Showing 209–224 of 296 results
-
REQUEST A QUOTE
- Channels: 4 analog inputs and 2 analog outputs (combination module).
- Signal Formats: Supports 0–10 VDC, ±10 VDC, 0–20 mA, and 4–20 mA voltage and current ranges.
- Resolution: 12-bit resolution ensuring dependable processing accuracy.
- Physical & Industrial Specs: Includes screw terminal connections, an IP20-rated enclosure, and Class I Division 2 certification for hazardous areas.
- Temperature Range: Operates reliably between -25°C and 65°C.
IDEC FC6A-L06A1 Analog Combo Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Output Specifications: Relay outputs rated at 2A per point (240V AC / 30V DC).
- Terminal Type: Removable screw terminals.
- Environmental Limits: Operating temperature range from -25°C to 65°C.
- Certifications: IP20 rated, CE marked, UL listed, TUV certified, and approved for Class I Division 2 hazardous locations.
IDEC FC6A-M08BR1 Digital I/O Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Module Type: Digital Mixed I/O Expansion Module
- Power Supply: 24V DC
- Total Channel Count: 24 channels (16 inputs / 8 outputs)
- Digital Inputs: 16 inputs (24V DC)
- Digital Outputs: 8 relay outputs
- Terminal Type: Spring-clamp / pluggable terminal blocks
- Environmental Protection: IP20 rated
- Operating Temperature: -10°C to 55°C
- Certifications: CE marked, cULus certified
IDEC FC6A-M24BR1 Digital I/O Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Module Type: Digital Input Module
- Inputs: 8 points, operating at 24V DC
- Connection Type: Removable screw terminal block for easy wiring and maintenance
- Operating Temperature: Wide temperature range of -25°C to 65°C
- IP Rating: IP20 (finger-safe protection)
- Certifications: CE, UL, and TUV certified
- Hazardous Locations: Rated for Class I Division 2 environments
IDEC FC6A-N08B1 Digital Input Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Input Points: 16 points (16 points / 1 common)
- Rated Input Voltage: 24V DC (Sink/Source input signal)
- Input Voltage Range: 0 to 28.8V DC
- Rated Input Current: 7 mA per point at 24V DC
- Terminal Type: Removable 3.81mm pitch, 10-pin, screw fastened
- Turn ON / OFF Delay: 4.1 ms / 4.1 ms
- Input Impedance: 3.4 kΩ
- IP Rating: IP20 (finger-safe protection)
- Operating Temp: -25°C to 65°C
- Safety & Standards: CE Marking, UL Certification, and TÜV Certification.
IDEC FC6A-N16B1 Digital Input Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Input Capacity: 16 digital inputs (16 inputs / 1 common)
- Rated Voltage: 24V DC (supports both Sink or Source configurations)
- Connection Type: MIL connector terminal (requires a compatible MIL cable/terminal block setup)
- Operating Temperature: -25°C to 65°C
- IP Rating: IP20 (dust protection, indoor/enclosure use)
- Certifications: CE marked, UL listed, TUV certified, and rated for Hazardous Locations (Class I Division 2)
IDEC FC6A-N16B3 Digital Input Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Input Count: 32 digital inputs (configured as 16 inputs per common / 1 common).
- Input Voltage: 24V DC.
- Input Type: Sink/Source selectable.
- Connection Interface: MIL-style rectangular connector.
- Operating Temperature: Suitable for extreme environments, ranging from -25°C to 65°C.
- Mounting: Heavy-duty DIN rail mount.
- Certifications: CE marked, UL listed, TUV certified, and rated for Class I Division 2 hazardous locations.
- Ingress Protection: IP20 rated.
IDEC FC6A-N32B3 Digital Input Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Channels: 2 independent analog inputs
- Signal Ranges: 0–10V DC voltage or 0–20mA / 4–20mA current
- Resolution: 12-bit (digital value range of 0 to 4095)
- Compatibility: Primarily used with IDEC FT1A SmartAXIS Touch (14 I/O models) and MicroSmart FC6A PLC series
- Certifications: CE and cULus approved for industrial environments
IDEC FC6A-PJ2A Analog Input Cartridge (MicroSmart FC6A).
-
REQUEST A QUOTE
- Output Points: 8 points (Normally Open)
- Output Type: Relay
- Maximum Current: 2A per point (with a maximum of 7A per common terminal)
- Rated Load Voltage: 240V AC / 30V DC (Resistive)
- Terminal Type: Removable M3 screw terminal block
- Mounting: Standard 35mm DIN rail
- Operating Temperature: -25°C to +65°C
IDEC FC6A-R081 Relay Output Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Output Type: 1NO (Normally Open) Relay
- Number of Outputs: 16 points (8 points per common x 2 commons)
- Maximum Load Current: 2A per point / 8A per common
- Rated Load: 240V AC (2A), 30V DC (2A)
- Terminal Style: Removable 3.81mm pitch screw terminals
- Operating Temperature: -25°C to 65°C
- Certifications: CE, UL, TUV, Class I Division 2 (Hazardous Locations)
- Electrical / Mech Life: 100k operations min (rated load) / 20M operations min (no load)
IDEC FC6A-R161 Relay Output Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Module Type: Digital Output Expansion
- Output Type: Transistor Sink (Sinking layout)
- Number of Outputs: 8 points
- Rated Voltage: 24V DC
- Current Capacity: 0.3A maximum per point
- Connection Type: Removable Screw Terminals
IDEC FC6A-T08K1 Transistor Output Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Specification Attribute: Details
- Module Type: Digital Output Expansion Module
- Number of Outputs: 16 points
- Output Type: Transistor Source (PNP)
- Rated Supply Voltage: 24V DC
- Current Rating: 0.3A per point
- Terminal Type: Removable / Pluggable Screw Terminal
- Mounting Type: 35mm DIN Rail
- IP Rating: IP20
- Operating Temperature: -25°C to 65°C (-13°F to 149°F)
IDEC FC6A-T16P1 Transistor Output Module (MicroSmart FC6A).
-
REQUEST A QUOTE
- Product Type: Programmable Logic Controller (PLC) CPU Module
- Series: MicroSmart (All-in-One CPU)
- I/O Capacity: 16 integrated I/O points
- Inputs: 9 digital inputs (24V DC)
- Outputs: 7 relay outputs (240V AC / 30V DC, 2A general/resistive, 7A common)
- Operating Line Voltage: 100-240V AC
- Mounting Style: DIN Rail / Panel Mount
- Operating Temperature: Up to 55°C (65°C under de-rating conditions)
- Programming Software: IDEC WindLDR
IDEC FC6B-C16R1A PLC CPU Module (MicroSmart Series).
-
REQUEST A QUOTE
- I/O Capacity: 40 Embedded I/O points (typically divided into 24 inputs and 16 outputs).
- Power Supply: 24V DC operating voltage.
- Output Type: Transistor Source (PNP).
- Termination Style: Screw Terminal block connections.
- Hardware Ports: Built-in USB Mini-B port for easy programming and maintenance.
- Memory & Performance: Offers 384KB program capacity, 1024 timers, and 56,000 data registers.
- Industrial Approvals: Built to handle harsh environments with an IP20 rating, Class I Division 2 hazardous location certification, CE marking, and UL listing.
- Temperature Range: Built for extreme environments with an operating temperature range of -25°C to 65°C.
IDEC FC6B-C40P1C PLC CPU Module (MicroSmart FC6B).
-
REQUEST A QUOTE
- I/O Capacity: 40 built-in I/O points (typically split as 24 inputs and 16 relay outputs).
- Power Supply: 100 to 240V AC broad-range voltage input.
- Output Type: Mechanical Relay, providing isolated, robust current switching.
- Industrial Connectivity: Integrated support for Modbus TCP and RTU protocols alongside embedded Ethernet and serial communication capabilities.
- Data & Memory: Features data logging to an embedded SD memory card slot and an integrated web server for remote monitoring.
IDEC FC6B-C40R1A PLC CPU Module (MicroSmart FC6B).
-
REQUEST A QUOTE
- Product Line: ClassicLine 4DI-Y
- Digital Inputs: 4 x PNP
- Network Address: Extended Addressing Mode
- Connection Type: 4 x M12 Connectors
- Ingress Protection: IP67
- Mean Time to Failure: 405 Years
- Quick Mounting Technology: Features toolless, rapid insulation-piercing contacts designed specifically for standard AS-i flat yellow cables. The lower mounting section holds the cable firmly without screws.
- Flexible Orientation: The internal routing allows the flat bus cable to exit or enter from three different selectable directions, eliminating tight bend radius issues in compact control boxes or machine profiles.
- On-board Diagnostics: Outfitted with high-visibility, powerful status LEDs:
IFM AC5215 AS-i Input Module (AS-Interface).
