• Processor: Intel Atom N270 clocked at 1600 MHz (533 MHz Front Side Bus, 512 kB L2 Cache)
• Chipset: Intel 945GME with integrated Intel GMA 950 graphics
• Memory: 2x DDR2 slots supporting SO-DIMM RAM
• System BIOS: AMI BIOS
• Storage Interface: EIDE standard
• Power Input: 24 VDC
• Certifications: CE and UKCA compliant for rigorous industrial applications

B&R 5PC600.X945-00 CPU Board (APC600).

• Processor: Intel® Core™ Duo L2400 running at 1.66 GHz (Dual-core, 667 MHz Front Side Bus, 2 MB L2 cache).
• Chipset: Intel® 945GME.
• Memory Support: 2x slots for SO-DIMM DDR2 modules, allowing a maximum expansion of 3 GB RAM.
• Graphics: Integrated Intel® GMA 950.
• Networking: Equipped with a Realtek Ethernet Controller RTL8111B.
• System BIOS: AMI BIOS.
• Model Number: Processor Type

B&R 5PC800.B945-00 CPU Board (APC810).

• Processor: Intel Core2 Duo L7400
• Clock Speed: 1.5 GHz (Dual-core, 667 MHz FSB, 4 MB L2 cache)
• System Chipset: Intel 945GME
• Memory Support: 2x SO-DIMM DDR2 slots (Supports up to a maximum expansion of 3 GB RAM)
• Integrated Graphics: Intel GMA 950
• Network Controller: Realtek RTL8111C Gigabit Ethernet Controller
• System BIOS: AMI BIOS
• Mandatory Firmware: Firmware updates for this specific 945GME-2 architecture series require explicit B&R BIOS Upgrades to resolve initialization delays and manage power-saving configurations like SpeedStep.
• System Integration: Engineering data and macros can be directly imported using the B&R EPLAN P8 Master Data Package for industrial control cabinet drafting.

B&R 5PC800.B945-11 CPU Board (APC810).

• Processor (CPU): Intel® Core™2 Duo U7500 clocked at 1.06 GHz (Dual-core, 533 MHz FSB, 2 MB L2 cache).
• Chipset: Intel® 945GME.
• Graphics: Integrated Intel® GMA 950.
• Memory Support: 2x slots for SO-DIMM DDR2 modules, allowing a maximum system expansion of up to 3 GB.
• Network Controller: Realtek Ethernet Controller RTL8111C.
• System BIOS: AMI BIOS.
• Mainboard Integration: This specific board functions seamlessly inside base units like the 5PC810.SX01-00 system housing.
• Firmware Updates: B&R distributes critical BIOS updates under the 5PC800.B945-1x family baseline. Keeping the BIOS updated is often mandatory to fix legacy boot issues (such as resolving initialization conflicts with Windows PE environments).

B&R 5PC800.B945-12 CPU Board (APC810).

• Processor (CPU): Intel Celeron G3900E dual-core processor
• Clock Speed: 2.4 GHz active cooling / 1.7 GHz passive cooling
• Chipset: Intel HM170 chipset
• Graphics: Integrated Intel HD Graphics 510 (950 MHz) with resolution capabilities up to WUXGA (1920×1200)
• Memory Capacity: 2x DDR4 RAM slots supporting up to 32 GB
• Storage Control: 4x SATA mass memory management channels
• Additional Features: Battery-buffered Real-Time Clock (RTC)
• Heat Sink: A heat sink must be purchased separately based on whether you are deploying an active or passive cooling infrastructure.
• System Unit Requirement: To properly support this Intel Skylake architecture CPU board, using the latest version of the hardware upgrade for the 5PC910.SX0x-00 system unit is mandatory.
• Software Compatibility: Requires B&R Automation Studio version 4.3.3 and Automation Runtime 4.33 or higher. It features built-in support for the B&R Hypervisor beginning with Automation Studio V4.4.

B&R 5PC900.TS17-02 CPU Board (APC900).

• Processor: Intel Core i7-3612QE Quad-Core clocked at 2.1 GHz with a 6 MB L2 cache.
• Chipset: Intel QM77 chipset.
• Memory: 2x DDR3 SO-DIMM slots supporting a maximum system memory capacity of up to 16 GB RAM.
• Graphics: Integrated Intel HD Graphics 4000, delivering output resolutions up to WUXGA (1920×1200).
• Firmware: AMI BIOS (UEFI).
• Storage Interface: Supports up to 4x SATA mass memory connections.
• Features: Features a plug-in design structure and a battery-buffered Real-Time Clock (RTC).

B&R 5PC900.TS77-01 CPU Board (APC910).
