Showing 65–80 of 100 results
-
- Manufacturer: LS
- Model / Part Number: L7SA020A
- Power Output: 2.0 kW (2000 Watts).
- Output Current: Rated at 13.5 A continuous, with a peak capacity up to 40.5 A.
- Main Power Input: 3-Phase AC 200V to 230V (-15% to +10% fluctuation allowance) at 50/60 Hz.
- Control Power Input: Single-Phase AC 200V to 230V.
- Supported Encoders: Quadrature type incremental line driver (up to 6000 P/R) and high-resolution Serial types (19-bit/20-bit BiSS protocol).
- Frequency Response: Max 1 kHz or above, allowing for highly dynamic response times.
- Control Interfaces: Supports standard Pulse/Direction inputs, Analog voltage commands (-10V to +10V), and built-in RS-422 or USB communication.
- Physical Weight: Approximately 2.43 kg to 2.5 kg (includes built-in cooling fan).
-
- Manufacturer: MITSUBISHI
- Model / Part Number: HC-KFS73B
- Rated Output Capacity: 750 W (0.75 kW)
- Supply Voltage Class: 200 VAC class
- Rated Current: 5.8 A (Maximum current: 18.6 A)
- Rated Rotational Speed: 3000 RPM
- Maximum Speed: 4500 RPM
- Rated Torque: 2.4 Nm nominal
- Maximum Torque: 7.2 Nm peak
- Moment of Inertia: 0.0001635 kg·m² (1.635 kg·cm²)
- Feedback Encoder: 17-bit absolute feedback encoder (131,072 p/rev)
- Shaft Design: Standard straight shaft
- Electromagnetic Brake: Built-in / Installed
- Flange Size: 80mm x 80mm mounting
- Dimensions: H 98.1mm x W 82mm x D 217.5mm
- Ingress Protection: IP55 rated (excluding the shaft portion and connector)
- Operating Temperature: 0°C to +40°C ambient
- Storage Temperature: -15°C to +70°C
- Approximate Weight: 2.5 kg to 3.0 kg
- HC-KFS: Low inertia, small capacity series
-
REQUEST A QUOTE
- Manufacturer: MITSUBISHI
- Model / Part Number: HG-KN43J-S100
- Rated Output Power: 400 W (0.4 kW)
- Rated Torque: 1.3 N·m
- Maximum Torque: 3.8 N·m
- Rated Speed: 3,000 r/min
- Maximum Speed: 5,000 r/min
- Rated Current: 2.6 A
- Encoder Resolution: 17-bit feedback resolution (equivalent to 131,072 pulses per revolution) acting as either absolute or incremental
- Environmental Protection: IP65 rated (completely dust-tight and resistant to water jets)
- Shaft Configuration: Straight shaft with a factory-installed oil seal
MITSUBISHI HG-KN43J-S100 Servo Motor. Key specifications include Rated Output Power: 400 W (0.4 kW); Rated Torque: 1.3 N·m; Maximum Torque: 3.8 N·m; Rated Speed: 3,000 r/min.
-
- Manufacturer: MITSUBISHI
- Model / Part Number: MR-J2S-10A
- Rated Power: 100 Watts (0.1 kW) output power.
- Input Voltage: Can run on 3-phase AC 200–230V or Single-phase AC 230V (at 50/60 Hz).
- Control Modes: Position, Speed, and Torque.
- Control Interface: Uses universal analog inputs or digital pulse trains to tell the motor where to go and how fast to spin.
- Communication: Built-in RS-232C and RS-422 serial ports for connecting to a PC or programming software.
- Weight: Super light at only 0.7 kg.
-
REQUEST A QUOTE
- Rated Output Power: 1000W (1.0 kW)
- Rated Current: 6.0 A
- Supply Voltage (AC): 200 Vac–240 Vac (Single-phase or 3-phase input)
- Supply Voltage (DC): 283 Vdc–340 Vdc
- Network Interface: SSCNET III/H (High-speed fiber optic motion network)
- Control Type: Fully closed-loop control (4-wire type)
- Encoder Interface: Load-side encoder A/B/Z-phase input
- Hardware Protections: Built-in dynamic brake & built-in regenerative resistor
- Ingress Protection: IP20
- Operating Temp: 0°C to +55°C (Ambient)
MITSUBISHI MR-J4-100B-RJ Servo Drive (MR-J4).
-
REQUEST A QUOTE
- Manufacturer: Mitsubishi
- Model / Part Number: MR-J4-20A
- Rated Output Power: 200 W (0.2 kW)
- Rated Current: 1.5 A
- Supply Voltage: 200–240 V AC, single-phase or three-phase input
- Communication Interface: RS-422 and RS-485
- Protection Rating: IP20
- Operating Temperature: 0 to +55 °C
Mitsubishi MR-J4-20A Servo Drive. Contact us for product information and quotation.
-
REQUEST A QUOTE
- Code Number: 1797
- Outer Diameter: ø30 mm
- Maximum Motor Speed: 19,000 RPM (at 0.5 MPa / 71 PSI)
- Maximum Power Output: 130 W
- Air Consumption: 180 NL/min (6.29 CFM)
- Proper Air Pressure: 0.3 – 0.5 MPa (42 – 71 PSI)
- Net Weight: 298 g (excluding hoses)
- Modular System: Designed as a separate-type system. It can be combined with various Nakanishi ø30 mm spindles or speed reducers (such as the ARG-011E 1/4 speed reducer) depending on the torque requirements of the application.
- Thermal Management: Engineered to withstand long, continuous operation without significant heat generation.
- Noise Reduction: Equipped with an inline silencer to minimize exhaust noise during operation.
- Required Accessories: To run this motor safely, it must be paired with an Air Line Kit (AL-M1202 or AL-M1203BS2) providing filtered, regulated, and lubricated air.
- Type: Motor; Outer Diameter: φ30 mm; Motor speed: 19,000 min-1 (0.5 MPa); Max. power: 130 W; Proper air pressure: 0.3–0.5 MPa; Air…
NAKANISHI AM-3020R Vane-Type Air Motor (Air-Speed Series).
-
- Manufacturer: NAKANISHI
- Model / Part Number: AM-310R
- Maximum Speed: Up to 30,000 RPM (at 0.5 MPa / 71 PSI)
- Max Output Power: 108 Watts
- Rotation Direction: Clockwise (Forward) only
- Outer Diameter: 22.8 mm (0.897 inches)
- Air Pressure Range: 0.3 to 0.5 MPa (approximately 43.5 to 72.5 PSI)
- Air Consumption: 190 NL/min (Normal Liters per minute)
- Weight: 203 grams (about 7.2 ounces without hoses)
- Continuous Operation: Engineered to withstand long, continuous usage without overheating.
- Quiet Design: Equipped with a built-in silencer system to keep industrial workplace noise to a minimum.
-
REQUEST A QUOTE
- Motor Type: Brushless DC Motor
- Outer Diameter: φ 30 mm
- Speed Range: 1,000 – 30,000 min⁻¹ (RPM)
- Housing Material: Stainless Steel (SUS416)
- Net Weight: 350 g (14.64 oz.) without cord
- Standard Accessories: Wrench (22 × 27): 1 pc.
- NSK Catalog Number: 11769
- Controller Requirement: This motor must be connected to a compatible NAKANISHI controller, such as the NSK America E3000 Controller. If it is hooked up to an older or incompatible legacy controller, the safety features will trigger and it will not rotate.
- Cord Limitations: The motor requires a specialized joint-type motor cord. Note that the long 25.3 ft / 8m cord (EMCD-3000J-8M) cannot be used with this torque motor.
- Variant Differences: EM-3030T vs. EM-3030T-J
NAKANISHI EM-3030T Electric Spindle (E3000).
-
- Manufacturer: NAKANISHI
- Model / Part Number: EM25-5000-J4
- Speed Range: 1000 to 50000 r/min
- Output Power: 125 to 200 W, controller-dependent
- Housing Diameter: 25 mm
- Clutch Type: Negative clutch
- Housing Material: Stainless steel
- Weight: 250 g without cable
-
- Manufacturer: NAKANISHI
- Model / Part Number: NR-303
- Maximum Allowable Speed: 30,000 RPM (min⁻¹)
- Spindle Accuracy: Within 2 μm (runout precision)
- Outer Diameter: ø22.8 mm
- Total Length: 93.5 mm
- Net Weight: 215 g (7.58 oz)
- Compatible Collets: CHK Group (ranging from ø0.5 mm to ø6.35 mm)
- Coolant Compatibility: Safe for use with water-based or oil-based coolants
-
REQUEST A QUOTE
- Spindle Type: 90° Standard Right Angle Spindle
- Outer Diameter: φ 30 mm
- Reduction Ratio: 1 / 1.5
- Spindle Accuracy / Runout: Within 2 μm to 3 μm
- Collet Capacity: CHK Series: φ 0.5 mm to φ 6.0 mm (Up to φ 1/4")
- Net Weight: 580 g (1 lb. 4.46 oz.)
- NSK Catalog Number: ASE1579 (Formerly RAX-270E)
NAKANISHI RAX-271E Right-Angle Spindle (RAX Series).
-
REQUEST A QUOTE
- Manufacturer: Nidec Servo Corporation (Japan)
- Model Number: D1751S24B6CZ-16 (also referenced as D1751S24B6CZ16)
- Fan Type: Industrial DC Axial Flow Fan
- Dimensions: 172 mm × 172 mm × 51 mm (Standard 17251 frame)
- Frame Material: Full round aluminum frame with plastic impeller blades
- Rated Voltage: 24 VDC
- Rated Current: 1.8 A
- Power Consumption: 43.2 W
- Maximum Fan Speed: 6,950 RPM ± 10%
- Maximum Airflow: 16.5 m³/min (≈ 582 CFM)
NIDEC D1751S24B6CZ-16 DC Axial Fan (Nidec Servo).
-
REQUEST A QUOTE
- Control Method: Pulse train / Pulse input control
- Rated Output Capacity: 0.4 kW (400 W)
- Input Supply Voltage: 200–230 V AC, Single-phase (50/60 Hz)
- Load Current/Voltage: 2.5 A / 200 V load
- Compatible Motors: R88M-G40030H / R88M-GP40030H
- Mounting Type: Chassis Mount
- Operating Temperature: 0°C to +55°C
- Compliance: RoHS3 Compliant, Reach Unaffected
OMRON R7D-BP04H Servo Drive (SmartStep 2).
-
REQUEST A QUOTE
- Rated Output Power: 400 W (0.4 kW)
- Main Circuit Input Voltage: Single-phase 200 to 240 VAC (170 to 252 V)
- Control Circuit Voltage: 24 VDC (21.6 to 26.4 V)
- Current Output Rating: 2.3 A
- Supported Encoder: 23-bit high-resolution multi-turn (battery-free)
- Physical Dimensions: 223 mm (H) × 55 mm (W) × 196.05 mm (D)
- Weight: Approx. 1.5 kg
- Built-in Safety (STO): Features a hardwired Safe Torque Off (STO) conforming to PLe (EN ISO 13849-1) and SIL3 (IEC 61508) standards, alongside network-based STO capabilities.
- Advanced Architecture: Equipped with screw-less, push-in pluggable connectors to facilitate rapid pre-wiring, reducing overall installation and maintenance times.
- Integrated Brake Control: An embedded relay allows direct motor brake control without requiring external components.
OMRON R88D-1SN04H-ECT AC Servo Drive (1S Series).
-
- Manufacturer: PANASONIC
- Model / Part Number: MCDDT3520
- Series: MINAS A4 Series (Standard Model)
- Rated Power: 750 Watts (0.75 kW)
- Frame Size: C-Frame
- Input Voltage: 200V to 240V AC (Works with either 1-phase or 3-phase power)
- Output Current: 30A maximum
- Frequency Response: 1.0 kHz
- Weight: About 3.3 to 3.6 lbs (1.5 to 1.6 kg)
