- Manufacturer: Beckhoff
- Model / Part Number: EL3201
- Product type: EL3201 EtherCAT Terminal, 1-channel analog input terminal for temperature measurement with RTD (Pt100), 16 bit
- Number of inputs: 1
- Sensor type: Pt100, Pt200, Pt500, Pt1000, Ni100, Ni120, Ni1000, resistance measurement (e.g. potentiometer, 10 ohm to 4 kohm), KTY sensors (types per documentation)
- Connection technology: 2-, 3-, 4-wire (default: 2-wire); 2-wire connection requires an external bridge
- Conversion time: Approx. 24 ms default setting, 4…500 ms configurable
- Temperature range: -200…+850 deg C (Pt sensors); -60…+250 deg C (Ni sensors)
- Resolution: 0.1 deg C per digit; 1 x 32 bit RTD input in the process image; input filter cut-off frequency typ. 1 kHz
- Electrical isolation: 500 V (E-bus/signal voltage)
- Current consumption E-bus: Typ. 190 mA; power supply via the E-bus
- Special features: Integrated digital filter, limit value monitoring, variable connection technology; resistance value can be output directly in ohms or converted to temperature in the terminal
- Weight / dimensions: Approx. 60 g; 12 mm x 100 mm x 68 mm (W x H x D); polycarbonate compact terminal housing with signal LEDs
- Operating conditions: -25…+60 deg C operating, -40…+85 deg C storage, 95% RH no condensation; IP20; vibration/shock per EN 60068-2-6/EN 60068-2-27; EMC per EN 61000-6-2/EN 61000-6-4
- Approvals/markings: CE, CCC, UL, ATEX, IECEx, cFMus; Ex marking ATEX/IECEx II 3G Ex ec IIC T4 Gc; cFMus Class I, Division 2, Groups A, B, C, D
- Product status: Regular delivery (active product; ordering variant ES3201 with pluggable wiring level also available)
-
- Manufacturer: Beckhoff
- Model / Part Number: EL4034
- Product type: EL4034 EtherCAT Terminal, 4-channel analog output terminal, voltage, +-10 V, 12 bit
- Number of outputs: 4
- Signal voltage: -10…+10 V, supplied to the process level with a resolution of 12 bits; output channels share a common ground potential
- Load: > 5 kohm (short-circuit proof)
- Conversion time: Approx. 250 us
- Distributed clocks: Yes (distributed clock support with user synchronization that can be activated)
- Power supply: 24 V DC via power contacts (typ. 40 mA); E-bus current consumption typ. 140 mA; output stages powered by the 24 V supply
- Electrical isolation: 500 V (E-bus/signal voltage)
- Bit width in the process image: 4 x 16 bit AO output
- Special features: Optional watchdog with user-specific output value and ramp; output state indicated by light emitting diodes
- Weight / dimensions: Approx. 85 g; 12 mm x 100 mm x 68 mm (W x H x D); polycarbonate compact terminal housing with signal LEDs
- Operating conditions: -25…+60 deg C operating, -40…+85 deg C storage, 95% RH no condensation; IP20; vibration/shock per EN 60068-2-6/EN 60068-2-27; EMC per EN 61000-6-2/EN 61000-6-4
- Approvals/markings: CE, CCC, UL, ATEX, IECEx, DNV, cFMus; Ex marking ATEX/IECEx II 3G Ex ec IIC T4 Gc; cFMus Class I, Division 2, Groups A, B, C, D
- Product status: Regular delivery (active product; ordering variant ES4034 with pluggable wiring level also available)
-
- Manufacturer: BECKHOFF
- Model / Part Number: EL5042
- Encoder Channels: 2
- Encoder Interface: BiSS-C
- Bus System: EtherCAT E-bus
- Mounting: DIN rail terminal assembly
-
- Manufacturer: BECKHOFF
- Model / Part Number: EL6631-0010
- Fieldbus Function: PROFINET RT controller
- Ethernet Ports: 2-port switched interface
- System Bus: EtherCAT E-bus
- Mounting: DIN rail terminal assembly
-
- Manufacturer: Beckhoff
- Model / Part Number: EL6632
- Technology / fieldbus function: PROFINET IRT, controller (master)
- Number of channels / ports: 1 channel; 2 switched ports (3-port switch, 2 x RJ45 external)
- Ethernet interface: 100BASE-TX Ethernet with 2 x RJ45
- Cable length: Up to 100 m twisted pair between devices
- Protocol: RT or IRT, Conformance Class C
- Min. IRT cycle / min. RT cycle: 500 microseconds / 1 ms
-
- Manufacturer: Beckhoff
- Model / Part Number: KL2872
- Outputs: 16 digital outputs.
- Voltage Rating: 24 V DC (-15% / +20%).
- Current per Channel: Max 0.5 A (short-circuit proof).
- Connection Method: 20-pin connector header for ribbon/flat cables using insulation displacement contacts (IDC).
- Process Image Width: 16 bits (1 bit per output).
- Status Indicators: 16 individual LEDs to display the logical signal state of each channel.
-
REQUEST A QUOTE
- Number of Channels: 3-phase voltage and current
- Nominal Voltage Range: Up to 500 V AC
- Extended Max Current: 5 A AC (Standard variant is 1 A)
- Resolution: 16-bit
- Calculation Bandwidth: Cut-off/Limit frequency of 2 kHz
- Measurement Accuracy: 1% to 5% (depending on wave shape curves)
- Calculated Values: RMS Voltage (U), RMS Current (I), Effective Power (P), Apparent Power (S), Reactive Power (Q), Frequency (F), Phase Shift
- Voltage Inputs: Direct wire connection to network phases L1, L2, L3, and Neutral (N).
- Current Inputs: Fed through the secondary windings of external current transformers into terminal points IL1, IL2, IL3, and IN (star point).
BECKHOFF KL3403-0010 3-Phase Power Measurement Bus Terminal (KL3403 Series).
-
- Manufacturer: Beckhoff
- Model / Part Number: KL4002
- Technology / channels: 2-channel analog output, single-ended
- Signal voltage: 0…10 V DC; load > 5 kOhm (short-circuit proof)
- Resolution / conversion time: 12 bit; approx. 1.5 ms
- Power supply: Via K-bus (no power contacts); K-bus current consumption typ. 75 mA
- Electrical isolation: 500 V (K-bus/signal voltage)
- Process image bit width: Output 2 x 16 bit data (2 x 8 bit control/status optional); no address or configuration setting
-
- Manufacturer: Beckhoff
- Model / Part Number: KL4004
- Number of Channels: 4 independent analog outputs.
- Signal Range: 0 to 10 V DC standard voltage signals.
- Resolution: 12-bit, providing smooth, fine-graded signal transitions.
- Electrical Isolation: 500 V between the internal K-bus and the process data signals.
- Ground Potential: All 4 channels share a single, common ground connection.
- Housing Size: Compact 12 mm width to optimize space on a standard DIN rail.
-
- Manufacturer: Beckhoff
- Model / Part Number: KL4434
- Signal Range: -10 V to +10 V.
- Resolution: 12 bits
- Number of Channels: 4 analog outputs.
- Conversion Time: Typically 4 ms.
- Connection Method: 2-wire installation per output.
- Ground Potential: Common reference ground shared through the 0 V power contact.
-
REQUEST A QUOTE
- Bus Interface: 2 × RJ45 (built-in daisy-chaining/cascading)
- Data Transfer Rate: 100 Mbit/s (100BASE-TX)
- Power Supply: 24 V DC (-15% / +20%)
- K-Bus Current Supply: 1750 mA
- Power Contacts: Max. 24 V DC / Max. 10 A
- Electrical Isolation: 500 V (contacts / supply / Ethernet)
- Operating Temperature: -25°C to +60°C
- Protection Rating: IP20
- Topology Versatility: The dual RJ45 ports allow the coupler to act as a line or star topology endpoint. The upper port connects to the network segment, while the lower port interfaces with downstream EtherCAT devices.
- Placement Restrictions: In an EtherCAT network, the BK1120 can be positioned anywhere along the 100BASE-TX signal transfer section, except directly connected to a standard Ethernet switch (it requires an EtherCAT Master or an appropriate junction component like an EK1000).
- Configuration: System integration and parameterization can be handled via the Beckhoff KS2000 Configuration Software or through EtherCAT ADS (Automation Device Specification).
- Diagnostics: Features onboard LEDs indicating the status of the EtherCAT state machine (RUN and ERROR), alongside standard indicators for the 24 V coupler supply and active power contact bridging.
BK1120 BECKHOFF EtherCAT Bus Coupler.
