Showing 17–32 of 100 results
-
REQUEST A QUOTE
- Model Code: FC-051P2K2T4E20H3BXCXXXSXXX
- Power Output: 2.2 kW / 3.0 HP
- Input / Output Voltage: 380–480 V AC (Three-Phase)
- Amperage Output: 4.8 A (Constant) / 5.6 A (Max)
- Control Principle: Open Loop Vector / V/Hz
- Braking Features: Built-in Brake Chopper
- RFI Filter: Class A1/B (C1)
- Enclosure Rating: IP20 / Chassis
- Frame Size: M2
- PCB Protection: Conformal Coated
DANFOSS 132F0022 VLT Micro Drive (FC-51 Series).
-
- Manufacturer: Delta
- Model / Part Number: ASD-A2-1543-M
- Series: ASDA-A2 Series
- Rated Output Power: 1.5 kW (1500 W)
- Input Voltage / Phase: 3-Phase 380V to 480VAC (± 10%), 50/60Hz
- Continuous Output Current: 5.02 Arms
- Instantaneous Max Current: 10.04 Arms
- Control Configurations: Features built-in electronic cam (E-CAM) functionalities and Full-Closed Loop control capabilities to compensate for mechanical backlash.
-
REQUEST A QUOTE
- Series: ASDA-A2 Series (High-performance, closed-loop)
- Model Code: ASD-A2-3023-L
- Rated Output Power: 3.0 kW (3000 Watts)
- Input Voltage / Phase: 3-phase (supports 1-phase operation with derating) 200V ~ 230VAC, -15% to +10%
- Continuous Output Current: 19.4 Arms
- Encoder Resolution Support: 20-bit Incremental encoder / 17-bit Absolute encoder
- Control Modes: Position Control (Pulse + Direction), Speed Control, and Torque Control (via ±10 VDC voltage range)
- Communication Interface: 1x RS-232, 1x RS-485, and 1x USB built-in communication ports
- Enclosure Rating: IP20
- ASD: AC Servo Drive
DELTA ASD-A2-3023-L AC Servo Drive (ASDA-A2).
-
REQUEST A QUOTE
- Series: ASDA-B3 High Performance Platform
- Rated Output Power: 1.0 kW (1000 Watts)
- Input Power Phase / Voltage: 1-Phase / 3-Phase, 220 VAC
- Continuous Output Current: 7.3 Arms
- Instantaneous Max Current: 21.21 Arms
- Encoder Resolution Support: 24-bit (16,777,216 pulses/rev)
- Response Bandwidth: 3.1 kHz
- ASD: AC Servo Drive
- Advanced Suppression Tuning: Integrates robust auto-tuning algorithms alongside automated notch filters for mechanical vibration suppression, eliminating system resonance during sharp acceleration transitions.
- High Motor Speed Support: Fully compatible with high-speed servo motors reaching operational profiles up to 6,000 r/min.
DELTA ASD-B3-1021-L AC Servo Drive (ASDA-B3).
-
- Manufacturer: Delta
- Model / Part Number: ECM-B3L-C20401RS1
- Rated Output Power: 0.1 kW (100 Watts)
- Rated Torque: 0.32 N-m
- Speed Range: 3,000 RPM rated speed, reaching up to a max full speed of 6,000 RPM
- Encoder Resolution: 24-bit incremental optical encoder yielding 16,777,216 pulses per revolution for ultra-precise positioning
- Rated Current: 0.857 Arms (with an instant max output current of 3.44 Arms)
- Physical Weight: Lightweight design at roughly 0.5 kg (1.1 lbs)
-
- Manufacturer: Delta
- Model / Part Number: ECM-B3M-C20604RS1
- Output Power: 0.4 kW (400 Watts)
- Rated Torque: 1.27 N-m
- Rated Speed: 3000 RPM (Full range up to 6000 RPM)
- Rated Current: 2.4 Arms
- Max Current: 9.47 Arms (Instant peak)
- Rotor Inertia: Medium Inertia
-
- Manufacturer: DELTA
- Model / Part Number: ECMA-C10807RS
- Series: ECMA Series (ASDA-A2 Compatible)
- Rated Power Output: 750W / 0.75 kW
- Supply Voltage: 220V AC (Single/Three Phase)
- Rotor Inertia: Low Inertia
- Rated Torque: 2.39 Nm
- Rated Speed: 3000 RPM
- Frame Size: 80 mm
- Shaft Diameter: 19 mm
- Encoder Resolution: 20-bit Incremental Encoder (1,280,000 pulses/rev)
- Shaft Features: Keyway with screw hole (Tap)
- Brake Option: No Brake
- Ingress Protection: IP65 (with built-in oil seal)
-
REQUEST A QUOTE
- Feature / Attribute: Technical Specification
- Manufacturer: Karl Dungs GmbH & Co. KG
- Model / Part Number: SAD1.2 / 229813
- Power Supply: 24 VDC
- Power Consumption: 7 W
- Torque Rating: 1.2 Nm (Newton-meters)
- Ingress Protection: IP40 (Note: Beware of generic web listings claiming IP65, which often mistake industrial burner servos for standard CNC motors)
- Primary Material: Durable, lightweight engineered composite housing
- Air/Fuel Ratio Control: It drives the mechanical positioning of valves to control precisely how much gas, oil, or air enters the burner system.
- Modulation: Unlike basic open/close solenoid valves, the stepper design allows for incremental adjustments to adapt to shifting load demands.
DUNGS SAD1.2 Motorized Actuator (SAD Series).
-
REQUEST A QUOTE
- Model / Part Number: SP0405
- Series Platform: Control Techniques Unidrive SP (500 Series)
- Input Voltage: 460 VAC (380V – 460V operating range)
- Motor Power Rating: 2 HP / 1.5 kW (Note: Some light-duty configurations scale down to 0.55 kW)
- Continuous Output Current: 4.2 A
- Short-Term Overcurrent: 6.3 A for up to 60 seconds (Transient peak handling)
- Protection Rating: IP20 (Enclosed cabinet mounting required)
- Physical Weight: ~ 8 kg (17.6 lbs)
- High Performance Control: Supports multi-mode motor control, including open-loop, closed-loop vector, and servo control for synchronous and asynchronous standard three-phase AC motors.
- Space-Efficient Design: Features a compact book-style footprint with an IP20 rating optimized for clean, space-saving panel thermal layouts.
EMERSON SP0405 Variable Frequency Drive (Unidrive SP).
-
REQUEST A QUOTE
- Model Designation: Alpha iF 12/3000 (α iF12/4000 series platform configured for 3000 RPM)
- Power Rating: 2.5 kW to 3.0 kW
- Rated Speed: 3000 RPM
- Stall Torque: 12 Nm
- Current Rating: 14 A
- Input Voltage: 3-Phase, 200–240 VAC (50/60 Hz)
- Shaft Type: Straight shaft (no key, no brake)
- Feedback Device: α1000iA absolute encoder / PulseCoder (Part Number: A860-2000-T301)
- Environmental Protection: IP65 standard seals
- Physical Weight: Approx. 20 kg (42.6 lbs)
FANUC A06B-0243-B100 Precision AC Servo Motor (Alpha i Series).
-
- Manufacturer: FANUC
- Model / Part Number: A06B-2116-B203
- Model Series: βiS 1/6000 (Beta iS series)
- Max Speed: 6,000 RPM
- Shaft Type: Straight shaft (ST) with a KEY way
- Feedback System: Equipped with a βiA 1000 absolute pulsecoder
- Insulation Class: Class F
-
REQUEST A QUOTE
- Model / Type: Beta Series Servo Unit, Type SVU-20
- Interface Type: Fanuc I/O Link Interface
- Single-Phase Input: 220–240 VAC @ 10.1 A, 50/60 Hz
- Three-Phase Input: 200–240 VAC @ 6.3 A, 50/60 Hz
- Rated Output: 240 VAC, 5.9 A
- Control Method: Digital servo control with Incremental Encoder (INC) support
- Compatible Motors: Fanuc βM0.5/4000 (20A), βM1/4000 (20A), β3/3000, β6/2000
- Related Manuals: Functional descriptions in B-65232EN; Maintenance instructions in B-65245EN
- PMC Axis Control: Unlike standard centralized servo drives, the I/O Link drive handles item sequencing internally. The CNC sends a target position/index amount and feed rate, and the amplifier handles zero returns, overtravels, axis clamping/unclamping, and e-stop processing independently before passing a "finish" signal back.
- Indexer Configuration: It features dedicated internal parameters that allow it to act as an indexer (e.g., managing tool magazine positions automatically).
FANUC A06B-6093-H152 Servo Amplifier (Beta Series).
-
REQUEST A QUOTE
- Model Number: Alpha Servo Module SVM1-130
- Interface Type: FSSB (Fanuc Serial Servo Bus)
- Rated Input Power: 283–325 VDC, 9.1 kW
- Rated Output Voltage: 230 VAC
- Rated Output Current: 52.2 A (L-Axis)
- Physical Dimensions: 14.0" H x 3.3" W x 11.9" D (380 x 90 x 307 mm)
- Weight: 13.5 lbs (6.12 kg)
- Environmental Tolerances: 0 to 40°C/55°C operating range; 5G vibration resistance
- Official Documentation: Fanuc Maintenance Manual B-65162
- Safety Preparation: If diagnosing a vertical axis, physically prop up or secure the axis. When the motor brake is released during testing, the axis will drop under gravity if unsupported.
FANUC A06B-6096-H106 Servo Amplifier Module (Alpha Series).
-
REQUEST A QUOTE
- Model Type: SVM2-80/80 (Alpha Series)
- Interface Type: FSSB Optical Fiber Interface
- Number of Axes: 2 (Dual Axis / Twin Axis)
- Rated Output Current: 18.7 A (per axis)
- Output Voltage: 230 V AC
- Power Rating: 9.5 kW
- Input Voltage Range: 283 – 339 V DC (Power Link)
- Feedback Support: Incremental Encoders (INC)
- Approximate Weight: ~15 lbs (6.8 kg) to 25 lbs (11.3 kg) depending on packaging
- Target Machinery: Primarily integrated into industrial automation setups such as CNC Lathes and CNC Machining Centers.
FANUC A06B-6096-H208 Servo Amplifier Module (Alpha Series).
-
- Manufacturer: FANUC
- Model / Part Number: A06B-6110-H026
- Power Output: 26 kW
- Input Rating: 106 Amps
- Input Voltage: 200–240 Volts AC (3-Phase)
- Output Voltage: 283–325 Volts DC
-
- Manufacturer: FANUC
- Model / Part Number: A06B-6114-H303
- Manufacturer: FANUC (Japan)
- Part Number: A06B-6114-H303
- Model Code: SVM3-20/20/20i
- Number of Controlled Axes: 3 Axes (Labeled L, M, and N)
- Total Input Power Rating: 7.5 kW
- Rated Input DC Link Voltage: 283 V to 339 V DC (supplied by a PSM power supply module)
- Maximum Output Voltage: 240 V AC
- Rated Output Current: 6.5 A continuous per axis (20 Amp peak current class)
- Interface Communication Type: FSSB (Fanuc Servo Serial Bus) over high-speed fiber optic cables
- Cooling Method: Integrated internal fan cooling
- Mounting Type: Standard electrical cabinet panel mount
- Paired Motors: This specific 20 Amp class amplifier is typically paired with FANUC Alpha i Model 4i or 8i AC servo motors.
- Compatible CNC Controls: It integrates natively with FANUC 15i, 16i, 18i, and 21i generation CNC platforms, as well as modern iB and iC controls.
- Robotics: Frequently found managing synchronized motion in multi-axis FANUC industrial robot controllers.
