BANNER QCM50-K3D60-Q8-5 High-Performance Photoelectric Color Sensor

Manufacturer: BANNER
Model / Part Number: QCM50-K3D60-Q8-5
Sensing Range: 20 mm to 150 mm (about 0.8 to 6 inches).
Outputs: 3 discrete digital outputs that can be set as PNP or NPN.
Communication: Built-in IO-Link technology, which lets the sensor send detailed data directly to a factory computer network.
Connection: 5-pin M12 Euro-style quick-disconnect plug.
Build Quality: Highly durable die-cast zinc housing with heavy-duty IP67 and IP69K waterproof ratings.
Multi-Color Teaching: It features a special "TEACH" mode that can remember and differentiate up to 7 distinct colors.
Dual Smart Modes: You can set it to Color Mode to look for a specific color within a custom tolerance range, or Best-Fit Mode to automatically sort items by deciding which taught color they match closest.
Long Reach: Standard color sensors usually have to sit right next to an object, but this series can accurately read colors from several inches away.

Availability & Delivery

Availability shown is for reference only and will be confirmed at the time the order is processed.
Published quantities may change without prior notice.
The customer is responsible for verifying part number and specifications before confirming the purchase.
Certain products may be considered special order items depending on availability.
