ABB ACS580-01-363A-4 Variable Frequency Drive

Manufacturer: ABB
Model / Part Number: ACS580-01-363A-4
Input Voltage: 3-phase, 380V to 480V AC (Standard 400V rating).
Current Rating: 363 A (Normal duty / Light overload).
Heavy Duty Power: 160 kW (215 HP) at 293 A for high-overload applications.
Light Duty Power: 200 kW (270 HP) to 345 A / 363 A for variable torque loads.
Control Modes: Scalar (V/Hz) and Sensorless Vector control.
Enclosure Rating: Typically standard IP21 (UL Type 1) wall-mount hardware.
Physical Weight: Approximately 97 kg (214 lbs).
All-In-One Built Features: Includes integrated EMC filters, a choke to mitigate harmonics, and Modbus RTU fieldbus connectivity as standard equipment.
Assistant Control Panel: Uses an intuitive settings menu and computational setup assistants for straightforward commissioning, operation, and rapid error troubleshooting.
Target Systems: Optimized for large-scale industrial pumps, fans, compressors, conveyors, mixers, and extruders.
Primary Industries: Deployed globally across food and beverage processing, plastics manufacturing, textiles, agriculture, and material handling plants.
Electrical Hazard Safety: Operators must wait at least 5 minutes after disconnecting the main power supply before touching internal components to let the capacitors discharge safely. Verify zero voltage with a calibrated meter.
Circuit Board Cleaning: When clearing dust accumulation, technicians must utilize a specialized anti-static vacuum hose and nozzle. Normal household vacuum units create static discharges that permanently damage internal drive circuitry.
Debris Extraction: Use clean, dry, oil-free compressed air from bottom to top, while keeping a vacuum running concurrently at the top exhaust to secure loose particulates.
