Showing 769–784 of 2131 results
-
- Brand: Danfoss
- Model: 067B3210
- Series: TEX 12
- Product type: Thermostatic element for expansion valve
- Series: TEX 12
- Refrigerants: R22 / R407C
- Temperature range: -40 to +10 °C
- Pressure equalization: External
- Equalization connection: 1/4 in flare
- Capillary tube length: 3,000 mm (118 in)
- Maximum working pressure: 28 bar (400 psig)
- Body material: Brass
- Net weight: 0.533 kg
- EAN / UPC: 5702428149228
-
REQUEST A QUOTE
- Manufacturer: DANFOSS
- Model / Part Number: 067B3211
- Specification Field: Technical Data
- Product Type / Series: TEX 12 Thermostatic Element (TE 5 – TE 55 parts program)
- Compatible Refrigerants: R22 / R407C
- Pressure Equalization: Externally equalized via a 1/4-inch Flare connection
- Capillary Tube Length: 118 inches (3,000 mm)
- Maximum Working Pressure: 400 psig (28 bar)
- MOP (Max Operating Pressure): MOP 20 (-5°F / -20°C)
- Temperature Range: -60°C to -25°C (-75°F to -15°F)
- Body Material: Brass (laser welded for an extended lifetime)
- Modular Component: This is an element (power head) only, part of Danfoss's interchangeable parts program. It must be paired with a compatible TE 12 valve body and the appropriate orifice size to construct a complete operational expansion valve.
- External Equalization: The external equalizer line senses pressure directly at the evaporator outlet, neutralizing the effect of any pressure drops across the evaporator coils for far more accurate superheat control.
-
REQUEST A QUOTE
- Manufacturer: DANFOSS
- Model / Part Number: 067B3227
- Compatible Refrigerants: Engineered specifically for R22 and R407C systems.
- Temperature Operating Range: Measures from -40°C to 10°C (-40°F to 50°F).
- Pressure Equalization: Externally equalized via a 1/4-inch flare connection.
- Capillary Tube Length: Features a 3000 mm (3-meter / ~118 inches) capillary line attached to a brass body.
- Charge Type: Range N with a Maximum Operating Pressure (MOP) charge of +15°C.
-
REQUEST A QUOTE
- Manufacturer: DANFOSS
- Model / Part Number: 067B3232
- Refrigerant Type: R134a
- Temperature Range: -40°C to 10°C (-40°F to 50°F)
- Capillary Tube Length: 118 inches (3,000 mm)
- Pressure Equalization: Externally equalized
- Equalization Connection: 1/4-inch Flare connection
- Maximum Working Pressure: 400 psig (28 bar)
- Parts Program Series: TE 12
- Body Material: Brass
- Condition: Brand new.
- Policy: 30-day return window.
-
REQUEST A QUOTE
- Manufacturer: DANFOSS
- Model / Part Number: 067B3250
- Compatible Refrigerants: Optimized for R22 and R407C systems.
- Temperature Regulation: Operates on the standard Range N envelope, spanning -40°C to +10°C (-40°F to +50°F).
- Capillary Tube Length: Includes a 118-inch (3,000 mm) laser-welded stainless steel capillary tube.
- Equalization Connection: Features a 1/4-inch Flare external equalization connection to compensate for system pressure drops.
- Maximum Working Pressure (MWP): Rated for 28 bar (400 psig).
- Body Material: Durable brass valve base alignment with laser-welded element structure.
-
- Manufacturer: Danfoss
- Model / Part Number: 067B3267
- Refrigerants: Designed for R22 and R407C systems.
- Valve Type: Part of the TE 5 parts program.
- Temperature Range: Functions across a range of -40°C to 10°C (-40°F to 50°F).
- MOP (Maximum Operating Pressure): Features a MOP 100 point at 15°C (60°F) to protect the compressor motor against excessive suction pressure.
- Pressure Equalization: Uses an external flare connection measuring 1/4 inch.
- Capillary Tube Length: Measures 118 inches (3.0 meters).
-
- Manufacturer: DANFOSS
- Model / Part Number: 067B3278
- Device Type: TE 5 Series Thermostatic Element
- Compatible Refrigerant: R407C
- Temperature Range: -40°F to +50°F (-40°C to +10°C) — "N" Range
- Pressure Equalization: External (1/4 inch Flare connection)
- Maximum Working Pressure (MWP): 400 psig (28 bar)
- Capillary Tube Length: 118 inches (3,000 mm)
- Body Material: Brass
- Element Material: Laser-welded stainless steel
-
- Manufacturer: DANFOSS
- Model / Part Number: 067B3303
- Product Type: Thermostatic Power Element
- Valve Series: PHT Series
- Compatible Refrigerants: R22, R407C
- Temperature Range (Range N): -40°C to +10°C (-40°F to +50°F)
- Capillary Tube Length: 3000 mm (118 inches)
- Equalization Connection: Flare type (External equalization)
- Body Material: Brass
- Net Weight: 0.46 kg (1.01 lbs)
- EAN / Barcode: 5702428034562
-
- Manufacturer: DANFOSS
- Model / Part Number: 067B3343
- Compatible Valve Series: TE 5
- Supported Refrigerants: R404A and R507A
- Temperature Range: -75°F to -15°F (-60°C to -25°C)
- MOP Point (Maximum Operating Pressure): -5°F (-20°C) / MOP 30
- Pressure Equalization: External (1/4-inch Flare connection)
- Capillary Tube Length: 118 inches (3,000 mm)
- Maximum Working Pressure: 400 psig (28 bar)
- Body Material: Brass
- Net Weight: 0.97 lbs (0.44 kg)
-
- Manufacturer: DANFOSS
- Model / Part Number: 067B3344
- Valve Series: TE 5 / TES 5
- Compatible Refrigerants: R404A and R507A
- Temperature Range: -60°C to -25°C (-75°F to -15°F)
- Pressure Equalization: External equalization with a 1/4-inch flare connection
- Capillary Tube Length: 3,000 mm (about 118 inches or 9.8 feet)
- Maximum Working Pressure: 28 bar (400 psig)
- Body Material: Brass
- MOP (Maximum Operating Pressure): This specific model does not feature MOP.
-
- Manufacturer: DANFOSS
- Model / Part Number: 067B3345
- Product Type: TE 12 Thermostatic Element
- Compatible Refrigerants: R404A and R507A
- Temperature Range: -40°C to -5°C (-40°F to 25°F)
- MOP Point: 0°C (32°F) at MOP 70
- Maximum Working Pressure: 28.0 bar (400 psig)
- Pressure Equalization: External equalization via a 1/4-inch Flare connection
- Capillary Tube Length: 3,000 mm (118 inches)
- Body Material: Brass
- Net Weight: 0.529 kg (1.17 lbs)
- MOP Function: Built-in Maximum Operating Pressure (MOP) protection at 0°C. This protects the compressor motor against overload during system startup.
- Laser Welded Element: The power element is constructed using advanced laser welding technology. This gives the metal a longer lifetime and better strength under pressure.
- Parts Program: This is a separate piece of a modular system. You can mix and match this element with various Danfoss valve bodies and orifice sizes to fit your specific cooling setup.
-
- Manufacturer: DANFOSS
- Model / Part Number: 067B3347
- Model Series: TE 12 (specifically the TES 12 configuration)
- Compatible Refrigerants: R404A and R507A
- Pressure Equalization: Externally equalized with a 1/4-inch flare connection type
- Capillary Tube Length: 118 inches (3,000 mm)
- Temperature Range: -40°F to 50°F (-40°C to 10°C)
- Maximum Working Pressure: 400 psig (28 bar)
- Body Material: Brass
-
- Manufacturer: Danfoss
- Model / Part Number: 067G4001
- Compatible Models: Designed for TE 55 and TQ 55 expansion valve series.
- Flow Direction: Straightway (passage), meaning the fluid flows in a straight line through the body.
- Inlet Connection: 28 mm Solder / ODF (Outside Diameter Female) connection.
- Outlet Connection: 35 mm Solder / ODF connection.
- Material & Weight: Typically constructed of durable, corrosion-resistant brass/metal, weighing approximately 0.66 kg (1.46 lbs).
-
REQUEST A QUOTE
- Manufacturer: DANFOSS
- Model / Part Number: 067N2165
- Refrigerants: R22 and R407C
- Temperature Range: -40 to 10 °C
- Inlet Connection: 7/8-inch solder ODF
- Outlet Connection: 1-3/8-inch solder ODF
- Pressure Equalization: External, 1/4-inch connection
- Flow Configuration: Bi-flow, straightway body
- Maximum Working Pressure: 49 bar
- Capillary Tube Length: 3000 mm
- Body Material: Brass with copper connections
DANFOSS 067N2165 is an externally equalized thermostatic expansion valve for R22 and R407C refrigeration systems. It has solder ODF connections and a bi-flow configuration.
-
REQUEST A QUOTE
- Model Designation: TGEL 6.5
- Compatible Refrigerants: Engineered specifically for R-410A and R-32.
- Capacity: Rated at 5.5 to 6.5 Tons / 24 kW.
- Inlet: 1/2 inch Solder, ODF
- Outlet: 5/8 inch Solder, ODF
- Equalization Line: 1/4 inch Solder, ODF (External equalization)
- Capillary Tube Length: 59 inches (1500 mm)
- Flow Design: Bi-flow capability with balanced port design to ensure stable performance under varying head pressures.
- Body & Material: Brass body with copper solder connections and a laser-welded stainless steel power element.
- Maximum Working Pressure: 46 Bar (667 Psig)
DANFOSS 067N3153 Thermostatic Expansion Valve (TGE Series).
-
REQUEST A QUOTE
- Manufacturer: DANFOSS
- Model / Part Number: 067N4154
- Refrigerant Compatibility: Specifically designed for R407C systems.
- Cooling Capacity: 19 kW / 5 Tons (Tonnage Capacity).
- Connection Configuration: 1/2 inch x 7/8 inch ODF solder / welding connection.
- Equalization: Externally equalized via a 1/4 inch solder ODF connection.
- Capillary Tube Length: 59 inches (1500 mm).
- Flow Design: Bi-flow operation capability.
- MOP (Maximum Operating Pressure): Designed without MOP protection.
DANFOSS 067N4154: Refrigerant Compatibility Specifically designed for R407C systems.; Cooling Capacity 19 kW / 5 Tons (Tonnage Capacity).; Connection Configuration 1/2 inch x 7/8 inch ODF solder / welding connection.; Equalization Externally equalized via a 1/4 inch solder ODF connection..
