BELIMO LRQ24AX-SR Industrial Valve Component
- Manufacturer: BELIMO
- Model / Part Number: LRQ24AX-SR
- Nominal Voltage: AC/DC 24 V (50/60 Hz)
- Control Type: Modulating, DC 2…10 V
- Position Feedback: DC 2…10 V
- Torque: 4 Nm
- Running Time: 9 seconds for a 90° rotation
- Power Consumption: 13 W (Running) / 2 W (Holding) / 23 VA (Wire sizing)
- Electrical Connection: 1-meter cable, 4x 0.75 mm²
- Enclosure Rating: IP54 / NEMA 2
- Ambient Temperature: -30°C to 40°C [-22°F to 104°F]
- Automatic Adaptation: Pressing the physical button on the housing triggers an angle-of-rotation adaptation, calibrating the actuator automatically to the valve's absolute end stops.
- Parallel Operation: Multiple actuators can be wired together to run in parallel, provided you match the power performance data.
- Installation Guide: Check the Belimo Support Documents for standard LRQ/NRQ series mounting procedures.
- SKU: LRQ24AX-SR
- New Original In Stock
- 6 Months Warranty
- shipping by DHL or UPS
