Showing 225–240 of 2013 results
-
- Manufacturer: Allen-Bradley
- Model / Part Number: 25B-V4P8N104
- Input Rating: 100–120V AC, 1-Phase, 50/60 Hz
- Output Rating: 0–230V AC, 3-Phase, 4.8 Amps
- Physical Frame: Frame B Size, IP20 NEMA / Open Type enclosure, Panel Mount
- Control Modes: Volts per Hertz (V/Hz), Sensorless Vector Control, Closed Loop Velocity Vector, and Permanent Magnet Motor Control
- Embedded Communication: Features built-in EtherNet/IP and RS485 communication ports for seamless network integration.
- Hardware Inclusions: Includes an embedded Human Interface Module (HIM) keypad/display and an internal brake IGBT (transistor).
-
- Manufacturer: ALLEN-BRADLEY
- Model / Part Number: 2711P-T10C21D8S
- Display Size: 10.4 inches
- Display Type: Color TFT touch screen
- Resolution: 800 x 600 pixels
- Supply Voltage: 24 VDC
- Network Interface: Ethernet
- Front Protection: IP65
-
REQUEST A QUOTE
- Feature / Attribute: Specification Details
- Product Line: PanelView Plus 7 Standard (1000 Series)
- Display Size & Type: 10.4-inch TFT Color LCD (4:3 Aspect Ratio)
- Resolution: 800 x 600 SVGA (18-bit color graphics)
- Operator Input: Analog Resistive Touchscreen (1 million presses life)
- Operating System: Windows CE 6.0 (with runtime OS license)
- Communication: Single Ethernet Port (10/100 Base-T), (2) USB Ports
- Internal Memory: 512 MB RAM / 512 MB Storage (80 MB free user application memory)
- Input Voltage: 24V DC nominal (Operational range: 18 to 30V DC)
- Power Consumption: 50 Watts maximum (2.1 Amps at 24V DC)
ALLEN-BRADLEY 2711P-T10C21D8S SER.A Human-Machine Interface (HMI) (PanelView Plus 7).
-
- Manufacturer: ALLEN-BRADLEY
- Model / Part Number: 2711P-T15C21D8S
- Screen Display: 15.0-inch TFT color touchscreen with 1024 x 768 XGA resolution and a 4:3 aspect ratio.
- Power Supply: Operates on 24V DC power.
- Network Connectivity: Built-in single Ethernet port for connecting to automated equipment like programmable controllers.
- Operating System: Features an embedded Windows CE 6.0 operating system.
- Hardware Design: Built for tough industrial plants with a rugged frame, 512 MB RAM, and 80 MB of non-volatile storage space for programs.
-
REQUEST A QUOTE
- Product Family: PanelView 800
- Display Size: 7-inch Wide TFT Active-Matrix Color LCD
- Resolution: 800 × 480 WVGA pixels
- Color Depth: 65,536 colors (65K)
- Backlight: LED (40,000-hour minimum lifespan)
- Input Type: Analog resistive touchscreen
- Processor & OS: Windows CE 6.0
- Memory: 256 MB RAM / 256 MB Internal Storage
- Input Voltage: 24V DC (0 – 24 VDC operating range)
- Environmental Protection: IP65, NEMA 4X, NEMA 12, NEMA 13 (Front of panel)
ALLEN-BRADLEY 2711R-T7T Human-Machine Interface (HMI) (PanelView 800).
-
- Manufacturer: ALLEN-BRADLEY
- Model / Part Number: 440N-Z21SS3PH
- Supply Voltage: 24V DC (20.4–26.4V DC range)
- Housing Material: Rectangular Plastic
- Sensing Distance: 18 mm
- Safety Outputs: 2 x PNP (Solid State), 0.2A maximum
- Auxiliary Outputs: 1 x PNP, 0.2A maximum
- Connection Type: 6-inch pigtail cable with an 8-pin M12 Micro QD connector
- Environmental Rating: IP67 (Dust-tight and water-resistant)
- Low-level (Standard) Coding: 440N-Z21SS3PA, 440N-Z21SS3PB, 440N-Z21SS3PH, 440N-Z21SS3PJ. High-level (Unique) Coding: 440N-Z21US3PA…
-
REQUEST A QUOTE
- Manufacturer: Rockwell Automation / Allen-Bradley
- Part Number / MPN: 440N-Z21W1PH
- UPC: 612598472529
- Switch Type: Magnetically Coded Non-Contact Interlock
- Housing Design: Plastic Small Rectangular Flat Pack
- Safety Contacts: 2 N.C. (Normally Closed) Safety
- Auxiliary Contacts: 1 N.O. (Normally Open) Aux (1 PNP Aux)
- Output Type: Solid State Relay
- Actuator Included: Standard Actuator / Standard Code
- Connection Type: 6-Inch Pigtail Cable with 8-Pin Micro (M12) DC Quick Disconnect (QD)
ALLEN-BRADLEY 440N-Z21W1PH Safety Interlock Switch (Guardmaster).
-
- Manufacturer: ALLEN-BRADLEY
- Model / Part Number: 5069-OB16
- Technical Parameter: Specification Value
- Number of Outputs: 16 Channels (1 bank of 16)
- Output Type: Sourcing (provides power to the load)
- Voltage Class: 12 / 24V DC nominal
- Operating Voltage Range: 10…32V DC
- Max Output Current: 0.5 A per channel (8 A max per module)
- Minimum Load Current: 1 mA
- On-State Voltage Drop: Less than 0.2V DC
- Power Dissipation: 3.25 Watts (maximum)
- Thermal Dissipation: 11.09 BTU/hour
- Mounting Style: DIN Rail / Panel Mount
- Built-in Protection: Features built-in output overload and short-circuit electronic protection to shield your automation components from electrical hazards.
- Smart Status LEDs: Equipped with 1 green/red Module Status indicator and 16 yellow/red I/O status LEDs for clear visual troubleshooting.
- Module Power Routing: The module is powered via Local Actuator (LA) power instead of Sensor Actuator (SA) power, allowing it to pass SA power down the line to adjacent modules without consuming it.
- Required Accessories: Please note that this module requires a separate Removable Terminal Block (RTB) kit to function. It is compatible with the 5069-RTB18-SCREW (screw connection) or 5069-RTB18-SPRING (spring-clamp connection) terminal blocks.
-
REQUEST A QUOTE
- Operating Voltage: 220V AC (Acceptable range: 200V to 240V AC), 50/60 Hz
- Contact Rating: 5A at 250VAC (Resistive load)
- Pin Configuration: 8-Pin circular plug-in base (typically mounts to a PF083A socket)
- Timing Series (NB): 4 Selectable Ranges: 0–3 seconds, 0–30 seconds, 0–3 minutes, 0–30 minutes
- Dimensions: 50mm × 40mm × 82mm / 1.97" × 1.57" × 3.23" (W × H × D)
- Certifications: CE certified, UL / C-UL recognized, RoHS compliant
- DIP Switch Range Adjustment: The "NB" designation identifies the specific time-scale assortment. Users can configure the hidden DIP switches on the side or bottom of the housing to switch the faceplate's scaling dynamically between seconds (S) and minutes (M).
- A/B Operating Modes: A built-in slide switch allows the operator to alternate between two distinct contact behaviors:
- Mounting Adaptability: Out of the box, it is designed for surface mounting or standard DIN-rail mounting via an 8-pin base socket. It can also be flush-mounted into a control panel cutout using a standard Type Y-40 adapter.
ANLY AH3-NB AC220V Time-Delay Relay (AH3 Series).
-
REQUEST A QUOTE
- Manufacturer: APC by Schneider Electric
- Model Number: AP9335TH
- Connector Type: RJ-45
- Cable / Cord Length: 3.9 meters (approx. 13 feet)
- Product Color: Black
- Operating Temperature Range: 0 to 55 °C (32 to 131 °F)
- Operating Relative Humidity: 0 to 95% (Non-condensing)
- Operating Altitude: 0 to 10,000 feet (0 to 3,048 meters)
- Storage Temperature Range: -15 to 65 °C (5 to 149 °F)
APC AP9335TH Environmental Sensor (NetBotz).
-
REQUEST A QUOTE
- Temperature Sensor: NTC Thermistor
- Control Accuracy: ±1°C
- Set Temperature Range: 5°C to 35°C
- Power Supply: 220V AC ±10%, 50Hz
- Current Load: < 2A
- Self-Consumption Power: < 2W
- Physical Dimensions: 86 × 86 × 13 mm (Fits standard 60 mm installation hole spacing)
- Power Control: Press the Power Button ( ⏽ ) once to turn the unit on, and press it again to turn it off.
- Temperature Adjustment: Press the Down Arrow (▼) button to lower the target temperature and the Up Arrow (▲) button to raise it in 1°C increments.
- Mode Selection: Press the Mode Button ( M ) to cycle through the three primary operation types displayed on the LCD screen:
- Cooling: Represented by a snowflake icon.
- Heating: Represented by a sun icon.
- Ventilation: Represented by a fan icon (operates the fan without opening the motorized valve).
APC-TMS2000DA YORK Digital Room Thermostat.
-
REQUEST A QUOTE
- Kit Type: Fluid Section / Fluid End Repair Kit
- Diaphragm Material: PTFE (Teflon) with Santoprene backup diaphragms
- Valve Ball Material: PTFE (Polytetrafluoroethylene)
- Maximum Media Intake Pressure: 120 psi (8.27 bar)
- Operating Temperature Range: 40°F to 212°F (4.4°C to 100°C)
- Country of Origin: USA
- Exhaust Safety: Before beginning disassembly, disconnect the compressed air line and cycle the pump to safely bleed off any internal fluid and air pressure. Wear appropriate chemical-resistant Personal Protective Equipment (PPE).
- Orientation is Key: When installing the split-layer diaphragms, ensure the side marked "Air Side" faces inward toward the air motor cap, while the smooth PTFE face handles the aggressive fluid side.
- Torque Settings: Do not over-tighten fluid caps or diaphragm nuts, as this will crush or pinch the PTFE O-rings, leading to immediate leaks. Always cross-torque wetted bolts incrementally using a manual torque wrench to the exact specifications mapped out in your specific ARO Pro Series Operator Manual.
- Thread Prep: Clean off old residue and apply Loctite 271 (or the thread locker specified by your manual) strictly to the diaphragm rod threads to prevent the internal assembly from spinning loose during intense pressure cycles.
ARO 637119-44-C Fluid Section Repair Kit (Pro Series).
-
REQUEST A QUOTE
- Prefix (EF): Explosionproof enclosure (NEMA 7, 9) featuring a zinc-plated steel conduit with 18" continuous electrical leads.
- Suffix (MS): Equipped with a screw-type manual operator override.
- Pipe Thread / Size: G 1/4" interface (with a 1/8" outlet variation depending on sub-manifold options).
- Flow Characteristics: Orifice size: 6 mm; Flow Coefficient
- Operating Pressure: 2 to 10 Bar (30 to 150 PSI).
- Standard Coil Voltage: 24V DC (Consuming approximately 6.9 Watts).
- Body Material: Anodized Aluminum.
- Environmental Safety: The EF prefix confirms it is fully certified for hazardous locations, isolating electrical sparks from combustible atmospheric dust or gases.
- Pilot Conversion Alert: If converting from internal to external piloting, note that the end cover seals must be flipped to block off the internal channel. Ensure the end cover screws are properly torqued back to exactly 2 Newton meters (Nm) (17.7 in-lbs) using a calibrated torque device to avoid structural air bypass.
- Media Requirements: The media running through the valve must be clean, dry, or lubricated compressed air or inert gas. Particulate filtration (≤ 40 μm) is strongly recommended to protect the internal spool seals from premature wear.
ASCO EFG551A001MS Solenoid Valve (551 Series).
-
REQUEST A QUOTE
- Function: 2/2-Way, Normally Closed (NC)
- Operating Voltage: 24V DC
- Port Size: G 1/2" (ISO 228/1 / BSP) female connection
- Flow Rate: 2.77 Cv / 2.40 Kv
- Operating Pressure: 0.3 to 10 Bar (Requires a minimum 0.3 bar differential to function)
- Body Material: Brass
- Sealing Material: NBR / FPM (depending on the exact sub-variant)
- Electrical Connection: DIN plug connection providing IP65 ingress protection
ASCO SCE238D002 24DC Solenoid Valve (SCE238 Series).
-
REQUEST A QUOTE
- Valve Function: 2/2-Way, Normally Closed (NC)
- Actuation Type: Solenoid – Pilot Operated (Built-in Pilot, Floating Diaphragm)
- Port Size / Type: G 1/2 in (ISO 228/1 standard BSP threads)
- Orifice Diameter: 12 mm
- Body Material: Brass
- Seal Options: NBR (Standard option) or FPM / Viton
- Operating Pressure: Min: 0.3 bar (4.35 psi) | Max: 10 bar (145 psi)
- Temperature Range: -10°C to 85°C (14°F to 185°F)
- Operating Voltage: 24V DC
- Power Consumption: 6.9 W (DC holding power)
ASCO SCE238D002 24VDC Solenoid Valve (Series 238).
-
REQUEST A QUOTE
- Screen Size: 7.0 inches (diagonal)
- Resolution: 800 × 480 pixels (WVGA) at approximately 133 PPI
- Display Type: a-Si TFT-LCD, LCM module
- Backlight: Integrated WLED system with an included LED driver
- Contrast Ratio: 500:1 (Typical)
- Touchscreen: None (This is the display panel only; it does not include a touch digitizer layer)
- Operating Temperature: -20°C to 70°C
- Storage Temperature: -30°C to 80°C
AUO A070VW05 V0 TFT-LCD Display Panel (A070VW05 Series).
