Showing 753–768 of 2131 results
-
REQUEST A QUOTE
- Manufacturer: DAIKIN
- Model / Part Number: KFD-280-33-8B
- Motor Type: BLDC variable-frequency fan motor
- Rated Power: 33 W
- DC Voltage Range: 280–380 V DC
- Speed Range: 300–1,500 rpm
- Nominal Speed: 1,000 rpm
DAIKIN KFD-280-33-8B BLDC Fan Motor. Contact us for product information and quotation.
-
- Manufacturer: DAIKIN
- Model / Part Number: KFD-280-40-8B
- Voltage: DC 280V
- Rated Power: 40W
- Rotational Speed: 1640 r/min
- Motor Type: Brushless DC Motor (BLDC)
-
REQUEST A QUOTE
- Motor Type: Brushless DC (Variable Frequency) Outdoor Fan Motor
- Output Power: 66 W
- Operating Voltage: 280 V
- Pole Count: 8-Pole (-8A designation)
- Application: Condenser heat dissipation (Outdoor Unit)
- Daikin Genuine Spare Part ID: 2072018 or 4015260
- Alternative / Superseded Codes: Replaces older part number 1708648. An updated variant is also listed under 4015261.
- Red to Blue: Should read > 100 kΩ (If you see open loop or zero, reverse your meter leads; red probe on blue wire, black probe on red wire).
- Brown to Blue: Should read roughly > 100 Ω up to ~1.2 kΩ.
- White to Blue: Internal Vcc line, should read very high (> 1 MΩ).
DAIKIN KFD-280-66-8A DC Outdoor Fan Motor (KFD Series).
-
REQUEST A QUOTE
- Manufacturer: DAIKIN
- Model / Part Number: KFD-280-74-8A
- Model Number: KFD-280-74-8A
- Operating Voltage: 280V DC (DC280V)
- Power Output: 74 Watts (74W)
- Number of Poles: 8 Poles (8P)
- Motor Type: Brushless DC Motor (BLDC) / Inverter Variable Speed
- Application: Outdoor Condenser Cooling Fan (Commercial and Residential HVAC units)
- Variable Speed Control: Works directly with the Daikin inverter control module to dynamically adjust fan rotation based on cooling demand, improving energy efficiency.
- Low Noise: Utilizes brushless DC technology to minimize operational vibration and noise.
- Product Summary: 1Pcs KFD-280-74-8A DC Outdoor Fan Motor,Compatible For Daikin,Air Conditioner Spare Parts * Drive fan blade rotat…
-
REQUEST A QUOTE
- Manufacturer: DAIKIN
- Model / Part Number: KFD-325-70-8A2
- Power Output: 70W
- Operating Voltage: 325V DC
- Rotational Speed: 850 RPM
- Motor Poles: 8P (8-Pole)
- Substitutes & Alternates: Often interchanges with part numbers 148557J, 2480811, 2551189, and 4015250.
- Heat Pumps: EBLQ-C, EDLQ-C, ERRQ-A, ERSQ-A, and RRLQ011-016CAW1 series.
- Air Conditioners / VRV Multi-Split: RXYSQ-T, RMXS160CMV2C, 4MKD100DVM, and RR140MY1 outdoor units.
-
REQUEST A QUOTE
- Manufacturer: DAIKIN
- Model / Part Number: KFD-325-70-8C2
- Part Numbers: 5017652 (Primary), 5016324, 2538407, or 168668 (older substituted part)
- Input Voltage: DC 325V
- Power Output: 70 Watts
- Motor Poles: 8 Poles (8P)
- Rated Speed: 850 RPM
- Interchangeability: It is physically and functionally identical to the KFD-325-70-8A model, except the 8C2 variant includes a wire cable that is roughly 200mm longer, making it highly versatile for replacements.
- Daikin VRV / Multi-Split Series: RXYSQ models (including RXYSQ4TAV1B, RXYSQ5TAV1B, RXYSQ6TAV1B).
- Commercial Outdoor Inverters: RMXS140DV2C, RMXS160DV2, and RZQS100D7V1B.
- Isolate Power: Completely turn off the electrical mains to the outdoor unit.
- Disconnect the Plug: Locate the motor's control plug on the main PCB board. Release the safety prongs to pull the wiring harness out.
- Identify Wire Configuration: The plug features a multi-pin block containing a Red wire, a gap space, and then Blue, Brown, Orange, and White wires.
- Test Resistance Points: Measure the resistance between the following colors:
- Red to Blue: Should read high impedance (over 100 kΩ). If it reads open or shows no value, swap your multimeter prongs around to check the diode bias.
- Brown to Blue: Typically measures around 1,200 Ω (over 100 Ω).
- White to Blue: Typically measures in the megaohm scale (over 1 MΩ).
-
REQUEST A QUOTE
- Manufacturer: Daikin
- Daikin Part Numbers: 4015276, 5013791
- Alternative/Successor Part: KFD-380-50-8F (Part #5020670)
- Motor Type: Brushless DC (BLDC)
- Voltage Rating: DC 230V to DC 380V
- Power Output: 53 Watts (sometimes listed as 50W)
- Speed (RPM): 800 RPM
- Poles: 8-Pole (8P)
- Direction of Rotation: Clockwise (CW)
- Safety Certifications: CE, RoHS compliant
DAIKIN KFD-380-50-8C Brushless DC Fan Motor (KFD Series).
-
REQUEST A QUOTE
- Manufacturer: Daikin Industries
- Model Number: KFD-380-53-8B1
- Motor Type: Brushless DC Motor (BLDC) / Inverter Fan Motor
- Operating Voltage: 380V DC (DC380V)
- Output Power: 53 Watts (53W)
- Poles: 8-Pole (8P)
- Common Applications: 2 to 3 HP cabinet/ducted units, and outdoor condensing unit models (such as the RXD50CMVMC series).
- High Voltage Hazard: This motor operates on 380 Volts DC. DC voltages at this level hold dangerous electrical energy. Always disconnect the primary circuit breaker and verify that internal capacitors have completely discharged using a digital multimeter before touching any wires.
- Verify Part Revisions: Ensure your old motor matches the KFD-380-53-8B1 model precisely. Minor variations in the trailing characters (e.g., 8B vs 8B1 vs 8C1) can signify differences in wiring harness lengths, mounting bolt brackets, or communication protocols required by the main PCB board.
- Higher energy efficiency: Air conditioning DC motors are more energy-efficient than traditional AC motors, which can provide bette…
DAIKIN KFD-380-53-8B1 BLDC Outdoor Fan Motor (KFD Series).
-
- Manufacturer: DAIKIN
- Model / Part Number: ZKFN-34-10-1
- Voltage: DC 310V
- Rated Power: 34 Watts
- Current: 0.16 Amps
- Rotational Speed: 1000 RPM (Rotations Per Minute)
- Shaft Diameter: 8 mm
- Rotation Direction: Counterclockwise (CCW) or Clockwise (CW) depending on the exact variant sub-code. (Note: Check your old motor's arrow to be sure).
-
REQUEST A QUOTE
- Product Type / Series: KP1 Pressure Switch
- Reset Function: Automatic (Auto)
- Contact Type: Single-Pole Double-Throw (SPDT)
- Pressure Connection: 1/4 in Flare Male
- Enclosure Rating: IP44 (with top cover and backplate mounted)
- Ambient Temperature Range: -25°C to 65°C (-13°F to 149°F)
- Net Weight: 0.300 kg (0.66 lbs)
- Snap-Action Contact System: Utilizes an internal omega spring system that keeps electrical contacts firmly closed until the precise cut-in or cut-out threshold is hit. This ultra-short bounce time (10 to 15 microseconds) eliminates contact chatter and significantly extends electrical lifecycle.
- Vibration and Shock Resistance: Built to handle harsh environments, maintaining structural and operational stability through vibrations scaling from 20 to 1000 Hz.
- Refrigerant Compatibility: Approved for use with conventional fluorinated hydrocarbons and various modern low-GWP alternatives, including R134a, R22, R404A, R407A/C/F, R448A, R449A, R507A, R513A, and more.
DANFOSS 060-110191 Low-Pressure Switch (KP1 Series).
-
- Brand: Danfoss
- Model: 060G1036
- Series: AKS 32R
- Pressure range: -1 to 12 bar, sealed gauge
- Permissible working pressure: 33 bar
- Pressure connection: 1/4-inch flare, 7/16-20 UNF
- Electrical connector: DIN plug, 4 pins
- Supply voltage: 4.75–8 V DC
- Output signal: 10–90% of supply voltage; 0.5–4.5 V at 5 V supply
- Current consumption: Less than 5 mA at 5 V
- Response time: Less than 4 ms
- Accuracy: ±0.3% FS typical; ±0.8% FS maximum
- Compensated temperature: -30 to +40 °C
- Ambient temperature: -40 to +85 °C
- Protection: IP65 with mating connector
- Wetted material: Stainless steel 316L
-
REQUEST A QUOTE
- Manufacturer: DANFOSS
- Model / Part Number: 060G1151
- Series: MBS 3050
- Specification Key: MBS 3050-3031-A1FB04-4
- Pressure Range: 0 to 100 bar
- Pressure Reference: Sealed gauge
- Output Signal: 4 to 20 mA
- Pressure Connection: G 1/4 A (DIN 3852)
- Electrical Connection: Angular DIN plug, Pg 9
- Operating Temperature: -40 to 85 °C
- Accuracy: ±0.5% FS typical; ±1.0% FS maximum
- Pressure Damping: Integrated pulse snubber
DANFOSS 060G1151 is an MBS 3050 pressure transmitter with a 0 to 100 bar sealed-gauge range and a 4 to 20 mA output. It includes a pulse snubber and a G 1/4 A pressure connection.
-
REQUEST A QUOTE
- Manufacturer: DANFOSS
- Model / Part Number: 060G1368
- Specification Key: MBS 3300-1811-A6AB04-0
- Pressure Range: 0.00 to 6.00 bar (0 to 87.02 psi)
- Pressure Reference: Gauge / Relative
- Output Signal: Current loop, 4 – 20 mA
- Pressure Connection Size & Type: 1/4-inch G thread
- Electrical Connection: Angular connector (EN 175301-803-A, Pg 11 size)
- Enclosure Rating: IP65 protection against dust and water jets
- Operating Medium Temperature: -40°C to 125°C (-40°F to 257°F)
DANFOSS 060G1368: Specification Key MBS 3300-1811-A6AB04-0; Pressure Range 0.00 to 6.00 bar (0 to 87.02 psi); Pressure Reference Gauge / Relative; Output Signal Current loop, 4 – 20 mA.
-
REQUEST A QUOTE
- Manufacturer: Danfoss, Inc.
- Part Number / Code: 060L310466
- Product Series / Type: KPS 79
- Temperature Range: 50°C to 100°C (122°F to 212°F) (Note: The KPS79 type configuration is optimized for this range, though the broader series handles -10°C to +200°C)
- Output Configuration: SPDT (Single Pole Double Throw)
- Contact System: Gold-plated contacts (ensures high reliability in low-current application environments)
- Enclosure Rating: IP67 (Dust-tight and water-immersion resistant; sea-water proof)
- Electrical Connection: PG 13.5 cable entry
- Differential Type: Adjustable or fixed (depending on exact sub-setup calibration)
- Marine & Offshore Applications: Boiler rooms, engine monitoring, and cooling water systems on board vessels (holds all relevant marine approvals).
DANFOSS 060L310466 Temperature Switch (KPS79 Series).
-
REQUEST A QUOTE
- Series: MBS 5150
- Specification Key: MBS 5150-2011-A6DB04-4
- Pressure Range: 0 to 10 bar
- Pressure Reference: Gauge / relative
- Output Signal: 4 to 20 mA
- Supply Voltage: 10 to 32 VDC
- Pressure Connection: G 1/4 female with flange
- Electrical Connection: DIN 43650-A angular connector, Pg 11
- Medium Temperature: -40 to 85 °C
DANFOSS 060N1064 is an MBS 5150 pressure transmitter with a 0 to 10 bar gauge pressure range and a 4 to 20 mA output.
-
REQUEST A QUOTE
- Model Type: MBC 5100 (Specifically MBC 5100-3641-2CB04)
- Regulation Range: 5 to 40 bar (0.5 to 4 MPa)
- Burst Pressure: 300 bar
- Differential (Min/Max Setting): 2 bar at min range / 7 bar at max range
- Pressure Connection: G 1/4 Female
- Contact Function: SPDT (Single Pole Double Throw)
- Electrical Rating: AC15: 0.5 A, 250 V
- Electrical Connection: DIN-plug (EN 175301-803-A), M20 size
- Enclosure Rating: IP65 (Dust-tight and protected against water jets)
- Ambient Temperature Range: -10°C to 85°C (14°F to 185°F)
DANFOSS 061B110766 Block-Design Pressure Switch (MBC 5100 Series).
