SMC MHZJ2-10D Pneumatic Parallel Gripper
- Manufacturer: SMC
- Model / Part Number: MHZJ2-10D
- Gripping Force: Approximately 17 Newtons (N) when closing and 19.8 N when opening at 72 psi.
- Stroke Length: 4 mm of total finger movement.
- Operating Pressure: 29 psi to 102 psi (0.2 to 0.7 MPa).
- Repeatability: ±0.01 mm for highly precise, repetitive tasks.
- Port Size: M3 x 0.5 female threads for air line connections.
- Temperature Range: 14°F to 140°F (-10°C to 60°C).
- Linear Guide Rails: The finger mechanisms travel along a built-in guide rail. This prevents the fingers from twisting or shaking under heavy loads.
- Flexible Mounting: The square body has screw holes on three different sides. You can bolt it down in five different position styles depending on your machine layout.
- Auto-Switch Ready: The outer housing features specialized slots. You can slide magnetic sensors (like the SMC D-M9 series) into these slots to let your main computer know if the gripper is currently open or closed.
- SKU: MHZJ2-10D
- New Original In Stock
- 6 Months Warranty
- shipping by DHL or UPS
