Showing 145–160 of 309 results
-
REQUEST A QUOTE
- Power Supply: 100~240VAC
- Digital Inputs: 6 points 24VDC (2 high-speed 200KHz, 2 medium-speed 20KHz, 2 medium-speed 5KHz)
- Digital Outputs: 4 points Relay
- Communication: 1 built-in RS-232 port (expandable up to 5 ports)
- Real-Time Clock (RTC): Built-in
- I/O Expandability: Not expandable (Fixed configuration)
- Wiring: 7.62mm fixed terminal block
FATEK FBS-10MCR2-AC Compact Advanced PLC Main Unit (FBs-MC Series).
-
- Manufacturer: FATEK
- Model / Part Number: FBS-10MCR2-D24
- Series: FBs
- Digital Inputs: 6 x 24 VDC
- Digital Outputs: 4 relay outputs
- Supply Voltage: 24 VDC
- Mounting: DIN rail
-
- Manufacturer: FATEK
- Model / Part Number: FBS-10MCT2-AC
- Total Input/Output (I/O) Points: 10 points total
- Digital Inputs: 6 points (24VDC)
- Digital Outputs: 4 points using NPN Transistors (Sink type)
- Power Supply: 100 to 240VAC line power
- Communication: 1 built-in RS-232 port (expandable up to 5 ports total)
- Hardware Features: Built-in Real-Time Clock (RTC / Calendar)
- Wiring: 7.62mm fixed terminal block
- FBs: Refers to FATEK's premier, high-performance PLC series.
- MC: "Main Control" unit, meaning it belongs to the advanced type with high-speed counting and positioning features.
- AC: Operates on standard alternating current electricity (100–240VAC).
-
- Manufacturer: FATEK
- Model / Part Number: FBS-10MCT2-D24
- Model Number: FBs-10MCT2-D24
- Product Type: Advanced Main Unit (MC Series)
- Power Supply: 24VDC (-D24)
- Total I/O Points: 10 Points
- Digital Inputs: 6 points 24VDC (2x 200KHz high speed, 2x 20KHz medium speed, 2x 5KHz medium speed)
- Digital Outputs: 4 points Transistor NPN (Sink type) (2x 200KHz high speed, 2x 20KHz medium speed)
- Communication: 1 built-in RS-232 port (expandable up to 5 ports via boards/modules)
- Real-Time Clock (RTC): Built-in calendar clock
- I/O Expandability: Non-expandable on this specific 10-point chassis
- Wiring Method: 7.62mm fixed terminal block
- Certifications: UL Certified / CE Certified
- FBs: Series name
- MC: Advanced Core (Main Unit)
-
- Manufacturer: FATEK
- Model / Part Number: FBS-14MAR2-D24
- Total I/O Points: 14 channels (Inputs + Outputs combined).
- Digital Inputs: 8 points (24VDC), where 4 of the points can handle higher-speed signals up to 10KHz.
- Digital Outputs: 6 points of Relay type (represented by the R in the model name).
- Power Supply: 24VDC operational power input (represented by the D24 suffix).
- Core Series Level: MA (Economy/Basic type core architecture).
- Expandability: On this specific 14-point model, the physical I/O layout is not expandable. You cannot click extra physical input or output expansion blocks onto the side of it.
- Communication: Features 1 built-in RS-232 or USB port for communication. This can be expanded up to 3 communication ports by using additional expansion boards.
- Time Tracking: Features an integrated real-time clock (RTC).
- Programming Software: Programmed via Fatek's standard computer software application, WinProladder.
-
- Manufacturer: FATEK
- Model / Part Number: FBS-14MAT2-D24
- Total I/O Points: 14 Points 8 Inputs / 6 Outputs
- Power Supply: 24V DC Indicated by the -D24 suffix
- Output Type: Transistor Output 6 points total (Sink / NPN type)
- Communication: 1 Built-in Port RS-232 interface
- Real-Time Clock: Integrated Built-in RTC
- Expandability: Non-expandable I/O points are fixed for MA basic units
- High-Speed: 2 points capable of up to 100KHz.
- Medium-Speed: 2 points capable of up to 20KHz.
- Standard-Speed: 4 points with a total shared capacity of 5KHz.
- FBs: Product series name (FBs SoC-based architecture).
-
- Manufacturer: FATEK
- Model / Part Number: FBS-14MCR2-AC
- Power Supply: Runs on a standard power range of 100~240VAC (50/60Hz, using about 21 Watts).
- Total I/O Points: It has 14 total input/output channels (8 digital inputs and 6 digital outputs).
- Digital Inputs: 8 points that run on 24VDC.
- Digital Outputs: 6 points made of physical electrical relays.
- Built-in Clock: Features a built-in Real Time Clock (RTC) / calendar to schedule events based on the actual time of day.
- Communication: Includes 1 built-in RS232 or USB port to connect to computers. You can expand this up to 5 total ports using extra plug-in modules (like Ethernet, RS485, or Wi-Fi).
- No Expansion Board Support: It is vital to note that the total number of physical inputs and outputs on this unit cannot be expanded later. If you run out of the 14 available pins, you will need to upgrade to a larger PLC model.
- Software Capability: Fatek PLCs support over 300 instructions. This allows programmers to build complex mathematical logic loops easily compared to older hardware.
-
- Manufacturer: FATEK
- Model / Part Number: FBS-14MCR2-D24
- Digital Inputs: 8 points (24V DC).
- Digital Outputs: 6 relay outputs
- Communication: 1 built-in RS-232 or USB port. It can expand up to 5 communication ports using extra add-on boards.
- Calendar: Includes a built-in Real-Time Clock (RTC) for scheduling timed events.
-
- Manufacturer: FATEK
- Model / Part Number: FBS-14MCT2-AC
- Total I/O Points: 14 channels
- Digital Inputs: 8 points (24VDC)
- High-speed: 2 points (200KHz)
- Medium-speed: 2 points (20KHz)
- Low-speed: 4 points (5KHz total)
- Digital Outputs: 6 points (Transistor outputs)
- High-speed pulse: 2 points (200KHz)
- Power Supply: 100~240VAC (indicated by the "-AC" suffix)
- Communication Ports: 1 built-in port (Port 0, choose between RS232 or USB). Expandable up to 5 ports total using additional modules.
- Clock: Built-in Real-Time Clock (RTC) / Calendar.
- Wiring: 7.62mm detachable terminal block.
- FBs: The high-performance series name from Fatek.
- MC: Advanced Main Unit classification.
- AC: Operates on standard AC alternating current power (100-240V AC).
-
- Manufacturer: FATEK
- Model / Part Number: FBS-14MCT2-D24
- Series: FBs
- Controller Type: MC high-performance main unit
- Digital Inputs: 8 x 24 VDC
- High-Speed Input Channels: 2 x 200 kHz, 2 x 20 kHz, 4 x 5 kHz
- Digital Outputs: 6 transistor outputs
- High-Speed Output Channels: 2 x 200 kHz and 4 x 20 kHz
- Built-in Communication: 1 RS-232 or USB port
- Real-Time Clock: Built in
-
- Manufacturer: FATEK
- Model / Part Number: FBS-16RTD
- Total Channels: 16 channels, meaning it can connect to 16 separate sensors.
- Wiring Method: Uses a 3-wire connection for each sensor. This is helpful because it automatically ignores the natural electrical resistance of long wires, keeping your readings accurate.
- Built-in Smoothing: Features a software "moving average" filter to stop the numbers from jumping around erratically if there is electrical noise.
- Power Supply: Runs on a standard 24V DC power setup.
-
- Manufacturer: FATEK
- Model / Part Number: FBS-16TC
- Input Channels: 16 channels for thermocouple input.
- Supported Thermocouple Types: J, K, R, S, E, T, B, and N type sensors.
- Built-In Features: Cold Junction Compensation (CJC) and open thermocouple wire fault detection.
- High Resolution Option: Gives you a fine 0.1°C resolution with a 6-second temperature update cycle.
- Fast Mode Option: Gives you a 1.0°C resolution with a faster 3-second temperature update cycle.
-
- Manufacturer: FATEK
- Model / Part Number: FBS-16XYR
- Total Points: Adds 16 digital channels to your system.
- Digital Inputs: 8 input channels that accept 24VDC (Direct Current) signals. These inputs can be wired as either NPN or PNP configurations.
- Digital Outputs: 8 relay output channels. These use physical mechanical switches inside the unit to turn external devices on or off. They can handle up to 230VAC at 2 Amps.
- Physical Setup: This is a right-side expansion module. It snaps directly into the right side of the main FBs PLC unit using built-in ribbon cables.
- Size: It has standard compact dimensions measuring 90mm x 60mm x 80mm (Height x Width x Depth).
- FBs: Fits the Fatek FBs main series of PLCs.
- XY: Contains both inputs (represented by 'X' in PLC programming) and outputs (represented by 'Y').
-
- Manufacturer: FATEK
- Model / Part Number: FBS-16YR
- Output Count: 16 digital output points.
- Output Type: Mechanical Relay.
- Electrical Rating: Supports up to 250VAC or 30VDC at a maximum of 2A per point.
- Installation: Attaches as a Right-Side Expansion Unit and mounts onto standard DIN rails.
- Physical Size: Measures 90mm (H) x 60mm (W) x 80mm (D).
- FBs: Points to FATEK's high-performance micro PLC series.
-
- Manufacturer: FATEK
- Model / Part Number: FBS-1LC
- Input Channels: 1 channel for a load cell.
- Internal Resolution: 20-bit (very precise).
- Output Data: 16-bit signed integer format.
- Excitation Voltage: 5V DC.
- Sensor Sensitivity: Works with 2 mV/V, 5 mV/V, 10 mV/V, and 20 mV/V sensors.
- Sampling Rates: Adjustable between 5 Hz to 80 Hz.
- Set the Zero Point (Tare): Clear out any existing weight from the scale bed.
- Apply a Known Weight: Place a heavy, exact weight onto the scale.
- Set the Max Reference: Enter that known weight value into register R2 and flip a specific setting bit to lock it in.
- Software: You need WinProLadder V3.22 or newer to access the easy I/O configuration screens.
- PLC Firmware: The main PLC unit should run OS V4.71 or newer for seamless multi-module tracking.
-
REQUEST A QUOTE
- Power Supply Type: 24V DC
- Total I/O Channels: 20 Points Total
- Digital Inputs: 12 Points (24VDC)
- Digital Outputs: 8 Points (Relay Dry-Contact)
- Onboard Comm Ports: 1 x RS232 or USB Port (Expandable up to 3 total ports via expansion boards)
- Memory Allocation: 20K words Program Space / 20K words Data Space
- Execution Functions: 86 built-in sequential and application control functions
- Real-Time Clock: Built-In RTC hardware module included
- I/O Expansion Limits: Expandable up to 256 physical digital I/O points
- Regulatory & Origins: Manufactured in Taiwan; CE, RoHS, and UL certified
FATEK FBS-20MAR2-D24 PLC Main Unit (FBs Series).
