Products

25B-D013N114 ALLEN-BRADLEY Adjustable Frequency AC Drive

Product Line: PowerFlex 525 Series
Input Voltage: 380–480V AC, 3-Phase (50/60 Hz)
Output Current: 13 Amps
Power Rating: 5.5 kW / 7.5 HP (Normal & Heavy Duty)
Frame Size: Frame C
Enclosure Rating: IP20 NEMA / Open Type
EMC Filter: Integrated / Internal EMC Filter
Brake Chopper: Integrated Brake IGBT
Dimensions: 18.4 cm x 10.9 cm x 22.0 cm (7.24" x 4.29" x 8.66")
Weight: 3.5 kg (7.7 lbs)
Advanced Motor Control: Supports Volts per Hertz (V/Hz), Sensorless Vector Control (SVC), closed-loop velocity vector control, and permanent magnet motor control.
Embedded Connectivity: Features an integrated RJ45 EtherNet/IP port for seamless configuration and control network integration, alongside dual-port option cards.
Integrated Safety: Features hardware Safe Torque-Off (STO) certified at PLd/SIL2 Cat 3, which cuts rotational power to the motor without shutting down the entire drive.
Modular Design: The control module splits from the power module, allowing you to perform software configuration and wiring installations simultaneously to save commissioning time.
High-Frequency Output: Capable of handling output frequencies up to 500 Hz to drive high-speed motor applications.

Brand New ALLEN-BRADLEY 25B-D013N114 Adjustable Frequency AC Drive (PowerFlex 525 Series). In stock — ships worldwide within 5-10 days.

1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.

Availability & Delivery

Availability shown is for reference only and will be confirmed at the time the order is processed.
Published quantities may change without prior notice.
The customer is responsible for verifying part number and specifications before confirming the purchase.
Certain products may be considered special order items depending on availability.

Industrial Parts Specialists
