EATON MTL5546Y Galvanic Isolator (MTL Series)
- Technical Attribute: Specification Details
- Number of Channels: 1 (Single Channel)
- Signal Range: 4–20 mA (Analogue Output)
- Power Supply Voltage: 20–35 VDC
- Current Consumption: 35 mA at 24 VDC
- Power Dissipation: 0.8W at 24 VDC
- Communication Supported: Bi-directional HART® pass-through
- Functional Safety Rating: SIL 2 / SIL 3 (IEC 61508)
- Line Fault Detection (LFD): Normal input <6.0V; Open circuit threshold <0.5mA; Short circuit detection <50Ω
- Transfer Accuracy: Better than 20 µA
Brand New EATON MTL5546Y Safety Barrier Isolator. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
- SKU: MTL5546Y
- New Original In Stock
- 6 Months Warranty
- shipping by DHL or UPS
Availability & Delivery
- Availability shown is for reference only and will be confirmed at the time the order is processed.
- Published quantities may change without prior notice.
- The customer is responsible for verifying part number and specifications before confirming the purchase.
- Certain products may be considered special order items depending on availability.
