Showing 177–192 of 2013 results
-
REQUEST A QUOTE
- Manufacturer: ALLEN-BRADLEY
- Model / Part Number: 100-D180D11
- Current Rating: 180 Amperes continuous current.
- Coil Voltage: Conventional AC operating coil rated for 110V AC at 50 Hz / 120V AC at 60 Hz.
- Power Ratings: Capable of handling motors up to 60 HP at 230V, 150 HP at 460V, or structural loads up to 101 kW.
- Auxiliary Contacts: Built-in configuration with 1 NO (Normally Open) + 1 NC (Normally Closed) contacts.
- Design & Mounting: Non-reversing type, open-style construction engineered for direct panel mounting with screw-type terminals.
-
REQUEST A QUOTE
- Feature / Metric: Specification
- Manufacturer & Brand: Allen-Bradley / Rockwell Automation
- PC-Side Interface: Universal Serial Bus (USB)
- Drive-Side Protocols: DPI (Drive Peripheral Interface), DSI (Drive Serial Interface), and SCANport
- Data Transfer Rates: DPI: 125/250 Kbps | DSI: 19.2 Kbps | SCANport: 125 Kbps
- Serial Communication: Full-Duplex RS-232 DF1 Protocol; 8 Data Bits, 1 Stop Bit, No Parity
- Electrical Draw: DPI: 130mA @ 12V DC | DSI: 170mA @ 5V DC
- Diagnostic Indicators: Integrated LED status lights tracking Transmit (TX) and Receive (RX) activity
- Operating Environment: 0°C to 50°C (32°F to 122°F); 5% to 95% non-condensing relative humidity
- DPI Port Connection: PowerFlex 7-Class drives (e.g., PowerFlex 70, 700) and PowerFlex 750-Series (e.g., PowerFlex 753, 755, 755TS).
ALLEN-BRADLEY 1203-USB USB Converter (SCANport).
-
- Manufacturer: Allen-Bradley
- Model / Part Number: 140M-C2E-B16
- Product type: Motor protection circuit breaker (MPCB), Bulletin 140M, C-frame, screw terminals
- Rated operational current Ie: 1.6 A
- Motor current adjustment range: 1.0…1.6 A
- Magnetic trip current: 21 A (fixed short-circuit release, 13…14 x Ie max.)
- Number of poles: 3
- Rated operating voltage, max.: 690 V AC per IEC (SEV, VDE 0660); 600 V AC class per UL
-
REQUEST A QUOTE
- Manufacturer: ALLEN-BRADLEY
- Model / Part Number: 140M-C2E-B40
- Current Range: Adjustable from 2.5 to 4.0 A.
- Frame Size: C Frame.
- Number of Poles: 3-Pole design.
- Protection Type: Class 10 thermal-magnetic protection featuring adjustable thermal overload releases and fixed magnetic short-circuit trips.
- Breaking Capacity: Normal breaking capacity.
- Mounting Style: Standard DIN rail mount.
- Actuator Style: Rotary handle operation mechanism.
- Voltage Rating: Up to 600V / 690V AC at 50/60 Hz.
-
REQUEST A QUOTE
- Manufacturer: ALLEN-BRADLEY
- Model / Part Number: 140MT-C3E-B63
- Current Range: Adjustable from 4.0 to 6.3 Amps.
- Frame Size: Frame Size C.
- Magnetic Trip: Standard fixed magnetic trip at 14 × Ie.
- Tripping Class: Trip Class 10 (trips in 10 seconds or less).
- Breaking Capacity: Standard performance/breaking capacity.
- Voltage Ratings: Rated for a maximum supply voltage of 690V AC (commonly used in 480V 60Hz systems).
- Physical Interface: Equipped with a rotary turn handle (On/Off) and standard screw terminals.
- Mounting Type: Built for standard 35mm DIN rail installation.
- Certifications: UL Listed as a Type E Manual Self-Protected Combination Motor Controller.
- Modular Assembly: It can be paired directly with Allen-Bradley 100-C and 100-E series IEC-rated contactors to build complete, space-saving combination motor starters.
- Accessories: Supports both front and side-mounted auxiliary contacts for signaling and control loop integration.
- Group Installations: Certified for group motor installations, allowing multiple motors to clear under a single Branch Circuit Protective Device (BCPD) to reduce total panel footprint and cost.
- Lifecycle status: Active MPCB, Standard Magnetic Trip (Fixed at 14 x le), 4.0 – 6.3 A, Std. Performance, Frame Size C Preferred 14…
-
REQUEST A QUOTE
- Output Wattage: 240 Watts
- Output Voltage Range: 24–28 V DC (Adjustable)
- Output Amperage: 10 Amps @ 24 V DC
- AC Input Voltage: 100–240 V AC nominal (90–264 V AC absolute range)
- Input Phases: Single Phase
- Termination Type: Standard Screw Terminals
- Mounting Configuration: DIN Rail Mount
- Max Operating Temp: Up to +70 °C
- Compliance Certifications: CE, UL, CCC, C-Tick, RCM
- Slim Footprint: Part of the "Basic" or "Essential" segment designed to use minimal linear space on your DIN rail, allowing for higher component density within enclosure designs.
ALLEN-BRADLEY 1606-XLB240E Switched-Mode Power Supply (1606-XLB).
-
- Manufacturer: Allen-Bradley
- Model / Part Number: 1734-OE2V
- Product type: POINT I/O 2-channel analog output module (voltage)
- Output channels: 2 single-ended non-isolated voltage outputs
- Resolution: 14 bit (13 + sign), 1.28 mV/count
- Output range: 0…10 V (+10 V configurable)
- Load current: 3 mA per output
- Module power: POINTBus 75 mA at 5 V DC; external 24 V DC (10…28.8 V) 35 mA, 1.0 W
- Isolation: 50 V continuous, 2200 V DC for 60 s
- Dimensions: 56.6 x 12.1 x 77.5 mm, approx. 36 g
- Keyswitch position: 4
-
REQUEST A QUOTE
Technical Specifications
- Module Type: Analog Voltage Output Module (POINT I/O)
- Number of Outputs: 2 Single-ended, Non-isolated Channels
- Output Voltage Range: 0 to 10V or ±10V (configurable)
- Resolution: 14 bits
- Absolute Accuracy: 0.1% Full Scale @ 25°C (77°F)
- External Field Power: 24V DC nominal
- Mounting Format: DIN-rail mounted, open-style
- Key Features: On-board scaling, selectable input filters, hot-swappable (RIUP)
ALLEN-BRADLEY 1734-OE2V SER.C Analog Output Module (POINT I/O).
-
REQUEST A QUOTE
- Network Type: EtherNet/IP Adapter Module
- Input Voltage: 24V DC nominal (Range: 10–28V DC)
- Termination Type: M12 Quick-Disconnect
- Enclosure Rating: IP65, IP66, IP67, and IP69K (Sealed Housing when marked)
- Max Power Consumption: 8.1 W @ 28.8V DC (Backplane: 4.5 W @ 24V DC)
- Max Power Dissipation: 2.8 W @ 28.8V DC
- Dimensions: 4.41 x 2.83 x 2.56 in (112 x 72 x 65 mm)
- Weight: ~0.80 lbs (0.36 kg)
- Enclosureless Design: Features a heavily sealed, impact-resistant housing that meets IP67/IP69K standards, allowing direct machine mounting and eliminating the cost of electrical panels.
- Quick-Disconnect Fittings: Employs industry-standard M12 connectors for network and power inputs, lowering wiring labor costs and reducing point-of-failure exposure.
ALLEN-BRADLEY 1738-AENT EtherNet/IP Adapter (ArmorPOINT).
-
- Manufacturer: Allen-Bradley
- Model / Part Number: 1746-ITB16
- Product type: SLC 500 16-channel fast-response DC sinking input module
- Input channels: 16
- Input voltage: 24 V DC (10…30 V DC range)
- Input type: DC sinking
- Isolation: 500 V DC communication isolation
- Power dissipation: 0.2 W per point, 3.6 W total (per 1746-IN027)
-
- Manufacturer: Allen-Bradley
- Model / Part Number: 1746-NIO4I
- Product type: SLC 500 combination analog I/O module (2 inputs + 2 current outputs), single-slot
- Input channels: 2 differential inputs, voltage or current selectable per channel, not individually isolated
- Current input range: -20 to +20 mA (normal); absolute maximum -30 to +30 mA
- Voltage input range: -10 to +10 V dc – 1 LSB
- Input converter: 16-bit; current resolution 1.22070 uA/LSB (250 ohm input impedance); voltage resolution 305.176 uV/LSB (1M ohm)
- Output channels: 2 analog current outputs, not individually isolated
- Current output range: 0 to +20 mA normal (0 to +21 mA – 1 LSB with 5% overrange)
- Output converter: 14-bit, R-2R ladder; resolution 2.56348 uA/LSB; load range 0 to 500 ohm
- Backplane current draw: 55 mA at 5 V dc; 145 mA at 24 V dc
- Isolation / update time: Field wiring to backplane 500 V dc; 512 us update, all channels in parallel
- Environment: Operating 0 to +60 C; storage -40 to +85 C; 5 to 95% RH non-condensing
- Lifecycle status: Discontinued (2021-04-29); repair options available; engineering replacement category
-
- Manufacturer: Allen-Bradley
- Model / Part Number: 1746-NO4V
- Product type: SLC 500 analog output module, 4 voltage outputs (single-slot)
- Output channels: 4 analog voltage outputs, not individually isolated
- Voltage output range: -10 to +10 V dc – 1 LSB (single range and scale)
- Output converter: 14-bit, R-2R ladder; resolution 1.22070 mV/LSB; full scale 10 V dc
- Load range: 1K ohm to infinity; maximum load current 10 mA; max load reactance 1 uF
- Accuracy: +-0.208% of full scale at 25 C; +-0.384% over 0 to +60 C
- Step response: 2.5 ms (at 95%)
- Backplane current draw: 55 mA at 5 V dc; 145 mA at 24 V dc; external 24 V dc +-10% (21.6-26.4 V) for some applications
- Isolation / update time: Field wiring to backplane 500 V dc; 512 us update, all channels in parallel
- Environment: Operating 0 to +60 C; storage -40 to +85 C; 5 to 95% RH non-condensing
- Lifecycle status: End of Life 2015-12-30; replacement option 1746-NO8V
-
- Manufacturer: Allen-Bradley
- Model / Part Number: 1746-NR8
- Product type: SLC 500 8-point resistance (RTD) input module
- Input channels: 8
- A/D conversion: Sigma-Delta
- Backplane load: 100 mA at 5 V dc + 55 mA at 24 V dc; 1.82 W max
- Isolation: 500 V ac 1 min (channels to backplane); 5 V dc channel-to-channel
- RTD types: Platinum, nickel, nickel-iron, copper; Pt385 range -200 to +850 C
- Excitation: 0.25 / 1.0 mA
- Operating temperature: 0 to 60 C
- Lifecycle: Discontinued (2024-09-30), engineering replacement
-
REQUEST A QUOTE
- Platform Compatibility: Allen-Bradley SLC 500 (Fits into any standard SLC 1746 I/O chassis slot).
- Input Channels: 4 backplane-isolated channels.
- Supported Thermocouple Types: J, K, T, E, R, S, B, and N.
- Millivolt Range Options: ±50 mV or ±100 mV.
- Signal Accuracy: Utilizes two Cold-Junction Compensation (CJC) sensors built into the terminal block to maintain thermocouple signal tracking accuracy across temperature fluctuations.
- Backplane Power Consumption: Draws power directly from the chassis backplane:
- Resolution: 16-bit input conversion (0.01°C resolution).
ALLEN-BRADLEY 1746-NT4 SER.B Thermocouple Input Module (SLC 500).
-
- Manufacturer: Allen-Bradley
- Model / Part Number: 1746-NT4
- Product type: SLC 500 4-channel thermocouple/mV input module (Series B)
- Input channels: 4 (backplane isolated)
- Input types: Thermocouple or DC millivolt per channel, with cold junction compensation
- A/D conversion: Sigma-Delta modulation
- Input filtering: Programmable low-pass digital filter (10/50/60/250 Hz notch)
- Normal mode rejection: >100 dB at 50/60 Hz
- Common mode rejection: >150 dB at 50/60 Hz
- Isolation: 500 V dc continuous (inputs to chassis and backplane)
- Backplane load: 60 mA at 5 V dc + 40 mA at 24 V dc; 0.8 W max
-
- Manufacturer: Allen-Bradley
- Model / Part Number: 1746-OW16
- Module type: Relay contact output module, 16 channels, AC/DC voltage category; 8 points per common
- Output signal (load voltage): 5 to 125 V DC or 5 to 265 V AC digital contact output
- Relay contact ratings: Make/break 15 A / 1.5 A at 120 V AC; 7.5 A / 0.75 A at 240 V AC; DC limited to 28 VA, max 2 A below 14 V; min load current 10 mA at 5 V DC; 0 mA off-state leakage
- Continuous current: 8.0 A per common; module limited to 16.0 A AC and 1440 VA total
- Backplane current consumption: 0.170 A at 5 V DC; 0.180 A at 24 V DC
- Signal delay, max resistive load: On = 10.0 ms; Off = 10.0 ms
