Showing 529–544 of 2131 results
-
REQUEST A QUOTE
- Torque: 20 Nm (ideal for small to medium-sized valves)
- Nominal Voltage: AC/DC 24 V (50/60 Hz)
- Control Type: Open/close (2-point) or 3-point control
- Running Time: 90 seconds for a 90° rotation
- Enclosure Rating: IP54 (dust and splash resistant)
- Mounting: ISO 5211 F05 flange for direct mounting onto ball valves with a single central screw
- Power Consumption: 2 W during operation / 0.2 W at rest
- Built-in Protection: Fully protected against overload; it stops automatically at mechanical end stops without requiring limit switches.
- Manual Override: Features a temporary or permanent gear-disengagement pushbutton for manual valve adjustment.
- Parallel Operation: Can be safely wired in parallel with other actuators, provided performance data is respected.
BELIMO SR24A-5 Valve Actuator (SR Series).
-
REQUEST A QUOTE
- Input Signal: 4–20 mA
- Output Range: 3–15 PSIG (20–100 kPa)
- Supply Pressure: 18–100 PSIG (6.9 BAR max, requires min 3 psig above max output)
- Flow Capacity: Up to 12 SCFM (339 SLPM) via integrated pneumatic volume booster
- Enclosure Rating: General Purpose (panel or surface bracket mounting)
- Pneumatic Port: 1/4" NPT
- Electrical Port: 1/2" NPT with 18" wire leads
- Field Reversible: Reverse-acting operation by swapping signal lead polarity
- Calibration: External zero and span adjustments
- Split Ranging: Field-recalibratable to 3–9 PSIG or 9–15 PSIG
Bellofram 961-070-000 T1000 Electro-Pneumatic I/P Transducer (Type 1000 Series).
-
REQUEST A QUOTE
- Sensing Type: Through-beam type (Emitter + Receiver)
- Sensing Distance: 10 meters (approx. 32.8 feet)
- Sensing Target: Opaque materials (Minimum diameter: Ø16 mm)
- Light Source: Infrared LED (850 nm wavelength)
- Power Supply Voltage: 24–240 VAC ±10% (50/60Hz) / 24–240 VDC ±10% (Ripple P-P: max 10%)
- Power Consumption: Max. 4 VA
- Control Output: Relay contact output (SPDT, 1c contact composition)
- Contact Capacity: 30 VDC 3A resistive load / 250 VAC 3A resistive load
- Operation Mode: Light-ON / Dark-ON (Selectable via built-in switch/VR)
- Response Time: Max. 20 ms
- Indicators: Operation indicator (Red), Stability indicator (Green)
- Connection Method: Cable type (Ø5 mm, 5-wire, Length: 2 meters)
- Ingress Protection: Rated at IEC IP50
- Operating Temperature: -20°C to +65°C (-4°F to 149°F) with no icing or condensation
- Vibration Resistance: 1.5 mm amplitude at a frequency of 10 to 55 Hz in X, Y, Z directions for 2 hours
- Housing Material: Heat-resistant ABS (Case/Cover); Polycarbonate (Sensing lens)
- Dimensions: 18 mm (W) x 50 mm (H) x 50 mm (D)
- Included Accessories: VR adjustment screwdriver, mounting bracket, bolts, and nuts
- Power Connections: The internal power regulator allows you to use standard industrial AC or DC lines without swapping sensor models.
- Relay Protection: When driving inductive loads (like an external contactor or motor coil), use a surge absorber or diode across the load to safeguard the internal SPDT relay contact lifetime.
- Alignment: Emitter and receiver must be mounted directly face-to-face. Use the stability indicator (green LED) to fine-tune the alignment until it stays solidly lit.
BEN10M-TFR AUTONICS Through-beam Photoelectric Sensor.
-
REQUEST A QUOTE
- Sensing Type: Diffuse reflective
- Sensing Distance: 300 mm (12 inches)
- Sensing Target: Opaque and translucent materials
- Light Source: Infrared LED (940 nm)
- Response Time: Maximum 1 ms
- Power Supply: 12–24 VDC (±10% ripple)
- Operation Mode: Light-ON / Dark-ON selectable via a built-in switch
- Control Output: NPN and PNP open collector simultaneous output
- Connection Type: Attached 2-meter cable
- Built-in Amplifier: Avoids the need for external control units, saving space in tight industrial enclosures.
- Simultaneous Output: Simplifies wiring and integration by providing both NPN and PNP transistor outputs at once.
- Noise Immunity: Features a built-in specialized IC photodiode that filters out electrical interference and ambient sunlight up to 11,000 lx.
- Visual Diagnostics: Includes stability and output LED indicators for quick installation, troubleshooting, and alignment checking.
- Common Uses: Ideally deployed on assembly lines, conveyor systems, packaging machines, and bottling plants to verify object positioning or piece counting.
BEN300-DDT AUTONICS Diffuse Reflective Photoelectric Sensor.
-
REQUEST A QUOTE
- Sensing Type: Diffuse reflective.
- Sensing Distance: 300 mm (30 cm).
- Target Material: Opaque and translucent materials.
- Light Source: Infrared LED (940 nm).
- Power Supply: Universal 24–240VAC (50/60Hz) or 24–240VDC.
- Control Output: Relay (comprising COM, NO, and NC terminals).
- Operation Mode: Light-ON or Dark-ON (selectable via an onboard switch).
- Response Time: Maximum 20 milliseconds.
- Environmental Protection: IP50 rated.
- Built-In Power Supply: Simplifies installation by operating directly on standard AC or DC industrial control voltages.
BEN300-DFR AUTONICS Diffuse Reflective Photoelectric Sensor.
-
REQUEST A QUOTE
- Sensing Type: Retroreflective (Standard type)
- Sensing Distance: 0.1 to 5 meters (when used with MS-2 reflector)
- Sensing Target: Opaque material, minimum Ø60 mm
- Power Supply: 24–240 VAC ±10% 50/60 Hz / 24–240 VDC ±10%
- Power Consumption: Max. 4 VA
- Light Source: Infrared LED (940 nm)
- Response Time: Max. 20 ms
- Operation Mode: Light ON / Dark ON (Selectable via built-in switch)
- Control Output: Relay (SPDT contact, 1C)
- Relay Contact Rating: 250 VAC 3A resistive load
- Indicators: Orange (Operation Indicator), Green (Stability Indicator)
- Connection Type: Axial 2-meter, 5-wire outgoing cable (Ø6.0 mm)
- Protection Rating: IP50 (IEC Standard)
- Ambient Temperature: Operating: -20°C to 65°C (Storage: -25°C to 70°C)
- Brown: Power + / Line
- Blue: Power – / Neutral
- White: Common (COM)
- Black: Normally Open (NO)
- Gray: Normally Closed (NC)
BEN5M-MFR AUTONICS Retroreflective Photoelectric Sensor.
-
REQUEST A QUOTE
- Sensing Type: Retro-reflective
- Sensing Distance: 7 meters
- Sensing Target: Opaque materials
- Supply Voltage: 12–24V DC
- Control Output: Relay contact
- Light Source: Infrared LED
- Operation Mode: Light ON / Dark ON
- Indicators: Dual LED
- Connection Type: Pre-wired Cable
- Environmental Protection: IP54 / IP67
- Operating Temperature: -20°C to +65°C
- Adjustable Sensitivity: Built-in volume adjuster allows precision calibration based on background reflective materials.
- Relay Output Flexibility: The mechanical relay configuration makes it highly adaptive for switching both AC and DC industrial loads directly.
- Noise Immunity: Uses a specialized Autonics ASIC photodiode to minimize interference from surrounding ambient light or electrical line noise.
BEN7M-MDR AUTONICS Retroreflective Photoelectric Sensor.
-
REQUEST A QUOTE
- Housing Size / Style: M12x1 threaded barrel, Ø 12 x 78 mm
- Installation Type: Flush mounting
- Sensing Range: 1.5 mm
- Switching Output: PNP Normally Open (NO)
- Operating Voltage: 10…30 VDC
- Switching Frequency: 1000 Hz
- Maximum Pressure Rating: 500 bar
- Enclosure Rating: IP68
- Housing Material: Stainless steel with an EP sensing surface
- Electrical Connection: M12x1-Male connector, 4-pin
- Operating Temperature: -25°C to +80°C
BES 516-300-S135-S4-D BALLUFF Inductive Proximity Sensor.
-
REQUEST A QUOTE
- Sensing Range: 4 mm
- Installation Type: Non-flush (unshielded)
- Switching Output: PNP, Normally Open (NO)
- Housing Dimensions: M12x1 thread diameter, 50 mm length
- Connection: M12x1 male connector, 4-pin
- Operating Voltage: 10…30 VDC
- Switching Frequency: 2500 Hz
- Housing Material: Nickel-free coated brass with a Polybutylene Terephthalate (PBT) sensing surface
- Environmental Protection: IP68 rating
- Operating Temperature: -25°C to 70°C (-13°F to 158°F)
BES 516-356-E5-C-S4 BALLUFF Inductive Proximity Sensor.
-
REQUEST A QUOTE
- Dimensions: 120 mm x 120 mm x 38 mm (Standard 12038 frame size)
- Rated Voltage: 230V AC (Operates on 50/60 Hz frequencies)
- Power Consumption: 22 Watts at 50Hz / 19 Watts at 60Hz
- Rotational Speed: 2650 RPM (50Hz) / 3000 RPM (60Hz)
- Airflow Volume: 89 CFM at 50Hz / 100 CFM at 60Hz
- Noise Rating: 46 dBA to 48 dBA
- Bearing Type: Dual ball bearing (50,000-hour life expectancy)
- Construction: Die-cast aluminum metal frame with a glass fiber reinforced plastic impeller
- Termination: 2-wire leads or terminal pins
- Model: 4C-230HB (metal frame, plastic leaf) Size: 120*120*38MM Voltage: 230V (50/60HZ) Power: 19/22W Speed: 2650/3000RPM Bearing: …
BI-SONIC 4C-230HB 230V Industrial AC Axial Fan (4C Series).
-
REQUEST A QUOTE
- Component Type: AS-i Safety PCB / OEM Slave Module
- Dimensions: 73 mm x 37.5 mm
- I/O Configuration: 1 Safe Input (1SI) / 2 Standard Digital Outputs (2O)
- Connection Type: 11 mm short, angled wiring pins (Pin Variant 13194)
- Operating Voltage: 24V DC
- Mounting Style: Panel / Integrated PCB Mount
- Lifecycle: This specific part number has been discontinued by the manufacturer (Bihl+Wiedemann).
- Distributed Safety Systems: Transmits critical dual-channel safe inputs back to a centralized AS-i Safety Monitor over a standard yellow AS-i ribbon cable network.
BIHL+WIEDEMANN BW2334 AS-i Safety PCB Module (BW Series).
-
REQUEST A QUOTE
- Sensing Type: Through-beam type (Emitter + Receiver)
- Sensing Distance: 10 meters (approx. 32.8 feet)
- Standard Sensing Target: Opaque material (Minimum diameter: Ø12mm)
- Light Source: Red LED (660nm wavelength)
- Response Time: Maximum 1ms
- Power Supply Voltage: 12–24VDC ±10% (Ripple P-P: max. 10%)
- Operation Mode: Light ON / Dark ON (Selectable via switch or VR)
- Control Output: NPN open collector
- Protection Structure: IP65 / IP67 (IEC standards)
- Advanced Optical Performance: High-quality lenses offer robust noise resistance and minimize the destabilizing effects of inverter disturbance light or bright ambient illumination.
- Built-in Circuit Protection: Features integrated protection against reverse power polarity, output short-circuits, and overcurrent conditions.
- Easy Adjustment: Incorporates a built-in sensitivity adjustment VR (Variable Resistor).
BJ10M-TDT AUTONICS Through-Beam Photoelectric Sensor.
-
REQUEST A QUOTE
- Bus Interface: 2 × RJ45 (built-in daisy-chaining/cascading)
- Data Transfer Rate: 100 Mbit/s (100BASE-TX)
- Power Supply: 24 V DC (-15% / +20%)
- K-Bus Current Supply: 1750 mA
- Power Contacts: Max. 24 V DC / Max. 10 A
- Electrical Isolation: 500 V (contacts / supply / Ethernet)
- Operating Temperature: -25°C to +60°C
- Protection Rating: IP20
- Topology Versatility: The dual RJ45 ports allow the coupler to act as a line or star topology endpoint. The upper port connects to the network segment, while the lower port interfaces with downstream EtherCAT devices.
- Placement Restrictions: In an EtherCAT network, the BK1120 can be positioned anywhere along the 100BASE-TX signal transfer section, except directly connected to a standard Ethernet switch (it requires an EtherCAT Master or an appropriate junction component like an EK1000).
- Configuration: System integration and parameterization can be handled via the Beckhoff KS2000 Configuration Software or through EtherCAT ADS (Automation Device Specification).
- Diagnostics: Features onboard LEDs indicating the status of the EtherCAT state machine (RUN and ERROR), alongside standard indicators for the 24 V coupler supply and active power contact bridging.
BK1120 BECKHOFF EtherCAT Bus Coupler.
-
REQUEST A QUOTE
- Display Technology: TN, Normally White, Transmissive screen.
- Brightness & Contrast: Offers a high luminance ranging between 350 to 500 cd/m² (nits) depending on the sub-variant, paired with an excellent 800:1 contrast ratio for clean readability.
- Interface Options: Primarily designed with a 20-pin LVDS interface (supporting 6-bit/8-bit grayscale), though standard parallel RGB variants also exist for legacy boards.
- Thermal Endurance: Operates reliably in extreme temperatures ranging from -20°C to 70°C.
- Surface Treatment: Finished with an anti-glare hard coating to drastically reduce reflection in brightly lit environments.
- Touch Capability: Shipped as a display-only module without a built-in touch panel, though aftermarket resistive or PCAP digitizers are often overlaid by system integrators.
BOE BA104S01-100 TFT-LCD Display Module (BA104S01 Series).
-
REQUEST A QUOTE
- Screen Size: 12.1 inches (Diagonal active area)
- Native Resolution: 800 × 600 pixels (SVGA standard)
- Aspect Ratio: 4:3 (Standard Landscape layout)
- Display Technology: TN (Twisted Nematic), Normally White, Transmissive
- Luminance / Brightness: 400 nits (cd/m²) typical (High visibility under strong lighting)
- Contrast Ratio: 700:1 to 800:1 typical
- Color Support: 16.7M colors (Supports 6-bit / 8-bit grayscale)
- Viewing Angles: 80° / 80° (Left/Right), 65° / 75° (Up/Down)
- Signal Interface: LVDS (Low-Voltage Differential Signaling) standard panel connection
- Backlight System: White LED (WLED) with an integrated LED Driver
BOE BA121S01-100 TFT-LCD Display Panel (BA121S01 Series).
-
- Manufacturer: BOE
- Model / Part Number: MV190E0M-N10
- Screen Size: 19.0 inches diagonally.
- Resolution: 1280 × 1024 pixels (SXGA).
- Aspect Ratio: 5:4 square format.
- Display Technology: Advanced Super Dimension Switch (ADS / IPS type) providing deep blacks and wide 89° viewing angles from all directions.
- Brightness: 250 cd/m² (typical).
- Contrast Ratio: 1000:1.
