GE FANUC IC694MDL660-CC Discrete Input Module (PACSystems RX3i)

Technical Specifications

• Module Type: Discrete Digital Input Module
• Number of Points: 32 (Divided into 4 isolated groups of 8 channels)
• Rated Input Voltage: 24 VDC (Accepts range of 0 to 30 VDC)
• Logic Configuration: Positive/Negative (Sink or Source wiring options)
• Input Current: 7.0 mA per point typical at rated voltage
• Backplane Current Draw: 300 mA @ 5 VDC (With all inputs active)
• Optical Isolation: 250 VAC continuous / 1500 VAC for 1 minute (Field to Backplane & Group to Group)
• Configurable Filter Time: 0.5 ms to 100 ms per channel
• Flexible Logic Support: Because it handles both positive and negative logic, the module accommodates sourcing devices (where current flows from the device to the input) or sinking devices (where current flows from the input to the device).
• High-Density Footprint: Packing 32 channels into a single RX3i slot conserves critical backplane space, reducing the physical size of the automation enclosure.
• Industrial Isolation: Built-in optical isolation safeguards delicate internal backplane circuitry from high-voltage spikes or electrical noise generated in the field.

Brand New GE FANUC IC694MDL660-CC Module. In stock — ships worldwide within 5-10 days.

1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
