- Part Number Variant: E2V24BSF00 (Replaces the multi-pack OEM number E2V24BSF01).
- Connection Size: 12mm x 12mm (Copper ODF connection).
- Actuator Design: Equipped with a stepper motor that provides an equipercentile variation of refrigerant flow, ensuring highly accurate control even at very low flow rates.
- Tight Sealing: Features a Teflon gasket on the actuator and a calibrated spring, eliminating the need for an additional liquid-line solenoid valve.
- Compatibility: Wirelessly or natively supported by Carel controllers like the EVD EVO, MPXPRO, and pCO5 series.
- FrigoPartners: Listed at €149.11 under product number 47-32E2V24BSF00.
CAREL E2V24BSF00 Electronic Expansion Valve (E2V Series).
-
REQUEST A QUOTE
- Manufacturer & Model: CAREL — EVD0000E50 (EVD Evolution Series)
- Communication Interface: RS485 / Modbus® (Built-in serial protocol)
- Valve Compatibility: CAREL Stepper Motor Valves Only (e.g., ExV series)
- Power Supply: 24 Vac (+10/-15%), 50/60 Hz; or 24 Vdc (+10/-15%)
- Transducer Output / Inputs: 4 to 20 mA or low-power ratiometric pressure transducers
- Digital Inputs: 2 programmable digital inputs (e.g., for safety, external enable, or defrost)
- Relay Output: N.O. Contact; 5 A (resistive) / 2 A (inductive) @ 250 Vac
- Physical Housing: DIN Rail Mounting; Plastic; IP20 protection rating
- Superheat Regulation: Seamlessly acts as a standalone sensor controller adjusting the valve position based on pressure and temperature readings.
- Low Superheat Protection (LSH): Prevents liquid floodback to the compressor by rapidly closing the valve if superheat drops below safe limits.
CAREL EVD0000E50 Electronic Expansion Valve Driver (EVD Evolution Series).
-
REQUEST A QUOTE
- Device Type: Remote User Interface Terminal / Display
- Compatibility: CAREL MPXPRO Controller Series
- Visual Indicators: Green LED Display
- Input Interface: Integrated tactile keypad
- Audio Alerts: Internal buzzer for alarms and key feedback
- Connectivity: Commissioning port (for rapid setup & configurations)
- Wireless Support: Built-in Infrared (IR) sensor for compatible devices
- Weight: 0.05 lbs (Approx. 22.7 grams)
- Remote Monitoring & Control: Serves as the primary physical interaction panel for sub-case parameters, allowing real-time viewing of temperatures and operational status without accessing the main controller hub.
- System Commissioning: Features a dedicated commissioning port enabling technicians to rapidly upload, download, or alter complex parameter maps during installation or servicing.
CAREL IR00UGC300 Remote User Interface Terminal (MPXPRO Series).
-
REQUEST A QUOTE
- Supply Voltage: 12 → 24 V ac/dc
- Input Type: Voltage Input (0.5 → 1 V range)
- Front Dimensions: 75 × 33 mm (2.95 × 1.30 in)
- Panel Depth: 72 mm (2.83 in)
- Operating Temperature: 0°C → +50°C (32°F → 122°F)
- Control Action: On/Off Controller
- Replacement Specs: The upgrade model features 2 multi-inputs and 2 relay outputs operating on 24 Vac/dc power.
CAREL IR32W40000 Digital Temperature Controller (IR32 Series).
-
REQUEST A QUOTE
- Outputs: 4 SSR (Solid State Relay) outputs, ideal for rapid cycling applications.
- Inputs: 2 Analog inputs supporting NTC, PTC, or PT1000 temperature sensors.
- Digital Inputs: 2 Digital inputs for external switch or alarm triggers.
- Power Supply: Low voltage operation accommodating 12 to 24 V AC or 12 to 30 V DC.
- Form Factor: Panel-mount design measuring standard 76.2 x 34.2mm front dimensions.
- Interface Features: Built-in internal buzzer for audible alarms and an infrared (IR) receiver for remote control compatibility.
- ST: Temperature Set Point
- RD: Temperature Differential (Hysteresis)
CAREL IR33A7LR20 Universal Electronic Controller (IR33 Series).
-
- Manufacturer: Carel
- Model / Part Number: IR33B7LR20
- Outputs: Equipped with 1 relay output and 1 analog 0-10 V output for proportional or modulating control.
- Power Supply: Operates on low-voltage configurations, compatible with 12–24 VAC (50/60 Hz) or 12–30 VDC.
- Universal Inputs: Supports multiple probe types including NTC, NTC-HT, PTC, PT1000, PT100, TC J/K, as well as direct voltage and current signals.
- User Interface: Compact panel-mount design featuring a large digital display with icons, plug-in screw terminals, an integrated alarm horn, and an infrared (IR) receiver for remote control operation.
- Control Features: Built-in PID autotuning capabilities and dual independent control loops.
-
- Manufacturer: CAREL
- Model / Part Number: IR33C0HB00
- Power Supply: 115 to 230 V AC (50/60 Hz).
- Compressor: 1 x 16 A relay.
- Defrosting: 1 x 8 A relay.
- Evaporator Fans: 1 x 8 A relay.
- Auxiliary/Light: 1 x 8 A relay.
- Inputs: 2 NTC temperature probes (not included) and 2 configurable digital inputs.
- Temperature Range: Reads NTC sensors from -50°C to +150°C.
- Dimensions: Front face measures 76 x 34 mm, with a standard 71 x 29 mm panel cutting template.
-
- Manufacturer: CAREL
- Model / Part Number: IR33C0HB0M
- Power Supply: 115 VAC (±10%), 50/60 Hz
- Relay Outputs: 3 configurable relays
- Sensor Inputs: 1 or 2 NTC thermistor probe inputs
- Display: Bright red, 3-digit LED display for temperature monitoring
- Ingress Protection: IP65-rated front panel (dust-tight and water-resistant); IP20-rated rear
-
- Manufacturer: CAREL
- Model / Part Number: IR33C0LR00
- Power Supply: Operates on a 12 to 24 VAC (or VDC) electrical supply.
- Outputs: Equipped with 4 relay outputs to manage various parts of a cooling unit.
- Inputs: Includes 2 NTC sensor probe inputs to accurately monitor room and defrost temperatures.
- Display & Build: Features a clear, green or red digital display, a built-in alarm buzzer, and an IP65 waterproof rating for the front panel.
-
- Manufacturer: CAREL
- Model / Part Number: IR33E7HR20
- Controller Type: Digital temperature controller
- Sensor Inputs: Thermocouple and RTD
- Control Modes: ON/OFF and PID
-
- Manufacturer: CAREL
- Model / Part Number: IR33E7LR20
- Power Supply: Operates on 12 to 24 VAC (50/60Hz) or 12 to 30 VDC.
- Built-in Features: Includes an internal buzzer for local audible alarms and an infrared (IR) sensor for quick wireless setup via remote control.
- LR: Denotes the low-voltage power supply requirement (12–24 VAC / 12–30 VDC).
-
- Manufacturer: CAREL
- Model / Part Number: IR33F0AHA0（115V）
- Supply Voltage: 115 VAC
- Sensor Inputs: 2 NTC temperature inputs
- Digital Inputs: 1 digital input
- Output Relay Capacity: 2 HP
-
- Manufacturer: CAREL
- Model / Part Number: IR33F0AHE0
- Power Supply: 115 VAC
- Relay Outputs: Features powerful internal relays, including a 3/4 HP compressor relay, alongside 8A and 5A independent relays for controlling peripheral gear like fans or defrost cycles.
- Inputs: Equipped with 2 NTC sensor inputs for highly accurate dual-point temperature monitoring and 1 digital input (DI) for system safety switches or door alerts.
- Connection Type: Secure screw terminals for heavy-duty field wiring.
- Built-in Alerts: Includes an integrated buzzer for real-time error or high-temperature notifications.
- Global Certifications: Fully compliant with CE and UL international safety standards.
-
- Manufacturer: CAREL
- Model / Part Number: IR33F0EC00
- Power Supply: 230 Vac
- Inputs: 2 NTC or PTC probe sensors, plus 1 Digital Input (DI)
- Relay Outputs: Three distinct relays to power system components:
- Compressor Control: 8 A relay
- Defrost Control: 8 A relay
- Evaporator Fan Control: 5 A relay
- Terminal Type: Green screw terminals for wiring connections
- Visual Display: Features a bright LED interface showing current temperature, operational symbols, and system codes.
- Built-in Protection: The front panel is built for panel-mounting with an IP65 water-resistance rating.
- Audio Alerts: Features an integrated internal buzzer to flag system alarms or errors.
-
- Manufacturer: CAREL
- Model / Part Number: IR33F0EN00
- Power Supply: 230 Vac (Alternating Current)
- Temperature Sensor Inputs: 2 NTC probes (Negative Temperature Coefficient temperature sensors)
- Digital Inputs: 1 DI (Can be used for door switches or external alarms)
- Compressor Relay: 8 A
- Defrost Relay: 8 A
- Fan Relay: 5 A
- Terminals: Green screw terminals
- Temperature Range: –50°C to +90°C using standard NTC probes
-
- Manufacturer: CAREL
- Model / Part Number: IR33F0HN00
- Power Supply: 115 to 230 V AC
- Sensor Type: 2 NTC temperature probes
- Relay Outputs: 3 total relays for system control
- Digital Inputs: 2 programmable inputs (like a door switch or alarm)
- Temperature Range: -50 °C to +99 °C
- Display: 2½ digits with an integrated buzzer alarm
- Protection Class: IP65 waterproof front panel rating
- Dimensions: 71mm x 29mm panel cutout size with a 70.5mm depth
