Showing 49–64 of 94 results
-
-
PEPPERL+FUCHS KFD2-GUT-1.D Temperature Converter (KFD2)
- Manufacturer/Brand: Pepperl+Fuchs Process Automation
- Part Number: KFD2-GUT-1.D (Item Number: 231224)
- Channels: 1 isolated channel
- Power Supply: 20 to 30 V DC (24 V DC nominal) via Power Rail or terminals
- Input Options: Thermocouples (with optional redundant TC input), RTDs, Potentiometers, or Voltages (-100 to 100 mV, 0 to 1 V, 0 to 10 V)
- Analog Output: 0/4 mA to 20 mA current output
- Switch Output: 2 relay contact outputs (trip values)
- Configuration: Programmable via PACTware software or using the integrated front-panel keypad and LED display
- Safety Integration: Up to SIL 2 safety integrity level according to IEC/EN 61508
- Fault Detection: Built-in line fault detection (LFD) and sensor burnout monitoring
PEPPERL+FUCHS KFD2-GUT-1.D Temperature Converter (KFD2).
-
PEPPERL+FUCHS KFD2-STC4-Ex1.2O Signal Conditioner
- Manufacturer: PEPPERL+FUCHS
- Model / Part Number: KFD2-STC4-Ex1.2O
- Intrinsic Safety: It acts as a safety barrier.
- Signal Splitting: It takes 1 input from the hazardous area and splits it into 2 separate outputs in the safe area.
- Power Supply: It supplies power to field devices like 2-wire or 3-wire SMART transmitters.
- Two-Way Communication: It transfers regular 4–20 mA analog signals.
- Channels: 1-channel input.
- Input Signal: 0/4 mA to 20 mA.
- Dual Output: Two separate 0/4 mA to 20 mA signals.
- Safety Rating: Up to SIL 3 (Safety Integrity Level) according to IEC/EN 61508.
- Connection: Terminal blocks built with special test sockets for easy troubleshooting.
-
Pepperl+Fuchs KFU8-UFC-EX1.D Frequency Converter
- Manufacturer: Pepperl+Fuchs
- Model / Part Number: KFU8-UFC-EX1.D
- Input: It reads digital input signals from NAMUR sensors or simple mechanical switches (dry contacts). It can handle a wide frequency range from 1 mHz all the way up to 5 kHz.
- Output: It provides a standard analog current output of 0/4 mA to 20 mA. It also features two relay outputs and one transistor output to trigger alarms or shut down machines.
- Power Supply: It has a universal power pack, meaning it can run on multiple kinds of electricity (20–90 V DC or 48–253 V AC).
- Setup: You can easily program it by using the physical buttons and small screen on the front panel, or by plugging it into a computer using PACTware configuration software.
- Installation: It snaps directly onto a standard 35 mm DIN mounting rail inside an electrical control panel.
-
PHOENIX CONTACT 2963718 Safety Relay (PSR-SCP)
- Manufacturer: Phoenix Contact
- Part Number (MPN): 2963718
- Model Designation: PSR-SCP-24UC/ESM4/2X1/1X2
- Nominal Input Voltage: 24 V AC/DC
- Contact Configuration: DPST-NO (2 Enabling/Safety paths) & SPST-NC (1 Signaling/Auxiliary path)
- Safety Integrity Level: Up to SIL 3 (IEC 61508)
- Performance Level: Up to PL e / Category 4 (EN ISO 13849)
- Connection Method: Plug-in screw terminal blocks
- Mounting Type: Standard DIN Rail
- Protection Rating: IP20
PHOENIX CONTACT 2963718 Safety Relay (PSR-SCP).
-
PHOENIX CONTACT 2963750 Safety Relay (PSR-SCP)
Technical Specifications
- Core Function: Emergency stop and safety door monitoring.
- Safety Ratings: Up to Cat. 4 / PL e (EN ISO 13849-1), SIL 3 (IEC 61508).
- Channels: 2-channel operation.
- Contacts: 2 enabling current paths (DPST-NO) and 1 signaling current path (SPST-NC).
- Input Voltage: 24 V AC/DC nominal.
- Switching Capacity: Maximum 6 A / 250 V AC/DC.
- Connection Type: Plug-in screw terminal blocks.
- Mounting: Standard DIN rail mounting.
- WiAutomation US: Available at WiAutomation US.
- PLC Direct: Available at PLC Direct.
PHOENIX CONTACT 2963750 Safety Relay (PSR-SCP).
-
PHOENIX CONTACT 2963763 Safety Relay (PSR-SCP)
- Core Function: Safety monitoring for E-stops, light curtains, and safety gates.
- Safety Integrity: Up to SIL 3, Cat. 4, and PL e compliance according to EN ISO 13849 standards.
- Control Voltage: 24 V AC/DC nominal input.
- Contact Configuration: 3 Enabling current paths (3 NO / DPST-NO) and 1 signaling path (1 NC).
- Switching Capacity: Max. 6 A continuous current / 250 V AC/DC switching voltage.
- Connection & Mounting: Plug-in screw terminal blocks mounted on standard DIN rails.
- Activation Modes: Supports both manually monitored and automatic activation within a single device.
PHOENIX CONTACT 2963763 Safety Relay (PSR-SCP).
-
PHOENIX CONTACT 2963776 Safety Relay (PSR-SCP)
- Safety Ratings: SIL 3 (IEC 61508) • Cat. 4 / PL e (EN ISO 13849-1)
- Nominal Input Voltage: 24 V AC/DC
- Power Consumption: ~1.68 W
- Typical Input Current: 140 mA AC / 65 mA DC
- Output Contacts: 3 Enabling current paths (N/O) • 1 Signaling current path (N/C)
- Response / Release Time: 20 ms (manual start) • 10 ms (two-channel release)
- Connection Method: Plug-in screw terminal block
- Operating Temperature: -20 °C … 55 °C
- Flexible Control: Supports both 1-channel and 2-channel operation loops.
- Activation Modes: Configurable for manual monitored activation or automatic start.
PHOENIX CONTACT 2963776 Safety Relay (PSR-SCP).
-
PHOENIX CONTACT 2963912 Safety Relay (PSR-SCP)
- Control & Channels: 1- or 2-channel control with options for automatic or manually monitored activation.
- Contact Configuration: Features 8 enabling current paths (8PST-NO) and 1 signaling current path (SPST-NC).
- Electrical Ratings: Operates on a 24V AC/DC rated control supply voltage with a maximum switching current of 6 A per contact.
- Installation: Designed for standard DIN Rail mounting and features user-friendly plug-in screw terminal blocks.
PHOENIX CONTACT 2963912 Safety Relay (PSR-SCP).
-
PHOENIX CONTACT 2963996 Safety Relay
- Manufacturer: PHOENIX CONTACT
- Model / Part Number: 2963996
- Type Designation: PSR-SPP-24UC/ESAM4/8X1/1X2
- Supply Voltage: 24 VAC/VDC
- Safety Rating: Up to SIL 3 and PL e, Category 4
- Enabling Paths: 8 normally open
- Signaling Paths: 1 normally closed
- Operating Channels: 1-channel or 2-channel
- Contact Material: Silver tin oxide
- Maximum Current: 6 A
- Mounting: DIN rail
-
PHOENIX CONTACT 2981017 Safety Relay
- Manufacturer: PHOENIX CONTACT
- Model / Part Number: 2981017
- Power Input: It runs on 24 V DC electrical systems.
- Electrical Capacity: It can handle up to 6 Amps of current.
- Connections: It uses a pluggable Push-in terminal block, allowing wires to be connected easily without using screws.
- Size: It is very slim, measuring only 22.5 mm wide (less than an inch) to save space inside electrical cabinets.
- Mounting: It snaps directly onto standard DIN rails.
-
PHOENIX CONTACT 2981020 Safety Relay (PSR-SCP)
- Supply Voltage: 24 V DC (-15 % / +10 %)
- Typical Input Current: 50 mA DC
- Maximum Inrush Current: < 1 A
- Control Channels: 1-channel control
- Contact Configuration: 2 enabling current paths (NO), 1 signaling current path (NC, Type B according to EN 50205)
- Contact Material: Silver tin oxide with gold flash (AgSnO2, gold-flashed)
- Maximum Switching Voltage: 250 V AC/DC
- Minimum Switching Voltage: 10 V
- Limiting Continuous Current: 6 A
- Response Time: 60 ms (Automatic/manual start)
PHOENIX CONTACT 2981020 Safety Relay (PSR-SCP).
-
PHOENIX CONTACT 2981059 Safety Relay (PSR-SCP)
- Safety Integration: Achieves up to SIL 3 (IEC 61508) and PL e / Category 4 (ISO 13849-1) compliance.
- Control Configuration: Offers flexible 1- or 2-channel control with manually monitored or automatic activation options.
- Contact Pathways: Features 3 enabling (normally open) current paths and 1 signaling (normally closed) path.
- Electrical Ratings: Operates on a 24 V AC/DC nominal input voltage with a continuous switching current rating of 6 A up to 250 V AC/DC.
- Wiring System: Features a user-friendly, plug-in screw terminal block connection.
PHOENIX CONTACT 2981059 Safety Relay (PSR-SCP).
-
PHOENIX CONTACT 2981428 Safety Relay
- Manufacturer: PHOENIX CONTACT
- Model / Part Number: 2981428
- Control Voltage: 24V DC.
- Channel Support: Works with 1-channel or 2-channel setups.
- Contact Types: Includes 3 undelayed normally open (N/O) contacts, 1 normally closed (N/C) contact, and 2 N/O contacts with an adjustable dropout delay.
- Time Delay Range: The built-in dropout delay can be configured from 0.2 seconds to 300 seconds across 24 distinct increments.
- Connection Method: Utilizes secure, plug-in screw terminal blocks for quick wiring.
- Mounting: Snaps directly onto standard 35mm DIN rails.
-
PHOENIX CONTACT 2981486 PSR-SCP Safety Relay
- Manufacturer: PHOENIX CONTACT
- Model / Part Number: 2981486
- Supply Voltage: 24 V DC
- Safety Integrity Level: Up to SIL 3
- Performance Level: Up to PL e
- Enabling Contacts: 2 normally open
- Signaling Contact: 1
- Connection: Plug-in screw terminals
- Expansion Interface: TBUS
PHOENIX CONTACT 2981486 Safety Relay Module. Key specifications include Supply Voltage: 24 V DC; Safety Integrity Level: Up to SIL 3; Performance Level: Up to PL e; Enabling Contacts: 2 normally open.
-
PHOENIX CONTACT 2981800 Safety Relay Module
- Manufacturer: PHOENIX CONTACT
- Model / Part Number: 2981800
- Function: Emergency stop, safety door, and light grid monitoring.
- Control Voltage: 24 V DC.
- Current Rating: 6 A maximum current.
- Contacts: Features a maximum of 3 undelayed and 2 dropout delay contacts.
- Delay Time: Adjustable dropout delay from 0.1 to 30 seconds.
- Connection Type: Plug-in screw connection.
- Mounting: Standard DIN rail mounting.
- Safety Ratings: Up to SIL 3 (IEC 61508) and Performance Level e (EN ISO 13849-1).
