Showing 1137–1152 of 2086 results
-
- Manufacturer: HITECH
- Model / Part Number: PWS6600T-P
- Screen Size & Type: It features a 5.7-inch Color TFT LCD screen.
- Resolution: The display resolution is 320 x 240 pixels, which makes text and basic machine graphics easy to read.
- Touchscreen: It uses an analog touch screen panel for user input.
- Memory: It comes built with 4MB of Application Flash ROM and 512KB of RAM to store machine screens and pathways.
- Power Requirements: It runs on 24V DC power and consumes less than 20 watts.
- Durability: It has an IP65 rated front panel, meaning it is protected against dust and low-pressure water splashes commonly found in factory environments.
-
- Manufacturer: HITECH
- Model / Part Number: PWS6620S-P
- Display Size: 5.7 inches
- Display Type: STN LCD
- Resolution: 320 x 240 pixels
- Hardware Keys: 1 menu key and 5 function keys
- Serial Interfaces: RS-232, RS-422 and RS-485
- Front Protection: IP65
- Configuration Software: ADP6
-
- Manufacturer: HITECH
- Model / Part Number: PWS6620T-N
- Display Type: 5.7-inch TFT color touch screen display.
- Resolution: 320 x 240 pixels.
- Color Depth: 64,000 colors.
- Input Interface: Analog resistive touch screen.
- Communication Ports: 2 Serial COM ports supporting RS232, RS422, and RS485 communication protocols.
- Protection Rating: IP65 rated front panel, making it dust-tight and resistant to water splashes in tough factory environments.
- Software: This panel is traditionally programmed using ADP software (often ADP6), which is the standard software suite for the older Hitech PWS series.
-
- Manufacturer: HITECH
- Model / Part Number: PWS6620T-P
- Screen Size: 5.7 inches diagonally.
- Display Type: Color TFT LCD with 64,000 colors.
- Resolution: 320 x 240 pixels (QVGA).
- Backlight: Long-lasting LED backlight (lasts up to 50,000 hours).
- Front Protection: IP65 rated, meaning it is dust-tight and protected against water splashes.
-
- Manufacturer: HITECH
- Model / Part Number: PWS6700T-N
- Display: 7-inch color TFT LCD screen.
- Resolution: 800 x 480 pixels.
- Colors: 64K colors.
- Control Layout: Analog resistive touch screen along with 1 Menu key and 6 user-defined function keys (F1–F6).
- Power Supply: 24V DC (±15%), consuming under 24 Watts.
- Memory: 8 MB Flash ROM, 16 MB RAM, and 512 KB battery-backed memory for data/recipes.
- Data Expansion: Includes a CompactFlash (CF) card slot.
- Hardware Control: 32-bit RISC processor.
- Dimensions: External physical size is 231.0 x 176.0 x 46.8 mm, with a panel installation cutout size of 220.8 x 165.8 mm.
- USB: Features 2 USB Host ports and 1 USB Device port.
-
- Manufacturer: HITECH
- Model / Part Number: PWS6710T-N
- Display: A 7-inch Color TFT LCD screen.
- Resolution: 800 x 480 pixels for crisp screen details.
- Colors: Supports up to 64,000 colors.
- Network Interface: The "-N" at the end of the model name stands for the Network tier level.
- Communication Ports: Includes 3 COM communication ports, 2 USB Host ports, 1 USB Device port, and a CF (CompactFlash) memory card slot.
- Front Protection: The front screen panel has an IP65 protection rating.
-
REQUEST A QUOTE
- Specification Attribute: Details & Metrics
- Display Size: 7.5 inches
- Display Type: Color STN LCD
- Resolution: 640 x 480 pixels (VGA)
- Color Support: 64K Colors
- Processor: 32-bit RISC CPU
- Backlight Type & Life: CCFT Backlight / ~58,000 Operating Hours
- Memory Capacity: 8MB Application Flash ROM / 512KB Data/Recipe Storage
- Expansion Storage: CompactFlash (CF) Card Slot
- Physical Interfaces: 1x Menu Key, 6x User-Defined Function Keys (F1-F6)
HITECH PWS6800C-P Human-Machine Interface (HMI) (PWS Series).
-
- Manufacturer: HITECH
- Model / Part Number: PWS6A00T-N
- Display Type: Color TFT LCD
- Housing Size: 10.4 inches (diagonal)
- Resolution: 640 x 480 pixels
- Colors: 64K colors
- Brightness: 450 cd/m²
- Backlight: LED (with a lifetime of around 50,000 hours)
- Touchscreen: Analog resistive
- Processor: 32-bit RISC CPU
- Flash Memory: 8 MB
- System RAM: 512 KB
- Operating Software: Configured via H-Designer software
- Peripherals: Features USB host and device ports for data transfers
-
REQUEST A QUOTE
- Transmission Type: Half-duplex two-way transmission
- Transmission Method: Pulse modulation via Near-Infrared LED
- Transmission Time: 40 msec or less
- Verification Method: Parity check
- Power Source: 24VDC (Available range: 10 to 30VDC)
- Current Consumption: 100mA Max
- Output Type: NPN Open-collector (30V, 50mA or less)
- Ambient Temperature: -10 to +50°C
- Optical Communication: Replaces physical trailing cables or Wi-Fi networks in harsh industrial environments prone to radio frequency interference.
- Industrial Environment Tolerance: Features high resistance to ambient illumination (up to 4,000 lux) and robust vibration/impact protection to handle heavy factory floor dynamics.
HOKUYO DMS-HB1-N Optical Data Transmission Device (DMS Series).
-
REQUEST A QUOTE
- Component Type: Replacement Ultraviolet (UV) Flame Sensing Power Tube.
- Temperature Rating: 0°F to 250°F (-18°C to 121°C).
- Primary Applications: Industrial burners, commercial boilers, central furnaces, public ovens, and intense combustion systems.
- Country of Origin: United States (USA).
HONEYWELL 129464M UV Flame Sensing Tube (129464).
-
REQUEST A QUOTE
- Component Type: Replacement UV Power Sensing Tube with Base
- Operating Temperature: -40°F to +250°F (-40°C to +121°C)
- Dimensions: Height: 69 mm
- Diameter: 19 mm
- Weight: 0.038 kg (0.08 lbs)
- Tariff Code: 85408900
- Flame Amplifiers: Compatible with Honeywell R7849A/B UV flame amplifiers used in standard 7800 SERIES Burner Management Systems.
- Fuel Profiles: Engineered to monitor ultraviolet radiation from gas-, oil-, and coal-fired burners.
- High-Temperature Environments: If installing the companion primary detector in areas exceeding the baseline temperature limit, utilize specialized Honeywell F leadwires (Specification No. 32004766-003). This specialized wiring is continuously rated up to 400°F (250°C).
- Wiring Considerations: For non-high-temperature sections, utilize moisture-resistant No. 14 AWG wire rated for the peak ambient temperatures expected inside the burner enclosure.
HONEYWELL 129464N UV Flame Sensing Tube (129464).
-
REQUEST A QUOTE
- Operating Voltage: 24V AC (Lower functional limit: 19.20V AC).
- Control Signal: 0–10V DC modulating or proportional control.
- Positioning Force: 1600 N to 1800 N nominal force.
- Stroke / Nominal Travel: 40 mm.
- Operating Ambient Temperature: -10°C to 55°C.
- Alternative: Honeywell 24V Transformers
HONEYWELL AC24V1800N Damper Actuator (AC24V Series).
-
REQUEST A QUOTE
- Operating Voltage: 115 / 230 VAC (±10%), dual voltage selection
- Frequency: 50 / 60 Hz
- Temperature Rating: -40°F to +175°F (-40°C to +79°C)
- Enclosure Rating: NEMA 4 / IP66 (Dust and moisture resistant)
- Wiring Interface: Terminal block / Screw terminals
- Self-Check Mechanism: Oscillating shutter; cycles 12 times per minute
- Pressure Rating: Viewing window rated up to 20 psi (138 kPa)
- Dynamic Self-Checking: Features an internal, oscillating shutter mechanism that mechanically interrupts the path of UV radiation 12 times every minute. This constant cycling allows the flame safeguard system to verify that the UV sensor tube is functioning properly and hasn't failed in a dangerous "always-on" state.
- Flexible Positioning: Supports mounting horizontally, vertically, or at any intermediate angle. Note that faceplate alignment with integral locating reference points is mandatory to guarantee correct mechanical shutter movement.
- Dual Detector Parallel Wiring: In demanding or irregular flame-sighting conditions, two C7061A scanners can be wired completely in parallel to a single terminal. This significantly mitigates nuisance system shutdowns.
HONEYWELL C7061A1020 Flame Detector (C7061).
-
- Brand: Honeywell
- Model: C7061A1053
- Series: C7061A
- Detection method: Ultraviolet
- Self-checking: Yes
- Supply rating: 120 V AC, 50/60 Hz
- Pipe connection: 1 inch
- Lead length: 8 ft
- Ambient temperature: -40 to +175 °F
- Flame amplifier: R7861, as marked on detector
-
REQUEST A QUOTE
- Torque Rating: 5 Nm (44 lb-in), suitable for managing smooth, seal-less air damper applications up to approximately 10 sq. ft.
- Control Signal Types: Versatile triple-mode support including Modulating (analog signal), Floating (3-point), and ON/OFF (2-position).
- Nominal Voltage: 24 Vac/dc, 50/60 Hz.
- Rotation Stroke: 95° with a built-in rotation limiter and adjustable mechanical end limits.
- Runtime: 110 seconds at 50Hz or 90 seconds at 60Hz.
- Power Consumption: 5VA / 2W.
- Protection Class: IP54 rated for dust and splash protection.
- Shaft Mounting: Direct coupling for round shafts (8 to 16 mm) and square shafts (6 to 13 mm).
- Integrated Feedback: Provides a continuous voltage position feedback signal directly to the building automation system or PLC for real-time tracking of the exact damper angle.
- Auto-Calibration: Automatically runs an auto-calibration sequence upon power-cycling to map the mechanical limits before aligning to the control signal.
HONEYWELL CN7505A2001 Direct Coupled Damper Actuator (CN7505 Series).
-
REQUEST A QUOTE
- Manufacturer: Honeywell Sensing and Control
- Model / Series: GCP-33AN (GCP Series)
- Number of Poles: 3-Pole (Triple Pole)
- Amperage Rating: 10A
- Trip Mechanism: Electromagnetic Overcurrent Protection
- Form Factor: Subcompact (17.5 mm width per single pole)
- Mounting Standard: DIN Rail installation (IEC Standard compliance)
- Durability Ratings: Vibration: 15G | Mechanical Shock: 50G
- Secure Insulation Engineering: Terminal blocks are protected by structural walls to ensure that live electrical wiring is never exposed to external accidental contact.
- Intuitive Troubleshooting: Features highly visible, color-coded ON/OFF indicators paired with an integrated handle guard. These metrics allow floor technicians to rapidly identify operating trip states from a distance while preventing unintended manual flipping.
HONEYWELL GCP-33AN 10A Electromagnetic Circuit Protector (GCP Series).
