Showing 881–896 of 2168 results
-
REQUEST A QUOTE
- Part Numbers: 400508-00062, 40050800062
- Interchange / Cross-References: 400508-00110, 400508-0062, HIFI SN25153
- Outer Diameter: 110 mm (~4.33 inches)
- Height: 145 mm (~5.71 inches)
- Material: High-efficiency filter paper with a robust steel housing
- Weight: Approximately 5 lbs (~2.27 kg)
- Equipment Type: Compatible Models
- Doosan Excavators: DX140 LC-5, DX150, DX160 W-5, DX215, DX225 LC-5, DX255 LC-5, DX260-9C, DX300 LC-5, DX340 LC-3, DX420 LC-5, DX530 LC-5 (and variants)
- Doosan Wheel Loaders: DL200, DL200-3, DL250-5, DL300-5, DL420-5
- Cranes & Specialty: Demag AC 250-5 Crane, ACX 23 RR Crane, Lefort Scrap Shear
DOOSAN 400508-00062 Fuel Filter (Doosan).
-
REQUEST A QUOTE
- Voltage Input Range: 208 to 480 V AC (covers 3-phase mains systems from 177 V AC up to 552 V AC with a ±15% tolerance).
- Output Configuration: 1 Single Pole Double Throw (SPDT) relay, normally energized.
- Current Contact Rating: 5 Amps switching maximum.
- Frequency Range: 50 to 60 Hz.
- Housing Profile: 17.5 mm ultra-compact width for space-saving DIN-rail mounting.
- Safety & Certifications: UL, CSA, and CE compliant.
- Phase Sequence Protection: Prevents three-phase motors from starting or running in the reverse rotation, which can quickly cause catastrophic mechanical failures in HVAC compressors, industrial conveyors, and pumps.
- Phase Loss Monitoring: Automatically disconnects the load if any individual phase drops out, avoiding motor overheating and rapid torque reduction.
- Regenerated Voltage Detection: Safely triggers a fault response even if a failing motor attempts to reconstruct a missing phase voltage up to 85% of the nominal grid value.
- Plug-and-Play System: Operates on an automatic setup profile requiring no manual setting adjustments or external calibration. Dual LED bulbs give instant visual diagnostics for "Power Supply On" and "Relay Status".
- Logistics Note: The suffix variation "B014" is a specific packaging or manufacturing batch suffix often designated on units distributed directly from factory assembly facilities in Europe and Asia. It remains fundamentally interchangeable with the standard catalog identifier DPA51CM44.
DPA51CM44B014 CARLO GAVAZZI Phase Monitoring Relay.
-
REQUEST A QUOTE
- Function: 3-phase monitoring relay (phase sequence, total and partial phase loss)
- Supply / Measuring Voltage: 208 to 480 VAC (±15%)
- Output: Relay output
- Series: Carlo Gavazzi DPA51CM44
- Application: Protection of electrical systems and motors
DPA51CM44B014T CARLO GAVAZZI Phase Monitoring Relay.
-
REQUEST A QUOTE
- Manufacturer: Dräger Medical (Draeger Inc.)
- Part Number (MPN): 8403735 (Also alternates with 6871980)
- Sensor Type: Spirolog / Spiroquant A+
- Measurement Technology: Hot-wire anemometer (measures cooling effect of gas across a heated wire)
- Material: Acrylonitrile Butadiene Styrene (ABS)
- Reusability: Autoclavable, disinfectable, and reusable
- Operating Range: 0 to 100% flow; 15°C to 40°C operational temperature
- Standard Packaging: Typically sold in boxes/packs of 5 units
- Anesthesia Systems: Dräger Primus, Fabius GS, Julian, Cato, Cicero, and Sulla.
- Intensive Care Ventilators: Evita Family (including Evita 4, Evita XL) and Savina / Savina 300 series.
DRAGER 8403735 Flow Sensor (Spirolog).
-
REQUEST A QUOTE
- Sensing Mode: Polarized Retroreflective
- Output Type: Complementary PNP (Light-ON & Dark-ON options)
- Response Time: 2 milliseconds (ms)
- Operating Temperature: -20°C to +70°C (-4°F to +158°F)
- Standard Cable: Pre-wired 2-meter (6.5 ft) cable with flying leads
DS18VP6LP BANNER Polarized Retroreflective Sensor.
-
REQUEST A QUOTE
- Approximate Weight: 1.85–2.2 kg
- Environmental Protection: Features high dust and waterproof ratings equivalent to an IP65 classification.
- Contamination Tolerance: The wet-type solenoid allows the core moving components to be continuously lubricated by system hydraulic oil, which cushions impact and provides strong resistance against fluid contamination.
- Fluid Compatibility: Designed standard with Buna-N (NBR) seals, compatible with typical petroleum-based industrial hydraulic oils, water-glycols, and water-in-oil emulsions.
DSG-01-3C4-A110-50 YUKEN Solenoid Directional Control Valve.
-
REQUEST A QUOTE
- Application Media: Natural gas, propane, butane, air, and inert gases.
- Pressure Setting Range: 5 to 150 mbar (Adjustable via an integrated scaling wheel).
- Switch Type & Electrical Rating: SPDT (Single Pole Double Throw) | 6A @ 250Vac.
- Protection Class: IP54 (Dust and splash water protection).
- Temperature Limits: Ambient temperature from -15 °C to +70 °C.
- Enclosure Material: Sturdy die-cast aluminum housing with an O-ring flange connection.
- Power-Free Operation: Works as a mechanical single-acting over-pressure switch, meaning it functions without requiring an external auxiliary power supply.
- Fast Response Time: Features short response times during rapid, short-term pressure fluctuations to ensure system safety.
- Direct Component Mounting: Built specifically to be mounted either directly onto the housing of DUNGS GasMultiBloc and DMV double solenoid valves, or by using a direct adapter.
DUNGS GW150A5 Compact Gas Pressure Switch (GW Series).
-
- Manufacturer: Dungs
- Model / Part Number: GW150A6
- Adjustable Scale Range: 5 to 150 mbar (millibar).
- Maximum Operating Pressure: 500 mbar (50 kPa).
- Media Compatibility: Suitable for air, flue gases, exhaust gases, hydrogen, and standard fuel gases.
- Housing Material: Durable die-cast aluminum base with a polyamide plastic dial cover.
- Enclosure Rating: IP54 protection against dust and water splashes.
- Electrical Connection: Standard plug-in connection.
- Pressure Connection: Threaded G 1/4" inner thread located on the bottom center of the housing.
- Integrated Testing Feature: Includes a built-in metal test nipple (9 mm diameter) to check system pressure easily.
-
- Brand: DUNGS
- Model: LGW 10 A2
- Series: LGW A2
- Monitored condition: Overpressure, underpressure or differential pressure
- Setting range: 1 to 10 mbar
- Maximum operating pressure: 500 mbar (50 kPa)
- Media: Air, flue gas, exhaust gas and non-aggressive gases
- Pressure connection: 4.6 mm hose connection
- Ambient temperature: -15 to +70 °C
- Storage temperature: -30 to +85 °C
- Contact material: Silver
- Switching voltage AC: 24 to 250 V AC
- Nominal current: 10 A AC
- Electrical connection: Screw terminals via M20 × 1.5 cable entry
- Protection rating: IP54
-
REQUEST A QUOTE
- Manufacturer: DUNGS
- Model / Part Number: LGW 150 A4
- Setting range: 30–150 mbar
- Maximum operating pressure: 500 mbar
- Switching tolerance: ±15% maximum
- Switching difference at minimum setting: ≤3 mbar
- Switching difference at maximum setting: ≤5 mbar
- Protection: IP54
- Rated frequency: 50/60 Hz
- Nameplate contact rating: 10 A, 250 V AC
-
- Manufacturer: DUNGS
- Model / Part Number: MAG.NR.200
- Voltage Options: Commonly 230 VAC (50–60Hz) or 24 VAC depending on the specific product number.
- Power Consumption: Usually around 25 Watts.
- Duty Cycle (ED): 100%, meaning it is built to stay powered on continuously without overheating.
- Weather Protection: Rated at IP54 or NEMA Type 12, which shields it against dust and splashing water.
- MVD Series: MVD 207/5, MVD 210/5, MVD 507/5, MVD 510/5
- MVDLE Series: MVDLE 207/5, MVDLE 210/5, MVDLE 507/5
- Industrial Distributors: Many regional heating and combustion equipment suppliers stock these under article numbers like Art.Nr. 213795 or PN 240311.
-
REQUEST A QUOTE
- Maximum Inlet Pressure: 360 mbar (36 kPa / 5.22 PSI) max operating pressure.
- Outlet Pressure Range: 4 mbar to 20 mbar (0.4 kPa to 2 kPa) adjustable output.
- Connection Size: Rp 3/4 threaded internal diameter inlet/outlet flanges.
- Main Valve Features: Integrated manual main volume restrictor and bypass valve.
- Electrical Standard: Configurable variants typically running at 230 VAC (50-60 Hz) or 110 VAC.
- Enclosure Rating: IP54 dust and splash protection.
- Operating Temperatures: -15°C to +70°C (5°F to 158°F).
- Approvals: Certified under European standards EN 161 (Class A, Group 2 automatic shut-off valves) and EN 88 (pressure regulators).
- Pressure Switch Combinations: Pre-assembled packages with safety cut-out switches can be acquired through Comtherm with Pressure Switch (GW150/GW50).
DUNGS MB-DLE407B01S20 Gas Combination Unit (GasMultiBloc).
-
REQUEST A QUOTE
- Part Number (MRN): 226799
- Outlet Pressure Range: 4 – 20 mbar (0.4 – 2.0 kPa)
- Nominal Diameter: DN 40 (Connection size flange dependent)
- Coil Voltage Supply: 230 VAC (50–60 Hz) [110 VAC variants available]
- Power Consumption: 60 VA
- Protection Class: IP54
- Ambient Temperature: -15 °C to +60 °C (Up to +70 °C variant-dependent)
- Closing / Opening Time: Closing: < 1 second / Opening: < 20 seconds
- Default Pressure Switch: GW 50 A5 or GW 150 A5 (depends on standard kit)
- Unit Net Weight: 6.6 kg (14.5 lbs)
DUNGS MB-DLE415B01S20 Gas Valve (GasMultiBloc).
-
- Manufacturer: DUNGS
- Model / Part Number: MB-DLE420B01S50
- Connection Size: 2" NPT or Flange (DN50)
- Operation: Single-stage gas control block
- Media Compatibility: Suitable for gases of families 1, 2, 3 (Natural gas, propane, butane) and other neutral gaseous media
- Part Number / SKU: 226805
-
- Manufacturer: DUNGS
- Model / Part Number: MB-ZRDLE415B01S20
- Model Type: Two-stage gas valve (ZR) with adjustable slow-opening behavior (-LE) and main volume restrictor (-D).
- Part Number (MRN): 226807 (frequently bundled with a GW 50 A5 pressure switch).
- Connection Size: DN 40 flange (1 ½" BSP thread matching standard gas piping).
- Maximum Inlet Pressure: Up to 360 mbar (36 kPa).
- Outlet Pressure Range: 4 to 20 mbar (0.4 to 2 kPa), which can be adjusted at the regulator.
- Electrical Power: 230 V AC operating voltage at 50–60 Hz.
- Operating Protection: IP 54 rated against dust and moisture splashes.
- Temperature Range: -15 °C to +70 °C (For liquid gas systems, do not use below 0 °C).
- MB-ZR: MultiBloc system featuring a two-stage valve design. This allows the burner to fire at a lower partial flame before stepping up to full heat.
- DLE: Equipped with a main volume restrictor (D) and an adjustable slow-opening hydraulic brake (LE) to prevent gas bursts when starting.
-
REQUEST A QUOTE
- Feature / Attribute: Technical Specification
- Manufacturer: Karl Dungs GmbH & Co. KG
- Model / Part Number: SAD1.2 / 229813
- Power Supply: 24 VDC
- Power Consumption: 7 W
- Torque Rating: 1.2 Nm (Newton-meters)
- Ingress Protection: IP40 (Note: Beware of generic web listings claiming IP65, which often mistake industrial burner servos for standard CNC motors)
- Primary Material: Durable, lightweight engineered composite housing
- Air/Fuel Ratio Control: It drives the mechanical positioning of valves to control precisely how much gas, oil, or air enters the burner system.
- Modulation: Unlike basic open/close solenoid valves, the stepper design allows for incremental adjustments to adapt to shifting load demands.
DUNGS SAD1.2 Motorized Actuator (SAD Series).
