Showing 1009–1024 of 1357 results
-
REQUEST A QUOTE
- Resolution: 2,000 pulses per revolution (P/R).
- Control Output: Line driver (RS-422A interface) providing differential outputs (A, Ā, B, B̄, Z, Z̄) for high noise immunity.
- Power Supply: 5 VDC (±5% ripple max).
- Mechanical Design: 40mm casing diameter with a 6mm solid shaft.
- Rotational Speed: Rated up to 6,000 rpm.
- Protection Rating: IP50 dust resistance.
Brand New OMRON E6B2-CWZ1X 2000P R Rotary Encoder. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Resolution: 1024 Pulses per Revolution (P/R), delivering highly accurate granular feedback.
- Power Supply Voltage: 5 to 24 VDC, making it widely compatible with different PLCs and control systems.
- Output Type: NPN Open Collector.
- Output Phases: A, B, and Z (reversible), allowing direction sensing via phase difference and origin alignment via the Z-phase index.
- Mechanical Dimensions: 40 mm casing diameter with a 6 mm solid flatted (D-shape) shaft.
- Max Speed: Up to 6000 RPM permissible rotation.
- Environmental Protection: IP50 rating with operating tolerances from -10 to 70 °C.
- Brown: Power Supply (5 to 24 VDC)
- Blue: 0V / Common (GND)
- Black: Phase A output
Brand New OMRON E6B2-CWZ6C 1024P-R Rotary Encoder. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Resolution: 500 Pulses per Revolution (P/R).
- Output Type: NPN open-collector output.
- Supply Voltage: 5 to 24 VDC.
- Output Phases: A, B, and Z (Quadrature output with index pulse).
- Physical Dimensions: 40 mm outer diameter housing with a 6 mm solid shaft (D-type flatted end).
- Maximum Speed: 6,000 RPM.
- Protection Rating: IP50 (dust protection).
- Connection: Standard models come pre-wired with a 2-meter cable.
- Brown: Power Supply
- Blue: Common / Ground (0V)
Brand New OMRON E6B2-CWZ6C 500P R Rotary Encoder. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Series Type: EASY Type (Non-cascadable, simplified on/off functions)
- Protective Height: 185 mm (7.28 inches)
- Detection Capability: 25 mm diameter (Optimized for Hand Protection)
- Number of Beams: 8 beams
- Beam Gap / Pitch: 20 mm
- Operating Range: 0.2 m to 7.0 m (0.65 ft to 23 ft)
- Safety Outputs: 2 x PNP outputs (200 mA max at 24 VDC)
- Supply Voltage: 24 VDC ±20% (SELV/PELV)
- Cable Type: 3-meter pre-wired discrete cable
- Enclosure Rating: IP65 (Dust-tight and protected against water jets)
Brand New OMRON F3SJ-E0185P25 Safety Light Curtain. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Display Device: 3.5-inch TFT color LCD screen
- Resolution: 320 × 240 pixels
- Display Colors: 16.7 million colors
- Menu Languages: English, German, French, Italian, Spanish, Traditional Chinese, Simplified Chinese, Korean, Japanese
- Sensor Capacity: Can recognize and switch between up to 32 sensors max; displays up to 8 sensors simultaneously on the monitor.
- Storage Slot: Micro SD card slot for data logging (measurement results and images).
- Communication Interface: RJ45 (10BASE-T) connector.
- Supply Voltage: 24VDC nominal (Acceptable range: 21.6 Vdc to 26.4 Vdc)
- Housing Material: ABS resin, rectangular shape
- Operating Temperature: 0 to +50°C ambient
Brand New OMRON FQ2-D30 Machine Vision Camera. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Power Supply Voltage: 24 VAC/VDC (50/60 Hz)
- Operating Voltage Range: 85% to 110% of rated voltage
- Power Consumption: 1.7 W max. (at 24 VDC) / 5.7 VA max. (at 24 VAC)
- Safety Outputs (Instantaneous): 3PST-NO (3 Normally Open poles)
- Auxiliary Output: SPST-NC (1 Normally Closed pole)
- Rated Switching Voltage: 250 VAC, 30 VDC
- Operating / Response Time: Operating: 30 ms max. / Response: 10 ms max.
- Safety Category: PLe / Category 4 (conforming to EN ISO 13849-1)
- Housing Width: 45 mm (DIN rail or screw mounting)
- PE: Protective Earth / Ground terminal.
Brand New OMRON G9SA-30124V Relay. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Safety Outputs: 5PST-NO (5 Form A) instantaneous
- Auxiliary Output: SPST-NC (1 Form B)
- Contact Rating: 5A at 250 VAC / 30 VDC
- Safety Performance: Rated up to PL e / Safety Category 4
- Input Channels: Configurable for 1-channel or 2-channel inputs
- Mounting: Standard DIN rail
Brand New OMRON G9SA-501 Safety Relay. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Number of Ports: 3 Ports
- Power Supply Voltage: 24 VDC
- Current Consumption: 80 mA
- Operating Temperature: -10°C to +55°C
- Housing Width: 25 mm
- Unit Weight: Approx. 0.04 kg (40 grams)
- Protocol Support: EtherCAT
- Flexible Topology Modifications: Breaks away from strict daisy-chain limitations to seamlessly allow star, tree, and redundant ring configurations (essential for specialized setups like PMAC Programmable Multi-Axis Masters).
- System Segmenting & Isolation: Allows users to design, test, or debug specific hardware segments independently. If a slave device down-line fails, the junction prevents complete machine shutdowns and minimizes product/workpiece loss.
- Space-Saving Design: Noted as one of the industry's smallest profiles with its ultra-narrow 25 mm footprint, leaving maximum room for other control-cabinet essentials.
Brand New OMRON GX-JC03 Network Switch. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Voltage Supply: AC200/220/240V at 50/60 Hz.
- Output Contacts: DPDT (2 Form C) time-limit contacts rated at 3A at 250VAC (resistive load).
- Time Settings: Ultra-wide coverage from 0.1 seconds up to 9990 hours, easily configured using front-facing pushwheel switches combined with time-unit switches.
- Physical Form Factor: Standard 1/16 DIN (48 × 48 mm front panel).
- Mounting type: 8-Pin Socket (surface or DIN rail mountable via an optional base socket like the Omron PF085A, sold separately).
- Display: High-visibility digital LCD with an integrated countdown bar graph.
- Mode: Function Type
- Power/Coil Terminals: Pin 2 and Pin 7 accept the raw AC220V line input.
Brand New OMRON H3CA-8 AC220V Timer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Model Identification: H3CA-8H AC200/220/240
- Supply Voltage: 200 / 220 / 240 VAC (50/60 Hz)
- Mounting Type: 8-pin plug-in unit (compatible with surface, panel, or DIN rail tracks using separate sockets).
- Time Range: 0.1 seconds to 9,990 hours (configured via thumbwheel switches).
- Display: 5-digit digital display paired with a real-time LCD time-remaining bar graph.
- Contact Form: SPDT (Single Pole Double Throw), typically rated at 3 A resistive load.
- Standards & Compliance: UL Listed, CSA Certified, EMC compliant (EN61812-1), and CE marked.
- Mode: Function Name
Brand New OMRON H3CA-8H 220VAC Timer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Rated Supply Voltage: 100 to 240 VAC (50/60 Hz) / 100 to 125 VDC
- Operating Voltage Range: 85% to 110% of rated voltage
- Time Range Capacity: 0.05 seconds to 300 hours (Field-selectable via rotary dials)
- Contact Configuration: Double-Pole Double-Throw (DPDT) time-limit output
- Contact Rating (Resistive): 5 A at 250 VAC / 5 A at 30 VDC
- Contact Rating (Inductive): 2 A at 250 VAC / 3 A at 30 VDC
- Pin Configuration: 11-pin round socket connection
- Input Type: No-voltage input (NPN type default)
- Accuracy: ±0.2% operating time accuracy
- Dimensions & Mounting: DIN 48 x 48 mm panel cutout (Length ≤ 75 mm)
Brand New OMRON H3CR-A 100-240VAC Timer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Feature / Attribute: Technical Specification Value
- Model Type: Solid-State Multifunctional Timer (8-Pin Connection)
- Rated Supply Voltage: 100 to 240 VAC (50/60 Hz) or 100 to 125 VDC
- Allowable Voltage Range: 85% to 110% of the rated power supply voltage
- Time Setting Ranges: 0.05 s to 300 h (divided into 14 to 18 field-selectable sub-ranges)
- Repeat Accuracy: ±0.2% max. (relative to the full-scale set value)
- Output Type: Relay Output: DPDT (2 Form C time-limit contact form)
- Contact Rating: 5 A at 250 VAC / 5 A at 30 VDC (Resistive Load)
- Power Consumption: Relay ON: Approx. 1.6 W / 2.0 VA at 240 VAC
- Relay OFF: Approx. 1.1 W / 1.3 VA at 240 VAC
Brand New OMRON H3CR-A8 100-240VAC Timer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Manufacturer / Series: OMRON Automation & Safety / H3CR-A
- Pin Configuration: 8-pin round base (Octal connection)
- Supply Voltage Options: Standard variant: 100 to 240 VAC (50/60 Hz) / 100 to 125 VDC
- Low-voltage variant: 24 to 48 VAC / 12 to 48 VDC
- Output Contacts: 1 × SPDT (1C/O) time-delayed contact AND
- Contact Rating: 5 A @ 250 VAC / 30 VDC (Resistive load)
- Timing Range: Ultra-wide range from 0.05 seconds to 300 hours
- Operating Modes: 4 to 5 selectable dial modes (e.g., Interval, ON-Delay)
- Protection Rating: Panel surface: IP40; Terminals: IP00
- Omron Timer: Surface Relay Mounting, 100 to 125V DC/100 to 240V AC, 0.05 sec – 300 hr Model: H3CR-A8E AC100-240/DC100-125
Brand New OMRON H3CR-A8E Timer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Primary Function: Star-Delta Motor Starting Control
- Supply Voltage: 200 to 240 VAC (50/60 Hz) — Fully covers nominal 220V systems
- Pin Configuration: 8-pin round octal plug-in terminal
- Output Type: Time-limit SPST-NO (Star circuit) & SPST-NO (Delta circuit)
- Contact Rating: 5 A at 250 VAC (Resistive Load)
- Time Ranges: 4 selectable scales: 0.5s to 120s maximum setting time
- Star-Delta Transfer Time: Selectable instant step change (0.05s, 0.1s, 0.25s, or 0.5s)
- Mounting Methods: Surface, flush, or DIN track/panel mounting (requires matching socket)
- Protection Rating: IP40 (Panel surface area)
- Compatible Sockets: Ensure you pair this plug-in module with a verified base tracking socket such as the OMRON P2CF-08 (for front-surface/DIN-track mounting) or P3G-08 (for back-mounting).
Brand New OMRON H3CR-G8L AC220 Timer. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Model Number: H7BX-AW AC100-240
- Supply Voltage: 100 to 240 V AC (50/60 Hz)
- Display Range: 6 digits (-99999 to 999999)
- Digit Height: 13.5 mm (Main PV) / 9.5 mm (Sub SV)
- Counting Speed: Selectable 30 Hz or 5 kHz
- Input Methods: No-voltage (NPN) or Voltage (PNP) selectable
- Control Outputs: 2-stage relay output (SPST-NO, 3 A at 250 VAC)
- Dimensions: 72 mm W × 72 mm H × 100 mm D
- IP Rating: IP54 front panel (dust-protected and water-resistant)
- Preset Counters: Configurable as a 1-stage or 2-stage preset counter to actuate relays at target metrics.
Brand New OMRON H7BX-AW AC100-240V Relay. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
-
REQUEST A QUOTE
- Display Type: 9-inch wide TFT LCD screen with a black frame.
- Resolution: 800 × 480 pixels supporting over 16.7 million colors.
- Touch Technology: Resistive touch interface.
- Storage / Memory: Features built-in SD card and USB peripheral support.
- Environmental Protection: Front side IP65 and NEMA 4X rated enclosure for protection against dust and fluid spray.
- Dimensions: 290 mm width × 190 mm height, requiring a 260 mm × 165 mm panel cutout.
Brand New OMRON NA5-9W001B-V1 Touch Screen. In stock — ships worldwide within 5-10 days.
1-year warranty against manufacturing defects. Contact us for pricing — reply within 24 hours.
