control System: V/F Control
- Communication Protocol: RS-485 (Modbus-RTU)
- Enclosure Rating: IP20
- Safety Integration: STO (Safe Torque Off)
MITSUBISHI FR-D720S-0.75K-CHT Variable Frequency Drive (FREQROL-D700).
-
- Manufacturer: Mitsubishi
- Model / Part Number: FR-E740-5.5K-CHT
- Input Power: Three-phase AC, 380V to 480V at 50/60Hz.
- Output Power: Three-phase AC corresponding to input voltage, with a rated capacity of 9.1 kVA.
- Smart Motor Control: Uses advanced magnetic flux vector control.
- Built-in Dial: Includes a physical control wheel on the front panel. You can use this to quickly change motor speeds or modify settings right on the machine.
- Expandable: Features a built-in USB port for computer setup and a slot to insert option cards for specialized industrial networks (like CC-Link).
-
REQUEST A QUOTE
- Series: FREQROL-E800
- Voltage Class: 200V Class (Three-Phase)
- Rated Capacity: 18.5 kW (~25 Horsepower)
- Ethernet: Standard / Base Model
- Monitor Output: FM Type Terminal
- Enclosure Rating: IP20
- Material Handling: Conveyors, sorting lines, and overhead cranes.
- HVAC Systems: High-capacity industrial fans, blowers, and commercial water pumps.
- Packaging & Textiles: Winders, tension-control machinery, and high-speed packaging lines.
- Food Processing: Industrial mixers, grinders, and automated bottling lines.
MITSUBISHI FR-E820-18.5K-1 Variable Frequency Drive (FREQROL-E800).
-
- Manufacturer: Mitsubishi
- Model / Part Number: FR-S520SE-0.75k-KC
- Series: FR-S500 (Specifically S520E sub-series) Compact, transistorized micro-inverter
- Motor Capacity: 0.75 kW (Equivalent to 1 Horsepower / 1 HP) Maximum applicable motor capacity
- Input Power Supply: Single-Phase 200V to 240V AC 50/60Hz frequency tolerance
- Output Power: Three-Phase 200V to 240V AC Converts single-phase input to three-phase output
- Control Platform: RS-485 Serial Communication Integrated digital dial setting and display
- Input Power Terminals: Marked as L1 and N for the single-phase power line connections.
- Output Terminals: Marked as U, V, and W to connect directly to the three-phase motor.
- Ground: Dedicated PE (Earth) terminal to prevent electrical shock.
- Control Interface: Features a built-in RS-485 port for connecting parameter units like the FR-PU04 or network systems.
- Integrated Protection: Built-in electronic thermal overcurrent protection safeguards your motor from overheating.
- Constant-Torque Tuning: Can be configured via parameter settings (Pr. 71 and Pr. 9) to provide 100% continuous torque even at low operational speeds.
- User-Friendly Interface: Uses a digital setting dial making parameter setup and adjustments incredibly quick.
-
REQUEST A QUOTE
- Specification Attribute: Details & Metrics
- Manufacturer: Mitsubishi Electric (MELSEC-F Series)
- Total Built-in I/O: 48 Points (Expandable up to 256 I/O points locally)
- Digital Inputs: 24 Inputs (24V DC, Sink/Source flexible configuration)
- Digital Outputs: 24 Relay Outputs (Normally Open contacts)
- Rated Voltage / Supply: 24V DC (Allowable supply range: 16.8V to 28.8V DC)
- Output Capacity: 2A per point (240V AC or 30V DC max)
- Program Memory: 64,000 Steps (Internal RAM, expandable via optional cassette)
- Execution Speed: High-speed processing (0.065 μs per basic instruction)
- On-board Comms: Integrated RS-422 port; expandable via specialized function boards
MITSUBISHI FX3U-48MR-DS PLC (MELSEC-F FX3U).
-
- Manufacturer: MITSUBISHI
- Model / Part Number: HC-KFS73B
- Rated Output Capacity: 750 W (0.75 kW)
- Supply Voltage Class: 200 VAC class
- Rated Current: 5.8 A (Maximum current: 18.6 A)
- Rated Rotational Speed: 3000 RPM
- Maximum Speed: 4500 RPM
- Rated Torque: 2.4 Nm nominal
- Maximum Torque: 7.2 Nm peak
- Moment of Inertia: 0.0001635 kg·m² (1.635 kg·cm²)
- Feedback Encoder: 17-bit absolute feedback encoder (131,072 p/rev)
- Shaft Design: Standard straight shaft
- Electromagnetic Brake: Built-in / Installed
- Flange Size: 80mm x 80mm mounting
- Dimensions: H 98.1mm x W 82mm x D 217.5mm
- Ingress Protection: IP55 rated (excluding the shaft portion and connector)
- Operating Temperature: 0°C to +40°C ambient
- Storage Temperature: -15°C to +70°C
- Approximate Weight: 2.5 kg to 3.0 kg
- HC-KFS: Low inertia, small capacity series
