Technical Specifications
- Brand/Manufacturer: Delixi
- Model Series: DZ47LE-125
- Poles Configuration: 4P (4 Poles, suitable for three-phase systems with a neutral line)
- Maximum Current Rating: 100 Amps
- Breaking Capacity: 10 kA
- Typical Leakage Sensitivity: 30 mA (standard for personnel safety and shock protection)
- Rated Voltage: Up to 400V AC (50Hz)
- Overload & Short Circuit Protection: Safeguards electrical wiring and connected machinery from drawing too much current or suffering from violent short-circuit damage.
- Residual Current (Leakage) Protection: Instantly trips the circuit if current leaks out of the system (such as into the ground or through an individual experiencing an electric shock).
- Application Environments: Highly utilized in industrial, commercial, and larger residential main distribution panels where high power capacity is required.
- Wholesale Sourcing: For bulk or business orders, international distribution platforms like Alibaba host direct factory-authorized listings.
Brand New Delixi DZ47LE-125 4P 100A Residual Current Circuit Breaker (DZ47LE Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Series: Sanyo Denki San Ace 40 (4028)
- Rated Voltage: 24V DC
- Rated Current: 0.18A (approx. 4.32W)
- Dimensions: 40 x 40 x 28 mm
- Rated Speed: 12,500 RPM
- Max Airflow: 16.2 CFM (0.458 m3/min)
- Noise Level: 44 dBA
- Bearing: Dual Ball Bearing
- Wiring: 3-wire (Red +24V, Black GND, Yellow/White tachometer signal)
- Status: Discontinued by manufacturer (custom spec, OEM spare part)
Brand New Sanyo Denki 109P0424J3073 DC24V 0.18A 3-Wire DC Cooling Fan (San Ace 40 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Display: 7.0-inch resistive touchscreen with an 800×480 resolution.
- Core Hardware: High-performance quad-core CPU backed by 128MB Flash and 128MB RAM.
- Network Connectivity: Built-in Wi-Fi, 1x 10/100M Ethernet port, and cloud integration.
- Serial Interfaces: Multi-protocol COM ports supporting RS232, RS422, and RS485.
- Physical Layout: Standard industrial cutout sizing of 192.0×138.0 mm.
- Protection Rating: Front-panel IP65 rating, making it dust-tight and resistant to water splashes in rugged environments.
- V-NET Cloud Platform: Connects seamlessly to Wecon's proprietary V-NET Cloud platform. This enables global remote tracking, configuration updates, and online data logging.
- Mobile & Web SCADA Access: Operators can view real-time operations, trigger virtual buttons, and manage alarms directly via mobile devices using dedicated cloud apps.
- Flexible Project Uploads: Projects can be compiled and uploaded via standard USB cables, USB flash drives, local LAN, or fully remote over-the-air (OTA) cloud transfers.
Brand New Wecon PI3070ig（WIFI） IoT HMI with WiFi (PI3000ig Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Instrument System: Core Specification Features & Capabilities
- Digital Oscilloscope: 2 Channels, 250MHz Bandwidth, 1 GSa/s Real-time Sampling Rate • 8M storage depth
- Waveform Generator: 1 Channel, 25MHz Frequency, 12-bit Resolution • 200 MSa/s sampling rate
- Digital Multimeter: 4000 Counts Resolution • Measures AC/DC voltage/current, resistance, capacitance, diode, and continuity
- Interface: Features a 7-inch TFT color capacitive multi-touch screen (800×480 resolution) for intuitive gesture operations.
- Power: Equipped with a massive 10,000mAh detachable lithium battery that supports Type-C 18W fast charging and can function as a temporary power bank.
- Form Factor: Built with an anti-fall, anti-seismic rugged casing and a unique suspension foot stand to allow hands-free benchtop operation.
- Analysis Tools: Features built-in hardware frequency counters, Math functions, FFT spectrum analysis, and up to 42 automatic measurement capabilities.
Brand New Hantek TO1252D Portable Tablet Oscilloscope (TO1000 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Display Size: 7 inches (16:9 Aspect Ratio)
- Resolution: 1024 × 600 pixels (16.77 million colors)
- Power Supply: DC 24V
- Digital Inputs: 16 points (DI)
- Digital Outputs: 16 points Transistor (TO) — optimized for high-speed switching
- Pulse Output: 4 channels, 200KHz (ideal for stepper and servo motor control)
- High-Speed Counters: Up to 4 channels
- Dimensions: 204 × 148 × 45 mm
- Programming Software: SKTOOL 7.1 (supports graphics configuration & ladder logic)
- Data Transfers: Supports project uploading and data updates via USB download, Ethernet download, and USB drive updates.
- Modular Extensions: Features a plug-in infrastructure capable of expanding up to 16 additional digital I/O points.
- Analog Integrations: Supports hardware plug-ins to add up to 8 channels of Analog Input (AI) and 8 channels of Analog Output (AO).
Brand New Samkoon GT-070-32MT HMI PLC All-in-One Controller (GT-070 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Actuator Type: Wobble Stick (Spring Lever with Plastic Rod)
- Contact Configuration: 1 NO + 1 NC (SPDT – Double Circuit)
- Electrical Rating: 5A at 250VAC / 240VAC
- IP Rating: IP65 (Dustproof and drip-proof)
- Operating Speed: 0.5 mm to 50 cm/s
- Mechanical Operating Frequency: 120 operations per minute max
- Electrical Operating Frequency: 30 operations per minute max
- Contact Resistance: 25 mΩ max. (initial value)
- Insulation Resistance: 100 MΩ min. (at 500VDC)
- Ambient Operating Temperature: -5°C to +65°C (with no icing)
- Mechanical Durability: >10,000,000 operations
- Body Dimensions: 88 mm × 28 mm × 25 mm (L × W × T)
- Mounting Hole Centers: 56 mm × 21 mm
- Mounting Hole Diameter: 4.5 mm
- Plastic Rod Length: 41 mm
- Net Weight: Approx. 142g
Brand New Tend TZ-8166 Double-Circuit Limit Switch (TZ Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Coil Voltage: 200–220V AC at 50/60 Hz
- Current Rating: 60 Amps
- Contact Configuration: 3-Pole main circuit with integrated 2NO + 2NC auxiliary contacts (2 Normally Open and 2 Normally Closed)
- Standard Certification: UL 508 certified for industrial motor control switches
- Mounting Type: Standard DIN rail or screw mounting
Brand New Shihlin S-P60T 220V Magnetic Contactor (S-P Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Control Voltage: 24V DC
- Output Contacts: 3 Normally Open (NO) safety contacts and 1 Normally Closed (NC) signaling contact
- Maximum Thermal Current: 5 A
- Monitoring Architecture: 2-channel evaluation with a start input
- Safety Integrity Levels: Engineered up to Category 4/PLe and SIL 3
- Electrical Connection: Screw terminals (fixed, non-detachable clamps)
- Enclosure Dimensions: 100 mm (Width) x 74 mm (Height) x 121 mm (Depth)
- Mounting Type: Standard DIN rail mounting
Brand New DOLD BN5930.48 DC24V 0041438 Emergency Stop Safety Relay (BN5930 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Series: Part of the ultra-compact TAKEX UM Series.
- Input Voltage: 12–24V DC standard operational power.
- Form Factor: Extra-thin, ultra-miniature profile (the series features a housing thickness as slim as 3.5 mm and a total component volume under 0.8 cm³).
- Light Source: Red LED, which projects a visible light spot allowing quick visual alignment and inspection during installation.
- Onboard Indicators: Equipped with built-in stability and operation LED indicators for simple troubleshooting and status checks.
Brand New Takex UM-Z3DS-38S Photoelectric Sensor (UM-Z3 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Protocol Support: PROFIBUS DPV1 (Cyclic I/O data and acyclic messaging).
- Hardware Form Factor: In-chassis module for 1769 CompactLogix systems (slots into the local I/O bank or remote 1769 expansion racks).
- Configuration Interface: Integrated via Studio 5000 / RSLogix 5000 as a standard I/O module using an Add-On Profile (AOP).
- Physical Hardware Address: Equipped with rotary switches to easily set the node's PROFIBUS bus address.
- Remote Access: The dedicated Ethernet port eliminates the need to plug directly into the module hardware on the plant floor; configuration and advanced troubleshooting can be handled over the plant network.
- Seamless PLC Integration: Appears to the CompactLogix controller as standard native I/O. Explicit CIP ladder logic message blocks handle slave status diagnostics and acyclic DP-V1 data commands.
- Configuration Flexibility: The module can automatically adapt to parameters downloaded from the PROFIBUS network Master or follow configuration locked down locally by the Logix processor.
Brand New ProSoft ILX69-PBS PROFIBUS Slave Module (ILX69 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Measuring Principle: Thin-film-on-steel Excellent long-term stability and resistance to pressure peaks.
- Measuring Range: 0 … 40 bar (Note: Some customized variants or sub-models may specify alternative ranges like 0-10 bar) Meant for high-pressure systems.
- Output Signal: 4 … 20 mA 2-wire analog current loop.
- Electrical Connection: Industrial plug EN 175301-803, Form A Standard industrial valve/sensor plug.
- Pressure Connection: G1/4″ male Threaded fitting.
- Protection Class: IP65 Dust-tight and protected against water jets.
- Material Construction: Stainless Steel Used for both the housing and the inner sensor body.
- Media Temperature Range: -25°C to +125°C
- Ambient Temperature Range: -25°C to +85°C
Brand New trafag 8244.78.2310 Pressure Transmitter (Picotrans Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Specification Parameter: Details & Values
- Channels: 1 input / 1 output
- Power Supply: 18 ~ 60 V DC
- Input Signal: 4 ~ 20mA, HART
- Input Line Resistance: Approx. 75Ω
- Available Voltage: Open-circuit voltage ≤ 26V; ≥ 16V at 20mA
- Output Signal: 4 ~ 20mA, HART
- Load Resistance: RL ≤ 550 Ω
- Transfer Accuracy: 0.1 % F.S.
- Temperature Drift: 30 ppm/°C
- Response Time: ≤ 2 ms
- Power Dissipation: 1.3 W
- Safety Integrity Level: Certified SIL3.
- Safe State Indicator: The output signal drops below 3.6mA or exceeds 21.5mA to flag faults.
- Galvanic Isolation: Full galvanic isolation between input, output, and power supply channels.
- Insulation Resistance: ≥ 100 MΩ (Input / Output / Power supply).
- Product Approvals: NEPSI, SIL, CE, FCC, CCS, CCC.
- Operating Temperature: -20 °C to +60 °C
- Storage Temperature: -40 °C to +80 °C
- Mounting Location: Must be mounted in a safe area and connected to intrinsically safe apparatus in hazardous areas (Zone 0, Zone 1, Zone 2, ⅡA, ⅡB, ⅡC, T4 ~ T6).
- Connection Method: Screw connection.
- Mounting Type: DIN 35 mm rail.
- Dimensions: 12.8mm (W) × 110mm (H) × 117mm (D).
Brand New NewPwR NPEXA-CM31 Analog Input Safety Barrier (NPEXA Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Manufacturer: Tamagawa Seiki Co., Ltd.
- Model / Part Number: TS5720N8406
- Encoder Type: Absolute Rotary Encoder (Multi-Turn / Single-Turn compatible)
- Resolution: 23-bit maximum (High resolution, serial data feedback)
- Supply Voltage: 5 VDC (standard system operating power)
- Output Communications: Serial Data / Bus-capable line driver interface (Tamagawa Serial Protocol)
- Physical Construction: Compact 35mm to 48mm housing format depending on application-specific flange mounts
- Common Application: Integrated feedback mechanism inside modern AC servo motors
- Reduced Wiring Count: Utilizes efficient high-speed serial communications, minimizing the bundle down to just 4 to 6 core output wires rather than parallel arrays.
- Absolute Angular Tracking: Retains position memory even during system power outages, mitigating the need to re-home axes upon restarts.
- Industrial Durability: Shielded electromechanical design built to withstand extreme electrical noise and high operational vibrations typical of factory automation settings.
Brand New Tamagawa TS5720N8406 Absolute Servo Encoder (FA-CODER Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Digital Inputs: 8 Channels (8DI)
- Signal Type: PNP
- Channel Connections: 8 x M8 3-pin connection ports
- Bus Connection: 2 x M12 B-coded ports
- Operating Voltage: 24 V DC
- Enclosure Rating: IP67 (dust-tight and water-resistant for harsh machine-mount environments)
- Housing Material: Plastic
- Key Feature: The "011" Distinction
Brand New Elco SPDB-0800D-011 Digital Extension I/O Module (Spider67 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Number of Channels: 2 independent channels.
- Safe-Area Output: Two relays equipped with single-pole, changeover contacts.
- Hazardous-Area Inputs: Inputs conform strictly to NAMUR/DIN 19234 standards for proximity detectors.
- Voltage Applied to Sensor: 7V to 9V DC from 1kΩ ±10%.
- Line Fault Detection (LFD): A user-selectable feature designed to identify open or short circuits within the field wiring circuits.
- Phase Reversal Control: Independent channel configuration allowing an alarm or output condition to be signaled for either state of the input sensor.
- Galvanic Isolation: 250V AC or DC continuous between the power supply, hazardous-area circuits, and relay outputs.
- Switches: Zone 0, IIC, T6 hazardous areas, or Class I, Div 1, Group A hazardous locations.
- Proximity Detectors: Zone 0, IIC, T4–T6 hazardous areas (if suitably certified), or Class I, Div 1, Group A hazardous locations.
Brand New MTL MTL5018 Switch Proximity Detector Interface (MTL5000 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Line Count: 2048 pulses per revolution.
- Output Signal: ~1 Vpp sinusoidal voltage signals (with 1 sine and 1 cosine track for absolute position detection per revolution).
- Power Supply: 5 V DC (±5%).
- Shaft Type: Tapered shaft (1 to 10 ratio, functional diameter of 9.25 mm).
- Electrical Connection: 14-pin straight double-row plug connector with a locking mechanism.
- Protection Rating: IP40 environmental protection against dust.
- Operating Temperature: Safe for operation between -40 °C and +120 °C.
Brand New Heidenhain ERN 1387 2048 62S14-70 ID：749144-59 Incremental Rotary Encoder (ERN 1387 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
