DELTA DVP-F2DA Analog Output Card (DVP Series)

• Model Type: Special Function Extension Card (Internal Plug-in slot)
• Output Channels: 2 Independent Channels (CH0, CH1)
• Analog Voltage Range: 0 to +10 V DC (Digital Resolution: 0 to +4,000)
• Analog Current Range: 0 to +20 mA / 4 to +20 mA (Digital Resolution: 0 to +4,000)
• Resolution: 12-bit
• Terminal Connection: 5-pin European-style (G-type) terminal block
• System Compatibility: Delta DVP-EH2, DVP-EH3, DVP-SV, DVP-SV2, and DVP-PM host MPUs
• AC Motor Drive Speed Control: It converts digital commands from the PLC into a varying 0–10V or 4–20mA signal sent to the input terminals (like the ACI or AVI inputs) of Variable Frequency Drives (VFDs) to dynamically alter motor rotation speeds.
• Proportional Valve Control: It regulates modulating valves, fluid actuators, and dampers in chemical processing or HVAC applications.
• System Registers: When installed, the status and configuration parameters correspond directly to Delta system registers like D1149 (detecting card type index 9 for analog output).

Brand New DELTA DVP-F2DA PLC Module. In stock — ships worldwide within 5-10 days.

1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
