MOXA MGATE MB3480 Modbus Gateway (MGate MB3480)
- Serial Ports: 4 x DB9 Male (Software-selectable RS-232, RS-422, or RS-485)
- Baud Rate: 50 bps to 921.6 kbps
- Ethernet Port: 1 x 10/100BaseT(X) port (RJ45 connector, Auto MDI/MDI-X)
- Magnetic Isolation: Built-in 1.5 kV isolation protection for Ethernet
- Device Routing: Auto-Device Routing (Automatically detects Modbus requests and populates slave ID routing tables via a single click)
- Security Functions: HTTPS, SNMPv3, Local database, Authentication, Encryption
- Input Power: 12 to 48 VDC
- Network Bridging: Ideal for connecting legacy serial PLCs, meters, and sensors to modern SCADA software platforms via Ethernet.
- Auto Device Routing: Eliminates the tedious, error-prone manual process of building a slave ID mapping routing table. Instead, it listens to traffic and maps connections with a single mouse click, reducing commissioning times.
- Mixed Serial Infrastructure: Because each of the 4 ports can be configured independently, you can run Modbus RTU on one port and Modbus ASCII on another, or use completely different baud rates within the same gateway.
Brand New MOXA MGATE MB3480 Gateway. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
- SKU: MGATE MB3480
- New Original In Stock
- 6 Months Warranty
- shipping by DHL or UPS
