ABB 3BSE013235R1 TU831V1 Module Termination Unit (MTU) (S800 I/O)

• Channels: Supports up to 8 isolated channels of field signals (configured via 2 x 8 signal terminals).
• Voltage Rating: Maximum rated voltage of 250 V.
• Current Rating: Maximum rated current of 3 A per channel (up to 10 A maximum total current).
• Process Connections: 16 total connection points.
• Mounting: Standard DIN rail mounting. Includes a robust latching device that locks the MTU to the rail to establish functional grounding.
• Physical Protection: IP20 rating.
• Weight: Base weight of approximately 0.2 kg (0.44 lbs).
• ModuleBus Routing: The TU831V1 automatically distributes the ModuleBus to the docked I/O module and bridges it forward to the next adjacent MTU.
• Automatic Shifting/Addressing: It generates correct addressing for the active I/O module by structurally shifting outgoing position signals to the next MTU downstream.
• Mechanical Keying: Features built-in hardware slots to prevent the accidental insertion of an incompatible I/O module, shielding the system from wiring misalignments.

Brand New ABB 3BSE013235R1 TU831V1 Module. In stock — ships worldwide within 5-10 days.

1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
