Showing 529–544 of 1357 resultsSorted by latest
-
REQUEST A QUOTE
- Nominal Resistance: 500 Ω
- Tolerance: ±5%
- Linearity: ±2%
- Loading Capacity: Max. 1 W
- Enclosure Rating: IP54 (Dust & splash proof)
- Electrical Connection: 1-meter halogen-free cable (3 × 0.75 mm²)
- Closed-Loop Feedback: Provides a continuous resistive signal to commercial proportional temperature controllers to indicate exact valve or damper positioning.
- Remote Position Indication: Routes resistance changes directly to external electric meters or building automation system (BAS) monitoring panels.
- Parallel Actuator Control: Serves as a master positioner to synchronize the operation of multiple slave actuators linked across the same network.
Brand New BELIMO P500A Potentiometer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque: 10 Nm
- Nominal Voltage: AC/DC 24 V (50/60 Hz)
- Control Input: Modulating DC 2…10 V (Operating range) / DC 0…10 V input signal
- Position Feedback: DC 2…10 V for electrical position indication
- Running Time: 150 seconds (constant for 90° rotation)
- Power Consumption: 2 W during operation / 0.4 W in rest position / 4 VA wire sizing
- Protection Rating: IP54 / NEMA 2
- Fail-Safe: Non fail-safe (stays in its last position upon power loss)
- Manual Override: Integrated push-button to disengage the gear train for manual adjustment
Brand New BELIMO NM24A-SR Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque: 8 Nm (70 in-lb), suitable for air damper sizes up to approximately 2 m².
- Running Time: Ultra-fast 4 seconds for a 90° rotation.
- Nominal Voltage: AC/DC 24 V (50/60 Hz).
- Control Type: Open/Close (Note: It is not designed for 3-point floating applications).
- Power Consumption: 13 W during operation / 2 W at rest.
- Enclosure Rating: IP54 (NEMA 2 equivalent).
- Simple Direct Mounting: Easily fastens to a universal shaft clamp and includes an anti-rotation strap.
- Manual Override: Features a self-resetting push-button that disengages the gear train for manual adjustment.
- High Operational Safety: The motor is completely overload-proof, requires no end-limit switches, and stops automatically when it hits a mechanical end stop.
Brand New BELIMO NMQ24A Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Running Time: 4 seconds for a 90° rotation, making it ideal for processes requiring rapid air volume adjustments.
- Torque: 8 Nm (Newton meters), capable of driving air dampers up to approximately 1.5 m² in size.
- Nominal Voltage: AC/DC 24 V (50/60 Hz).
- Control Type: Modulating 2…10 V DC control signal.
- Position Feedback: 2…10 V DC for precise system monitoring.
- Power Consumption: 13 W while running, 2 W in holding mode, and 23 VA for wire sizing.
- Enclosure Rating: IP54 and NEMA 2, providing solid environmental protection.
- Shaft Connection: Equipped with a universal shaft clamp supporting round and square shafts measuring 8…26.7 mm.
- Manual Override: Includes a lockable, self-resetting push-button to disengage the gear train for manual damper adjustment.
- Rotation Control: Features a selectable direction of motion switch (0/1) and adjustable mechanical end stops to limit the maximum angle of rotation (up to 95°).
Brand New BELIMO NMQ24A-SR Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Nominal Resistance: 10 kΩ
- Tolerance: ±5%
- Linearity: ±2%
- Resolution: Min. 1%
- Loading Capacity: Max. 1 W
- Enclosure Rating: IP54 (guarantees protection against dust and moisture splashes)
- Electrical Connection: Pre-wired 1-meter (3 ft), 3-conductor, halogen-free cable
- Housing Color: Grey (used for visual differentiation from other resistance variations like the 140 Ω, 500 Ω, or 2800 Ω models).
- Closed-Loop Monitoring: Directly feeds real-time resistance measurements back to an automation controller to indicate exact damper blade or valve position.
- Simple Mechanical Coupling: Mounts directly over the actuator spindle via an integrated shaft clamp mechanism, requiring no complex linkages.
Brand New BELIMO P10000A Potentiometer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Supply Voltage: AC/DC 24 V (50/60 Hz)
- Torque: 10 Nm (90 in-lb)
- Control Type: Open/Close or 3-point (floating control)
- Running Time: 150 seconds
- Angle of Rotation: Max. 95°, adjustable with mechanical end stops
- Enclosure Rating: IP54
- Manual Override: Pushbutton to disengage the gear train
- Actuator Model: Control Signal / Protocol
Brand New BELIMO NM24A Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Nominal Voltage: AC/DC 24 V (50/60 Hz)
- Operating Range: AC 19.2…28.8 V / DC 19.2…28.8 V
- Power Consumption (Operating): 1.5 W
- Power Consumption (Rest Position): 0.2 W
- Wire Sizing Capacity: 3.5 VA
- Connection (Supply/Control): 1-meter PVC cable, 3 x 0.75 mm²
- Torque Motor: 10 Nm
- Control Type: Open/close or 3-point
- Integrated Auxiliary Switch: 1 x SPDT (adjustable 0…100%, switching capacity 1 mA…3 A, AC 250 V)
- Direction of Rotation: Reversible (selectable with switch 0 for CCW / 1 for CW)
Brand New BELIMO NM24A-S Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Nominal Voltage: AC 100…240 V (50/60 Hz)
- Nominal Torque: 10 Nm
- Control Type: Open-close (On-Off), 3-point
- Power Consumption: 2.5 W (In operation) / 0.6 W (At rest) / 5.5 VA (Wire sizing)
- Running Time: 150 s / 90°
- Angle of Rotation: Max. 95° (Adjustable mechanical end stops)
- Direction of Motion: Selectable with switch 0 (CCW) / 1 (CW)
- Enclosure Rating: IP54 / NEMA 2
- Mechanical Connection: Universal shaft clamp 8…26.7 mm
- Electrical Connection: Cable 1 m, 3 x 0.75 mm²
Brand New BELIMO NM230A Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque (Motor & Fail-Safe): 10 Nm
- Control Type: Open/Close (On/Off)
- Running Time (Motor): 75 seconds for a 90° rotation
- Running Time (Fail-Safe): < 20 seconds at room temperature via spring tension
- Auxiliary Switches: 2x SPDT (Single Pole Double Throw) integrated switches for position feedback (one fixed at 10%, one adjustable from 11…90%).
- Power Consumption: 6 W in operation / 2.5 W in rest position
- Enclosure Rating: IP54 / UL Enclosure Type 2
- Shaft Mounting: 10…25.4 mm universal shaft clamp with an anti-rotation mechanism
- Normal Operation: The actuator moves the damper to its operating position while simultaneously tensioning its internal return spring.
- Fail-Safe Mechanism: If the supply voltage is interrupted, the actuator automatically turns the damper back to its safe emergency position using spring force.
Brand New BELIMO NFA-S2 Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque: 4 Nm
- Running Time: 9 seconds for a 90° rotation
- Power Supply: 24 V AC/DC (50/60 Hz)
- Control Type: Open/Close or 3-point (Floating)
- Enclosure Rating: IP54 (UL/NEMA 2)
- Mounting: Simple direct mounting on the ball valve via a single central screw.
- Manual Override: Equipped with a manual override push-button to temporarily disengage the gear train for adjustments.
Brand New BELIMO LRQ24A Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Control Type: Multi-Function Technology (MFT), programmable (Default analog 2…10 V DC, but configurable for floating point, PWM, or On/Off).
- Linear Force: 500 N [115 lbf].
- Supply Voltage: AC/DC 24 V (50/60 Hz).
- Power Consumption: 2.5 W running / 1.5 W holding; 4 VA for wire sizing.
- Running Time: 90 seconds (programmable range from 90 to 150 seconds).
- Stroke Length: Up to 0.6" [15 mm] for LV series linkages, or 3/4" [20 mm] for SV series.
- Manual Override: 4 mm hex crank (included).
- Enclosure Rating: IP54 / NEMA 2.
- Electrical Connection: 3 ft [1 m], 18 GA plenum-rated cable with 1/2" conduit connector.
- Assembly Type: Description
Brand New BELIMO LVX24-MFT Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque: 5 Nm
- Nominal Voltage: AC 100…240 V (50/60 Hz)
- Control Type: 2-point (Open/Close) or 3-point (Floating)
- Running Time: 90 seconds for a 90° rotation
- Power Consumption: 2 W in operation / 0.5 W in rest position (4 VA wire sizing)
- Protection Class: IP54 / NEMA 2
- Connection: Pre-equipped with a 1-meter cable
- Simple Direct Mounting: Attaches directly to compatible Belimo Ball Valves using a single central screw.
- High Functional Reliability: Features overload protection. It does not require end-limit switches and automatically stops when it hits mechanical end stops.
- Manual Override: Equipped with a manual override push-button that temporarily disengages the gear train for manual adjustment.
Brand New BELIMO LR230A Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque: 4 Nm (35 in-lb), suitable for air control dampers up to approximately 0.8 m².
- Nominal Voltage: AC/DC 24 V, 50/60 Hz.
- Running Time: 2.5 seconds for a 90° rotation.
- Control Type: Open/close (not suitable for 3-point controls).
- Power Consumption (Operating): 13 W
- Power Consumption (Rest): 2 W
- Power Consumption (Wire Sizing): 23 VA
- Angle of Rotation: Max. 95°, adjustable with mechanical end stops
- Connection: Cable 1 m, 3 x 0.75 mm²
- Protection Class: IP54 / Protection Class III (SELV)
Brand New BELIMO LMQ24A Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque Output: 5 Nm
- Running Time: 35 seconds for a 90° rotation (significantly faster than standard 150-second standard actuators)
- Nominal Voltage: AC 100…240 V (50/60 Hz)
- Control Type: Open/close or 3-point floating control
- Power Consumption: 2 W during operation / 0.5 W in rest position
- Integrated Auxiliary Switch: 1x SPDT (0…100%) for position feedback signals
- Protection Rating: IP54 / NEMA 2 enclosure type
- Simple Direct Mounting: Attaches easily to a universal shaft clamp with an included safety catch to prevent over-rotation.
- Manual Override: Features a temporary or lockable push-button manual override that disengages the gear train for manual adjustment.
- High Functional Safety: The actuator is completely overload-proof, requires no end switches, and automatically stops when hitting its mechanical limits.
Brand New BELIMO LMC230A-S Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque: 5 Nm
- Nominal Voltage: AC/DC 24 V (50/60 Hz)
- Control Signal: Modulating DC 2…10 V (or 4…20 mA with a 500 Ω resistor)
- Position Feedback: DC 2…10 V
- Enclosure Rating: IP54 (dust and splash water protection)
- Non-Fail Safe: The actuator remains in its last position if power is completely cut off (it does not spring back to an open or closed safety state).
- Manual Override: Features a manual disengagement push-button to manually position the damper during setup or power outages.
- Adjustable Rotation: The maximum mechanical angle of rotation is 95°, which can be physically limited with adjustable end stops.
Brand New BELIMO LM24A-SR-F-T Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque: 5 Nm
- Nominal Voltage: AC 100…240 V, 50/60 Hz
- Control Type: Modulating (DC 0…10 V, working range DC 2…10 V)
- Position Feedback: DC 2…10 V (Measuring voltage, max 1 mA)
- Power Consumption: 1.8 W (In operation) / 1 W (At rest) / 4 VA (Wire sizing)
- Running Time: 150 s / 90°
- Angle of Rotation: Max. 95° (Adjustable mechanical end stops)
- Mechanical Interface: Universal spindle clamp 6…20 mm
- Sound Power Level: 35 dB(A)
- Manual Override: Equipped with a lockable push-button for temporary manual adjustment.
Brand New BELIMO LM230ASR Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
