Showing 49–64 of 194 results
-
REQUEST A QUOTE
- Manufacturer: ABB
- Model / Part Number: ACS580-01-430A-4
- Model Number: ACS580-01-430A-4
- Global Product ID: 3AUA0000080510
- Power Rating: 250 kW (Normal Use / 400V) or 350 HP (Light Overload / 460V)
- Output Current: 430 A
- Input Voltage: 380 V to 480 V AC (3-Phase, 50/60 Hz)
- Enclosure Rating: IP21 / UL Type 1 standard
- EMC Filter: Integrated Category C2 filter
- Dimensions: 95.5 cm x 38.0 cm x 41.8 cm (H x W x D)
- Weight: 97 kg (213.8 lbs)
- Built-In Standard Features: Includes an intuitive setup assistant control panel, variable-speed cooling fans, and a built-in Safe Torque Off (STO) safety function.
- Protocol Support: Supports embedded Modbus RTU connectivity alongside option modules for PROFIBUS, EtherNet/IP, and PROFINET IO.
- Energy Management: Features integrated energy calculators that track hourly, daily, and cumulative energy savings.
- PLC Direct: Offers brand-new units with detailed component lists and full industrial application specifications on the PLC Direct Product Catalog.
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-02A4-3
- Supply voltage: 3-phase 380…480 V AC
- Nominal input current (I1): 2.4 A
- Nominal output current (I2N): 2.4 A
- Maximum output current (Imax): 3.1 A
- Nominal motor power (Pn): 0.75 kW
- Apparent power (Sn): 1.7 kVA
- Light-duty output: 2.3 A / 0.75 kW
- Heavy-duty output: 1.8 A / 0.55 kW
- Frame size / enclosure: R1, IP21
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-032A-3
- Supply voltage: 3-phase 380…480 V AC
- Nominal input current (I1): 32 A
- Nominal output current (I2N): 32 A
- Maximum output current (Imax): 42 A
- Nominal motor power (Pn): 15 kW
- Apparent power (Sn): 22 kVA
- Light-duty output: 30 A / 15 kW
- Heavy-duty output: 25 A / 11 kW
- Frame size: R3
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-038A-3
- Product type: LV AC industrial wall-mounted single drive (ACS880-01 series)
- Supply voltage: 3-phase 380…480 V AC (Un = 400 V)
- Nominal output current (I2N): 38 A
- Maximum output current (Imax): 54 A
- Nominal motor power (Pn): 18.5 kW (IEC, Un = 400 V)
- Nominal input current (I1): 38 A
- Apparent power (Sn): 26 kVA
- Light-duty rating (ILd / PLd): 36 A / 18.5 kW
- Heavy-duty rating (IHd / PHd): 32 A / 15 kW
- Frame size: R3
- Motor control: Direct torque control (DTC); supports induction and permanent magnet motors
- Safety: Safe Torque Off (STO) integrated as standard
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-03A3-3
- Product type: LV AC industrial wall-mounted single drive (ACS880-01 series)
- Supply voltage: 3-phase 380…480 V AC (Un = 400 V)
- Nominal output current (I2N): 3.3 A
- Maximum output current (Imax): 4.1 A
- Nominal motor power (Pn): 1.1 kW (IEC, Un = 400 V)
- Nominal input current (I1): 3.3 A
- Apparent power (Sn): 2.3 kVA
- Light-duty rating (ILd / PLd): 3.1 A / 1.1 kW
- Heavy-duty rating (IHd / PHd): 2.4 A / 0.75 kW
- Frame size: R1
- Motor control: Direct torque control (DTC); supports induction and permanent magnet motors
- Safety: Safe Torque Off (STO) integrated as standard
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-045A-3
- Supply voltage: 3-phase 380…480 V AC
- Nominal input current (I1): 45 A
- Nominal output current (I2N): 45 A
- Maximum output current (Imax): 64 A
- Nominal motor power (Pn): 22 kW
- Apparent power (Sn): 31 kVA
- Light-duty output: 43 A / 22 kW
- Heavy-duty output: 38 A / 18.5 kW
- Frame size: R4
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-04A0-3
- Supply voltage: 3-phase 380…480 V AC
- Nominal input current (I1): 4.0 A
- Nominal output current (I2N): 4.0 A
- Maximum output current (Imax): 5.6 A
- Nominal motor power (Pn): 1.5 kW
- Apparent power (Sn): 2.8 kVA
- Light-duty output: 3.8 A / 1.5 kW
- Heavy-duty output: 3.3 A / 1.1 kW
- Frame size: R1
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-087A-3
- Power Rating: 45 kW (Kilowatts)
- Current Output: 87 A (Amps) nominal rating
- Voltage Range: 380V to 415V (classified by the "-3" voltage code for 400V 3-phase power)
- Horsepower (HP): 60 HP for Normal Duty / 50 HP for Heavy Duty
- Frame Size: R5
- Enclosure Rating: IP21 standard protection against dust and dripping water (upgradable to IP55)
- Weight: Approximately 23 kg (50.7 lbs)
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-09A4-3
- Power Rating: 4 kW (about 5 Horsepower).
- Input Voltage: 3-phase, 380V to 415V AC.
- Frame Size: R1 (ABB's smallest physical size for this lineup).
- Control Tech: Uses Direct Torque Control (DTC) for highly precise motor control without needing extra sensors.
- Efficiency: Highly efficient at over 97% to 98%.
- Weight: Around 10.4 kg (23 lbs).
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-105A-3
- Power Output: 55 kW (approx. 75 Horsepower) 45 kW (approx. 60 Horsepower)
- Current Output: 105 Amps 87 Amps
- Enclosure Rating: IP21 (NEMA Type 1) standard, which keeps fingers and large dust particles out of the electronics.
- Weight: It weighs about 43 kg (95 lbs), making it a solid piece of industrial machinery.
- Direct Torque Control (DTC): This is ABB's special technology. It lets the drive control the motor's power with incredible precision and speed without needing extra sensors on the motor.
- Built-in Safety: It comes with a safety feature called Safe Torque Off (STO). This safely cuts power to the motor so it cannot spin accidentally during maintenance, keeping workers safe.
- Removable Memory: All the drive's settings and programs are saved on a tiny removable memory unit. If the drive ever breaks, you can just pop the memory card into a new drive and it is ready to go instantly.
- Works with Anything: It can talk to almost any major factory network (like Ethernet or Profibus) using add-on communication modules.
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-12A6-3
- Output Current: 12.6 A to 12.9 A
- Input Voltage: 3-Phase, 380V to 415V AC
- Frequency: 50 / 60 Hz
- Control Technology: Direct Torque Control (DTC) for extreme precision
- Mounting Style: Wall-mounted, compact frame
- Universal Compatibility: It works seamlessly with almost any AC motor type, including standard induction, permanent magnet, and synchronous reluctance motors.
- Direct Torque Control: ABB's proprietary DTC tech responds to changes in motor load in microseconds. This gives you precise speed hold even without an external sensor encoder.
- Energy Optimizer: Inside the programming is a smart feature that reduces power draw by adjusting the energy used to match the exact load required.
- Built-in Safety: Features like Safe Torque Off (STO) come standard. This helps safely shut down power to prevent accidental motor startups during machine maintenance.
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-145A-3
- Power Output: 75 kW (translates to about 100 Horsepower for light-duty or 75 Horsepower for heavy-duty industrial use).
- Frame Size: R6 (This tells technicians the physical build size for cabinet planning).
- Enclosure Rating: IP21 (Basic protection against dust and dripping water; intended for indoor use).
- Weight: 45 kg (About 99 pounds).
- Motor Control: Uses Direct Torque Control (DTC), which provides incredibly precise control over the motor's speed and twist power without needing extra sensor wires.
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-169A-3
- Product ID: 3AUA0000108027
- Voltage Rating: 3-phase, 380 V to 415 V (400V nominal)
- Frame Size: R7
- Frequency: 50/60 Hz input; 0 to 500 Hz output
- Enclosure Protection: IP21 standard (IP55 optional)
- Efficiency: IE2 level
- Load Type: Current (Amps) Power (kW) Equivalent HP
- Height: 880 mm (34.65 in)
- Width: 284 mm (11.18 in)
- Depth: 365 mm (14.37 in)
- Net Weight: 53 kg (116.8 lbs)
- Digital Inputs: 6
- Digital Outputs: 2
- Analog Inputs: 2
- Analog Outputs: 2
- Relay Outputs: 3
- Built-in Interfaces: RS-485 (Modbus RTU), USB
- Optional Fieldbus: PROFINET IO, Profibus DP, EtherNet/IP, Modbus/TCP
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-246A-3
- Power Rating (Normal Duty): 132 kW (approximately 175 Horsepower)
- Power Rating (Heavy Duty): 110 kW (approximately 150 Horsepower)
- Current Rating: 246 Amps
- Voltage Range: 380 V to 415 V (3-phase input and output)
- Frame Size: R8
- Enclosure Rating: IP21 (NEMA Type 1 protection for standard indoor wall-mounting)
- Weight: 68.0 kg (149.91 lbs)
- Direct Torque Control (DTC): Built-in DTC provides precise motor speed and torque control without needing an encoder sensor.
- Harmonic Filtering: Includes a built-in choke to reduce electronic noise distortion and protect your factory grid.
- Broad Connectivity: Supports major communication protocols including EtherNet/IP, Modbus, Profibus, and Profinet.
-
- Manufacturer: ABB
- Model / Part Number: ACS880-01-293A-3
- Power Rating: 160 kW (roughly 175 to 215 Horsepower depending on the heavy-duty or light-overload environment).
- Frame Size: R8 (this refers to its physical dimensions and footprint inside an electrical room).
- Enclosure Rating: IP21 standard protection (keeps out fingers and vertical water drops, meant for indoor walls or clean cabinets).
- Control Type: Direct Torque Control (DTC). This is a special math system built into the drive that reads and corrects the motor's performance in microseconds without needing extra sensor wires.
- Weight: Approximately 70 kilograms (154 lbs).
-
- Manufacturer: ABB
- Model / Part Number: ZCU-12
- Memory Unit: Requires a separate plug-in memory card, specifically the ZMU-02 or ZMU-03 module, to store drive parameters and firmware.
- Input Power: Works on standard internal 24V DC control voltage.
- Supported Protocols: Capable of handling fieldbus communication add-ons including Modbus, CANopen, and EtherCAT.
