Showing 289–304 of 1357 resultsSorted by latest
-
REQUEST A QUOTE
- Control Modes: Sensorless Vector Control (SVC), V/F Control, and Torque Control
- Input Phase & Voltage: 3-Phase, 380V to 415V AC (50/60 Hz)
- Compatible Motor Power: 4.0 kW (5 HP) for heavy-duty / 5.5 kW (7.5 HP) for light-duty
- Output Current: 9 Amps (General) / 13 Amps (Pump)
- Braking Unit: Built-in internal dynamic braking unit (for direct resistor connection)
- Enclosure Rating: IP20 Protection
- Advanced Control Engine: Utilizes a high-speed DSP control system to deliver precise open-loop vector motor control.
- Starting Torque: Delivers an impressive 150% torque at 0.5Hz under sensorless vector control.
- Built-in PLC & PID: Features a 16-step simple macro PLC setup, multi-speed controls, and a built-in PID loop controller for process automation.
- Flexible Programming: Fully programmable digital and analog input/output terminals.
- System Protection: Outfitted with specialized mechanical anti-resonance jump frequencies, instantaneous power failure ride-through, and sleep-wake delay modes.
- Manuals & Wiring: A comprehensive 156-page wiring and parameter overview is hosted on the ManualsLib INVT CHF100A-004G/5R5P-4 Hub.
Brand New Invt CHF100A-004G/5R5P-4 Variable Frequency Drive (CHF100A Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Channels & Signal Type: 4-channel digital input (NAMUR / mechanical switches).
- Supply Voltage: Universal range supporting 20–250 VAC or 20–125 VDC.
- Adjustable Modes: Parametrizable output mode (Normally Open / Normally Closed) via switches.
- Line Monitoring: Wire-break and short-circuit monitoring (can be toggled ON/OFF).
- Housing & Mount: Polycarbonate/ABS housing, IP20 rated, 27mm width for DIN rail mounting.
- Operating Temperature: Suitable for ambient conditions from -25°C to +70°C.
- Ex Zones: Certified for installation in Zone 2.
- Global Certifications: ATEX, IECEx, UL, cFMus, CSA, TR CU, INMETRO, TIIS, and NEPSI.
Brand New Turck IM1-451Ex-T 7541189 Isolating Switching Amplifier (IM1 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Measurement Principle: HDDM+ (High Definition Distance Measurement plus)
- Working Range: 0.05 m to 4 m
- Scanning Range (10% Remission): 2 m
- Aperture Angle: 270° horizontal
- Scanning Frequency: 15 Hz
- Angular Resolution: 1°
- Light Source: Infrared laser (850 nm), Laser Class 1 (eye-safe)
- Supply Voltage: 9 V DC to 28 V DC
- Power Consumption: Typ. 4 W (up to 16 W max)
- Digital Outputs: 3 x PNP outputs + 1 x Device Ready output
- Interface: Micro USB (Type B) for configuration
- Enclosure Rating: IP65
- Dimensions: 60 mm x 60 mm x 79 mm
- Response Time: 1 scan (typ. 67 ms)
- Systematic Error: ± 40 mm / Statistical Error: < 30 mm
- MTBF / MTTFd: > 100 years
Brand New SICK TIM320-1131000 1062219 2D LiDAR Sensor (TiM320 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Feedback Inputs: Features 2 independent input channels that support both incremental and SSI (Synchronous Serial Interface) encoders.
- High-Speed Counter: Equipped with a full 32-bit counter for high-resolution positioning tracking.
- Hardware Triggers: Allows for near-instantaneous position measurement and latching/storage initiated directly via hardware triggers.
- Diagnostics: Built-in monitoring safeguards, including encoder supply voltage monitoring and cable break detection to prevent runaway conditions if a feedback line is damaged.
- Wind Energy: Controlling blade pitch and yaw alignment systems.
- Marine Automation: Monitoring rudder feedback and winch operations.
- Industrial Machinery: High-accuracy CNC, packaging, or material handling axis control.
Brand New BACHMANN ISI202 Encoder Resolver Interface Module (MX200 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Input Signal Options: 0…20 mA, 4…20 mA, or 0…10 V DC (selectable via external DIP switches).
- Output Signals: 2x individual 0/4…20 mA analog outputs.
- Isolation Type: 4-Port Isolation (input, both outputs, and power supply are completely decoupled from each other).
- Power Supply: 24 V DC (±10%) with support for a 24V DC DIN rail bus connection system.
- Output Load: 2x 500 ohms (can drive up to 1000 ohms total load if outputs are combined).
- Response Time: < 1 ms for precise, high-speed signal tracking.
- Protective Separation: Conforms to EN 61140 to protect personnel and control equipment against high voltages.
- Space Saving: Replaces two standard isolator modules with a single ultra-slim 6 mm housing, dramatically cutting down DIN rail footprint.
- Easy Calibration: Supports calibrated range selection via DIP switches, eliminating the need for complicated manual trimming.
- Bus Connection: The P0 version utilizes an optimized DIN rail bus power option, reducing wiring labor and complexity across multi-unit setups.
Brand New Knick A 20300 P0 Signal Doubler Isolator (VariTrans Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Sensing Range: 5 mm nominal detection distance.
- Installation: Flush mounting (shielded), allowing it to be embedded directly into metal housing without false triggering.
- Output Type: PNP, complementary (meaning it features both Normally Open [NO] and Normally Closed [NC] outputs).
- Operating Voltage: 10 to 30 V DC.
- Housing Diameter: M18 threaded cylindrical barrel (18 mm outer diameter).
- Housing Length: 60 mm metal body length.
- Termination: V1 connector, which corresponds to a standard M12 4-pin male quick-disconnect plug.
- Switching Frequency: 0 to 800 Hz.
Brand New Pepperl+Fuchs NBB5-18GM60-A2-V1 Cylindrical Inductive Proximity Sensor (NBB5 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Compatible Cylinder Series: Designed for several Norgren ISO/VDMA profile cylinder ranges, including the DA/8000, PRA/182000, PRA/8000, RA/8000, and RA/181/182 series.
- Seal Material: High-grade polyurethane, which offers high impact resistance, efficient low-friction operation, and a long operational lifespan.
- Kit Contents: Comes as a complete overhaul set including all necessary O-rings, pneumatic seals, linear seals, and a grease pack for proper lubrication during reassembly.
Brand New Norgren QA/8032/00 Cylinder Service Seal Kit (QA Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Actuation Type: 3-Position Closed Center (Double Solenoid)
- Rated Voltage: 24V DC (designated by the "-5" code)
- Mounting Style: Base Mounted (without a sub-plate unless ordered via variant -02 or -03)
- Electrical Entry: DIN Terminal with connector (designated by the "Z" code)
- Indicator & Protection: Built-in LED light and surge voltage suppressor
- Fluid: Compressed Air
- Operating Pressure Range: 0.1 to 0.7 MPa (Internal Pilot)
- Max Fluid/Ambient Temp: 50°C (122°F)
- Manual Override: Non-locking push style
Brand New SMC SY7340-5DZ 5-Port Pneumatic Solenoid Valve (SY7000 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Display: 7" TFT LCD screen with an 800 x 480 resolution and LED backlight.
- Processor & Memory: Dual-Core RISC ARM CPU with 128 MB RAM and 256 MB onboard flash memory.
- Power Supply: Wide input voltage range of 10.5 to 28 VDC with built-in power isolation.
- Software: Configured using the free EasyBuilder Pro programming software.
Brand New Weintek MT8072iP HMI Touch Panel (iP Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Output Voltage: 24V DC (manually adjustable from 24–28V DC via front potentiometer)
- Output Current: 10A at 24V (continuous output)
- Power Reserve: 20% PowerBoost (delivers up to 12A / 288W continuously at ambient temperatures up to +45°C)
- Input Voltage: Single-phase 115/230V AC with auto-select input, preventing mis-wiring damage
- Efficiency: Reaches up to 91.6% efficiency with low heat generation
- Physical Profile: Only 60mm wide, maximizing control panel space
- Connections: Heavy-duty screw clamp terminals
Brand New Puls CS10.241 Single-Phase DIN-Rail Power Supply (DIMENSION C-Line Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Display Resolution: 640 × 480 (VGA), 76 PPI
- Signal Interface: Parallel RGB (1 channel, 6-bit), using a 31-pin connector
- Display Colors: 262K (6-bit)
- Brightness / Contrast: 250 cd/m² typical brightness with a 300:1 contrast ratio
- Viewing Angle: 70/70/40/70 (Left/Right/Up/Down)
- Operating Voltage: 3.3V or 5.0V power supply
- Original Backlight: Dual Cold Cathode Fluorescent Lamps (CCFL) with an integrated inverter
- Surface Treatment: Anti-glare treatment to reduce reflections in harsh shop floor environments
- LED Conversions: It is highly common to field-upgrade the display using third-party LED retrofit kits. Replacing the old CCFL bulbs with solid-state LED strips dramatically increases the longevity (often past 100,000 hours), improves energy efficiency, and removes the need for high-voltage CCFL inverters.
Brand New Sharp LQ10D368 Industrial TFT-LCD Display Module (LQ10D Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Number of Points: 16 digital outputs.
- Rated Voltage: 24 VDC (Operating load range of 15.0 to 28.8 VDC).
- Maximum Current: 0.5 A per point, capped at a maximum of 4 A total per unit.
- ON/OFF Response Time: 0.5 ms maximum OFF-to-ON delay / 1.0 ms maximum ON-to-OFF delay.
- Connection Method: 1-wire connection layout using a detachable push-in (spring-clamp) terminal block.
- Protection: Short-circuit protected outputs.
- Refreshing Methods: Supports Free-Run, Standard Speed, and Synchronous I/O refreshing (synchronizes directly with the controller cycle when connected via EtherCAT).
Brand New Omron NX-OD5256 Digital Transistor Output Unit (NX Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Display Design: TFT widescreen display with LED backlighting
- Screen Diagonal: 12 inches
- Resolution: 1280 x 800 pixels
- Color Depth: 65,536 colors
- Control Elements: Combined tactile keys (10 programmable function keys) and an analog resistive touchscreen
- Backlight Lifespan: 20,000 hours MTBF at 25 °C (100% dimmable)
- Rated Supply Voltage: 24 V DC
- Permissible Range: 19.2 V to 28.8 V DC
- Rated Current Consumption: 510 mA
- Power Consumption: ~12.2 W
- Network Interface: 1 x Industrial Ethernet/PROFINET interface (RJ45 port)
- USB Interface: 1 x USB port (supports system expansion or data archiving up to 16 GB)
- Supported Protocols: PROFINET, TCP/IP, DHCP, SNMP, DCP, LLDP, MODBUS TCP/IP, and EtherNet/IP
- Configuration Software: WinCC Basic V13 or STEP 7 Basic V13 (TIA Portal) and higher
- Enclosure Material: Durable plastic housing
- Protection Class: IP65 dust/water protection on the front side
- Mounting Positions: Supports both vertical (portrait) and horizontal (landscape) installation layouts
- Dimensions: 330 mm x 245 mm x 60 mm
- Weight: 2.16 kg
Brand New Siemens 6AV2123-2MB03-0AX0 HMI Basic Panel (SIMATIC KTP1200 Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Module Type: Failsafe Digital Safety Input Module
- Digital Inputs: 4 independent safety inputs (I0 to I3), operating at 24 V DC / 6 mA
- Digital Outputs: 2 test pulse transistor outputs (T0 & T1), rated at 24 V DC / 0.25 A
- Operating Voltage: 16.8V DC to 30V DC (24 V DC Nominal)
- Environmental Limits: 0°C to 60°C operating temperature; up to 2000 m permanent operating height
- Dimensions: 76 mm (H) x 12.6 mm (W) x 60.2 mm (D)
- Protection Class: IP20 enclosure level protection
- Supplier: Condition Base Price (USD) Delivery Details
Brand New Pilz 312200 Failsafe Digital I/O Module (PSSu Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Display Capacity: 8 lines of text, 240 x 160 pixels resolution.
- Environmental Rating: IP54 protection (dust and splash resistant, ideal for door mounting on electrical enclosures).
- Operating Temperature: -15°C to 50°C (+5°F to 122°F).
- Memory Capacity: Can save and download up to 4 distinct drive configuration files.
- Communication Interface: Built-in RS485 Modbus port.
- Compact & Machine Drives: ATV212, ATV312, ATV32, ATV320.
- High-Performance & Process Drives: ATV61, ATV71, ATV61Q, ATV71Q, and Altivar Lift.
- Door Mounting Kit: Part number VW3A1102 (IP54 bezel kit to securely anchor the keypad onto an enclosure face).
- Direct Drive Adapter: Part number VW3A1105 (needed if connecting the terminal directly to the front of certain drives without a remote bezel).
Brand New Schneider VW3A1101 Remote Graphic Display Terminal (Altivar Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Manufacturer: Nidec Corporation
- Model / Series: B35502-35DEL7 (BETAV TA450DC)
- Dimensions: 120 mm x 120 mm x 38 mm (12038 standard)
- Rated Voltage: 12V DC
- Current Draw: 1.40A (Note: Some variants label 1.54A)
- Power Consumption: 16.8 Watts
- Fan Speed: 4,000 to 4,200 RPM
- Maximum Airflow: 160 CFM
- Static Pressure: 0.883 in H₂O
- Acoustic Noise: 56.5 dBA
- Bearing Type: Dual Precision Ball Bearings
- Housing Material: PBT Plastic (UL94V-0 flammable rating)
- Black Wire: Ground (GND) (-)
- Red Wire: Power (12V) (+)
- Yellow or White Wire: Tachometer / RPM Signal (Sensor)
- Blue Wire: PWM Speed Control Input
- Dell Part Numbers: D8794, 0D8794, PP749-A00
- Common Applications: Dell Precision 390, T7500 workstations, and 12cm high-density server chassis.
Brand New NIDEC B35502-35DEL7 Axial Server Cooling Fan (TA450DC Series). In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
