- Nominal Voltage: AC 100…240 V (50/60 Hz)
- Nominal Torque: 10 Nm
- Control Type: Open-close (On-Off), 3-point
- Power Consumption: 2.5 W (In operation) / 0.6 W (At rest) / 5.5 VA (Wire sizing)
- Running Time: 150 s / 90°
- Angle of Rotation: Max. 95° (Adjustable mechanical end stops)
- Direction of Motion: Selectable with switch 0 (CCW) / 1 (CW)
- Enclosure Rating: IP54 / NEMA 2
- Mechanical Connection: Universal shaft clamp 8…26.7 mm
- Electrical Connection: Cable 1 m, 3 x 0.75 mm²
Brand New BELIMO NM230A Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Supply Voltage: AC/DC 24 V (50/60 Hz)
- Torque: 10 Nm (90 in-lb)
- Control Type: Open/Close or 3-point (floating control)
- Running Time: 150 seconds
- Angle of Rotation: Max. 95°, adjustable with mechanical end stops
- Enclosure Rating: IP54
- Manual Override: Pushbutton to disengage the gear train
- Actuator Model: Control Signal / Protocol
Brand New BELIMO NM24A Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Nominal Voltage: AC/DC 24 V (50/60 Hz)
- Operating Range: AC 19.2…28.8 V / DC 19.2…28.8 V
- Power Consumption (Operating): 1.5 W
- Power Consumption (Rest Position): 0.2 W
- Wire Sizing Capacity: 3.5 VA
- Connection (Supply/Control): 1-meter PVC cable, 3 x 0.75 mm²
- Torque Motor: 10 Nm
- Control Type: Open/close or 3-point
- Integrated Auxiliary Switch: 1 x SPDT (adjustable 0…100%, switching capacity 1 mA…3 A, AC 250 V)
- Direction of Rotation: Reversible (selectable with switch 0 for CCW / 1 for CW)
Brand New BELIMO NM24A-S Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque: 10 Nm
- Nominal Voltage: AC/DC 24 V (50/60 Hz)
- Control Input: Modulating DC 2…10 V (Operating range) / DC 0…10 V input signal
- Position Feedback: DC 2…10 V for electrical position indication
- Running Time: 150 seconds (constant for 90° rotation)
- Power Consumption: 2 W during operation / 0.4 W in rest position / 4 VA wire sizing
- Protection Rating: IP54 / NEMA 2
- Fail-Safe: Non fail-safe (stays in its last position upon power loss)
- Manual Override: Integrated push-button to disengage the gear train for manual adjustment
Brand New BELIMO NM24A-SR Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Torque: 8 Nm (70 in-lb), suitable for air damper sizes up to approximately 2 m².
- Running Time: Ultra-fast 4 seconds for a 90° rotation.
- Nominal Voltage: AC/DC 24 V (50/60 Hz).
- Control Type: Open/Close (Note: It is not designed for 3-point floating applications).
- Power Consumption: 13 W during operation / 2 W at rest.
- Enclosure Rating: IP54 (NEMA 2 equivalent).
- Simple Direct Mounting: Easily fastens to a universal shaft clamp and includes an anti-rotation strap.
- Manual Override: Features a self-resetting push-button that disengages the gear train for manual adjustment.
- High Operational Safety: The motor is completely overload-proof, requires no end-limit switches, and stops automatically when it hits a mechanical end stop.
Brand New BELIMO NMQ24A Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Running Time: 4 seconds for a 90° rotation, making it ideal for processes requiring rapid air volume adjustments.
- Torque: 8 Nm (Newton meters), capable of driving air dampers up to approximately 1.5 m² in size.
- Nominal Voltage: AC/DC 24 V (50/60 Hz).
- Control Type: Modulating 2…10 V DC control signal.
- Position Feedback: 2…10 V DC for precise system monitoring.
- Power Consumption: 13 W while running, 2 W in holding mode, and 23 VA for wire sizing.
- Enclosure Rating: IP54 and NEMA 2, providing solid environmental protection.
- Shaft Connection: Equipped with a universal shaft clamp supporting round and square shafts measuring 8…26.7 mm.
- Manual Override: Includes a lockable, self-resetting push-button to disengage the gear train for manual damper adjustment.
- Rotation Control: Features a selectable direction of motion switch (0/1) and adjustable mechanical end stops to limit the maximum angle of rotation (up to 95°).
Brand New BELIMO NMQ24A-SR Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Nominal Resistance: 10 kΩ
- Tolerance: ±5%
- Linearity: ±2%
- Resolution: Min. 1%
- Loading Capacity: Max. 1 W
- Enclosure Rating: IP54 (guarantees protection against dust and moisture splashes)
- Electrical Connection: Pre-wired 1-meter (3 ft), 3-conductor, halogen-free cable
- Housing Color: Grey (used for visual differentiation from other resistance variations like the 140 Ω, 500 Ω, or 2800 Ω models).
- Closed-Loop Monitoring: Directly feeds real-time resistance measurements back to an automation controller to indicate exact damper blade or valve position.
- Simple Mechanical Coupling: Mounts directly over the actuator spindle via an integrated shaft clamp mechanism, requiring no complex linkages.
Brand New BELIMO P10000A Potentiometer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Nominal Resistance: 2.8 kΩ (2800 ohms) with a ±5% tolerance.
- Loading Capacity: Max. 1 W.
- Connection: Pre-wired with a 1-meter (3 ft) 3-wire halogen-free cable.
- Environmental Protection: Enclosed in a grey housing rated for IP54 (NEMA 2 / UL Enclosure Type 2).
Brand New BELIMO P2800A Potentiometer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Nominal Resistance: 500 Ω
- Tolerance: ±5%
- Linearity: ±2%
- Loading Capacity: Max. 1 W
- Enclosure Rating: IP54 (Dust & splash proof)
- Electrical Connection: 1-meter halogen-free cable (3 × 0.75 mm²)
- Closed-Loop Feedback: Provides a continuous resistive signal to commercial proportional temperature controllers to indicate exact valve or damper positioning.
- Remote Position Indication: Routes resistance changes directly to external electric meters or building automation system (BAS) monitoring panels.
- Parallel Actuator Control: Serves as a master positioner to synchronize the operation of multiple slave actuators linked across the same network.
Brand New BELIMO P500A Potentiometer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Auxiliary Switch: 1x SPDT (Single Pole Double Throw), adjustable from 0 to 100% across the full range of rotation.
- Switching Capacity (AC): 1 mA to 3 A (0.5 A inductive) at max AC 250 V.
- Switching Capacity (DC): 1 mA to 0.5 A (0.2 A inductive) at DC 5 V to DC 110 V.
- Connection Type: Pre-wired cable, 1 meter (approx. 3 feet), 3x 0.75 mm².
- Wiring Colors: S1 = Violet, S2 = Red, S3 = White.
- Mounting: Attaches directly onto the spindle clamp of damper actuators or the position indicator of rotary actuators.
- Enclosure Rating: IP54, NEMA 2, UL Enclosure Type 2.
- Protection Class: IEC/EN II (reinforced insulation).
- Ambient Temperature: -22°F to 122°F (-30°C to 50°C).
Brand New BELIMO S1A Auxiliary Switch. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Switching Capacity: 3A (0.5A inductive) at 250 VAC max
- Contacts: 2x SPDT (Single Pole Double Throw)
- Switching Points: 0% to 100% fully adjustable rotation range via internal dials
- Electrical Connection: Pre-wired integrated 1-meter (3 feet) cable, 6 x 0.75 mm²
- Operating Temperature: -30°C to 50°C (-22°F to 122°F)
- Prepare the Actuator: Remove the clear position indicator ring and its underlying black plastic mounting bracket from the face of the actuator.
- Zero the Actuator: Manually press the gear release button and rotate the clamp fully counter-clockwise against the mechanical stop.
- Set Switching Points: Re-attach the driver disk mechanism. Use a flat-head screwdriver to align the indicator arrows on the internal dials to the exact angular points where you want your switches to trip.
- How To: Install the Belimo S2A Auxiliary Switch
Brand New BELIMO S2A Auxiliary Switch. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Switch Type: 2x SPDT
- Electrical Rating: 3 A (0.5 A inductive) @ 250 VAC max
- Enclosure Rating: IP54 / NEMA 2
- Connection: 3 ft (1 m) pre-wired cable, 6x 0.75 mm² (18 AWG)
- Ambient Temperature: -22°F to 122°F (-30°C to 50°C)
- Spring Return Actuators: LF, TF, NF..A, SF..A, NF-US, AF-US
- Fire & Smoke Actuators: FSNF, FSAF, BLF, BF
- How To: Install S1A and S2A Auxiliary Switches on Actuators
- How To: Install the Belimo S2A Auxiliary Switch
Brand New BELIMO S2A-F Auxiliary Switch. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Power & Voltage: 24 V AC/DC (50/60 Hz), with a power consumption of 5 W during operation and 3 W in rest position.
- Control & Feedback: Modulating control input signal of 0–10 VDC, operating range of 2–10 V, and mechanical position feedback of 2–10 V.
- Torque: 20 Nm (Newton-meters) for both motor and spring-return functions.
- Running Time: 140 to 150 seconds for motor operation, and a rapid emergency spring-return fail-safe time of less than 20 seconds.
- Mechanical Interface: Universal shaft clamp compatible with damper spindles ranging from 10 mm to 25.4 mm.
- Environmental Protection: IP54 enclosure rating (NEMA 2) with a permissible ambient temperature range of -30°C to 50°C.
- Fail-Safe Operation: When power is interrupted, the internal mechanical spring automatically drives the connected air damper back to its designated safe position (either fully open or fully closed depending on mounting orientation).
- Manual Override: Features an integrated locking switch and manual crank that allows for temporary positioning of the damper when the system is unpowered.
- Angle of Rotation: Adjustable up to a maximum angle of 95° using integrated mechanical end stops.
- Maintenance: Overload-protected and completely maintenance-free with a rated service life of at least 60,000 fail-safe positions.
Brand New BELIMO SF24A-SR Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Power Supply: 24V AC/DC (50/60 Hz)
- Power Consumption: 0.3 W (running) / 1 VA (for wire sizing)
- Output Control Signal: 2 to 10 VDC or 0.5 to 10 VDC (selectable via an internal slider switch on the PCB)
- Mounting Type: Surface mounted
- Housing Rating: Included NEMA 2 (IP54 protected enclosure)
- Wiring Connection: Screw terminals handling up to 14 AWG max
- Remote Control: Serves as a manual remote dial to position a proportional actuator from 0 to 100% of its rotation angle.
- Minimum Positioner / Limit: Can act as a "higher-of-two" signal selector. When wired inline with a primary controller, it ensures the actuator never closes past the minimum position set on the dial.
- Mechanical Limits: Includes adjustable mechanical stops beneath the turn-knob to physically limit the dial's rotation range.
- Design Data: Design Data. View Project Lists Duplicate with Configuration Continue Shopping. Bookmark this page. Share. Details; …
Brand New BELIMO SGA24 Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Supply Voltage: AC/DC 24 V (50/60 Hz)
- Power Consumption: 0.3 W (Running) / 1 VA (Wire sizing)
- Control Signal Output (Y): Selectable 2…10 VDC or 0.5…10 VDC via internal slide switch
- Control Range: 0 to 100% of the actuator's rotation angle
- Mounting Style: Flush, front-panel mounting (Note: If you need surface mounting, look for the Belimo SGA24)
- Protection Class: IP40
- Wiring Terminals: Supports up to 1.5 mm² (14 AWG) wire max
- Remote Manual Control: Turning the manual rotary knob outputs a proportional signal directly to the actuator to adjust airflow manually. The physical rotation range of the knob can be limited mechanically using adjustable physical stops.
- Minimum Positioner Limit: When wired alongside an automatic master controller, the SGF24 acts as a "higher of two signal" selector. Whichever signal is greater—the automated controller or the manual positioner—is sent to the actuator, ensuring a minimum damper position is strictly enforced (e.g., for fresh air requirements).
- OEM Part Cross-References: It is also distributed directly through equipment manufacturers, such as under Greenheck Product #381657.
Brand New BELIMO SGF24 Actuator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Nominal Voltage: AC 100…240 V (50/60 Hz)
- Torque: 20 Nm
- Control Type: Open/close, 3-point
- Power Consumption: 2.5 W (In operation) / 0.6 W (In rest)
- Running Time: 150 s / 90°
- Damper Spindle Size: 10…20 mm (universal clamp)
- Protection Rating: IP54
- Connection: 1m PVC cable
- Simple Direct Mounting: Attaches easily onto a standard damper spindle utilizing a universal shaft clamp. It is supplied with an anti-rotation mechanism to ensure high operational stability.
- Manual Override: The integrated gear train can be temporarily or permanently disengaged by pressing a self-resetting push-button, allowing for seamless manual damper adjustment.
Brand New BELIMO SM230A Actuator. In stock — ships worldwide within 5-10 days.
